Aercus Instruments WeatherSleuth Manual page 13

Figure 8a Figure 8b
Hockey Stick Mount Tripod Mount
Northern Hemisphere Locations Only
Reference Figure 9. Locate the four wind vane compass rose indicators of N, E, S, W (representing
North, East, South and West). Align the compass rose direction upon final installation with a
compass or GPS.
Figure 9
Southern Hemisphere Locations Only
This weather station can be used in both the Northern and Southern Hemispheres.
SOUTHERN HEMISPHERE USERS!!!
For stations located in the Southern Hemisphere you must follow these Southern
Hemisphere installation instructions and enter 180 for Wind Direction Offset in the
Calibration screen as shown in 3.6.9 otherwise your wind direction readings will be
incorrect.
Aercus Instruments™ - WeatherSleuth® 13 | P a g e
