3.3 Sensor Array Setup

No Description
1 Wind Vane (measures wind direction)
2 Wind Speed Sensor (measures wind speed)
3 Solar Panel
4 Battery Compartment
5 LED Transmission Indicator (turns on for 4
seconds on power up, flashes once per 16
seconds)
6 Reset Button
Aercus Instruments™ - WeatherSleuth®
Figure 1
No Description
7 Thermo-hygro Sensor (measures
temperature and humidity)
8 UV Sensor
9 Light Sensor
10 Rain Collector (self emptying)
11 Bubble Level
