TM
JTP18BABB - GE Profile
Optional Undercounter Installation
with 36" Gas Cooktop (in inches)
3-1/4
19-1/16" Cutout depth
3-1/2" MIN.
Free space
Conduit
1/2" Black
iron pipe
Pressure
regulator
Union
30" Built-in
oven
Shut-off
valve
3/4" Support
4" To 4-1/2"
Right cabinet side
Side View
Note: If a solid
bottom is used
Most 30" Wall Cabinets can be used with this unit.
instead of the
runners, a 6" x 10"
rectangle must be
cut out of the
Cut Opening
bottom for optimum
performance
in Solid
and proper air
Bottom
circulation.
10
6
6
(Must Support 275 lbs.)
Specification Revised 6/99
™
30" Single Wall Oven
Single Oven Wall-Mount or Cabinet Installation
Dimensions (in inches)
Note: These ovens are not
approved for stackable or
side-by-side installations.
2 (two) 90°elbows &
sufficient pipe to
connect in adjacent
cabinet
Junction box
for oven
Junction box in
28-1/4
adjacent cabinet
for counter unit
hook-up
22
Power cord
for counter unit
Allow minimum of 21'' for clearance
to adjacent corners, drawers, walls, or etc.
A=Allow 1" overlap of oven over top and bottom edges of cutout.
B=Allow 11/16"-3/4" for overlap of oven over side edges of cutout.
28-1/2'' MIN.
28-5/8'' MAX.
23-1/2'' MIN.
Cutout depth
30
A
B
27-1/4'' MIN.
Conduit
27-5/16'' MAX.
(48" long)
Cutout height
Recommended
cutout location
32-1/2"
21
from floor
30
KW Rating
240V
3.6
5
208V
2.7
Breaker Size
Junction
20 Amps
†
box
location
†
Note: Check local codes for required
breaker size
22'' MIN.
Note: Oven is rated for use only under the
following cooktops:
• GE 30" and 36" electric coil and CleanDesign
cooktops (Excluding Induction)
• GE 30" and 36" gas standard and sealed
burner cooktops
Note: Gas or electric cooktops may be installed
over this oven. See cooktop installation
instructions for cutout size. See label on back
of oven for approved cooktop models.
Installation Information: Before installing,
consult installation instructions [Pub. No.
31-10125] packed with product for current
dimensional data and for alternate
installation options.
For answers to your Monogram,
GE Profile Performance Series,
GE Profile
™
or GE appliance questions, call
GE Answer Center
®
Listed by
Underwriters
Laboratories
R
®
™
service, 800.626.2000.
