Getting Started - REV Robotics MINI BOT Assembly Manual

Welcome to your new REV Mini Bot kit.
First things first, we recommend that you lay out and familiarize yourself with all of the parts.
Below is the list of parts included in your kit, along with the quantity of each
(visuals of parts on next page)
When you finish your assembly, you WILL have extra parts.
Don't worry, you've done nothing wrong.
Consider those parts our gift to you. Go forth and keep creating!
REV PART NUMBER
REV-41-1317
REV-41-1303
REV-41-1300
REV-41-1329
REV-41-1326
REV-41-1347
REV-41-1327
REV-41-1336
REV-41-1354
REV-41-1325
REV-41-1324
REV-41-1361
REV-41-1359
REV-41-1360
REV-41-1431
REV-41-1166
REV-41-1119
REV-41-1337
NOTICE: The Expansion Hub is not inculded in this kit

Getting Started

Materials
PART NAME
Bracket, Bearing Pillow Block
Bracket, Motion
Core Hex Motor (cables included)
Bearing, Through Bore, Long
Bearing, Through Bore, Short
5mm x 75mm Hex Shaft
Shaft Collars
Gear, 72 Tooth
Wheels, 90mm, Traction
Spacer, 1.5mm
Spacer, 3mm
M3, Nyloc Nuts
M3 x 8mm Hex Cap Screws
M3 x 16mm Hex Cap Screws
Extrusion, 225mm, 90-90 Degree
Battery Holder Plate
5.5mm Nut Driver
Gear, 90 Tooth
TOTAL PARTS
8
8
2
12
12
8
20
4
4
28
16
100
100
4(+)
3
2
1
4
