Care in feeding cables
Ensure the cables feeding the multipole plug are clamped to avoid any vibration being transmitted along
them to the unit. Cable clamp posts are provided on the baseplate. The two clamps (highlighted) must be
used to prevent the cable vibrating loose.
380mm
(15")
Notes on installation space
Additional space is required around the plug to accomodate the disconnection of the cable from the unit.
AD network video ©2011
FWD
350mm
(13")
5
