CATEYE
PADRONE DIGITAL
CC-PA400B
Quick Start
START
Click the button and follow the
instructions.
The Bluetooth® word mark and logos are owned by the Bluetooth SIG,
Inc. and any use of such marks by CATEYE Co., Ltd. is under license. Other
trademarks and trade names are those of their respective owners.

Advertisement

loading
Need help?

Need help?

Do you have a question about the CC-PA400B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cateye CC-PA400B

Summary of Contents for Cateye CC-PA400B

  • Page 1 Click the button and follow the instructions. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by CATEYE Co., Ltd. is under license. Other trademarks and trade names are those of their respective owners.
  • Page 2 Thank you for purchasing our cyclocomputer CATEYE PADRONE DIGITAL. This Quick Start Manual explains how to set up the PADRONE DIGITAL and how to install the unit on your bicycle. Please set up the unit according to the specified procedure, then it will be ready for use as a cyclocomputer.
  • Page 3 This PDF contains a movie file. When you click on the movie screen, a message regarding security appears. Click the “Trust in the text” or “Play” button to close the message. Click the screen again to play the movie. Next...
  • Page 4 Setup with a smartphone (Cateye Cycling™) How to install the bracket (movie) How to install the speed sensor (ISC-12) (movie) How to wear the heart rate sensor (HR-12) (movie) *Triple wireless kit only Importing measurement results to a smartphone (Cateye Cycling™)
  • Page 5 Operation of buttons Set up the PADRONE DIGITAL by operating the buttons as follows. Check the button position before you start setting up. Back MENU MODE Press the MENU button and the MODE button on the back of the PADRONE DIGITAL. Next...
  • Page 6 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual Setup with the PADRONE DIGITAL Formatting operation Formatting operation While holding down the MENU button on the back of the PADRONE DIGITAL, press and release the AC button. Setting the speed unit...
  • Page 7 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual Setup with the PADRONE DIGITAL Setting the speed unit Formatting operation When the MODE button is pressed, either “km/h” or Setting the speed unit “mph” is selected for the speed unit display. Select the unit of your choice.
  • Page 8 The unit switches to the pairing standby screen and Pr Pairing with a sensor (1/3) flashes on the screen. Activate the sensor. Entering the tire circumference CATEYE sensors Activating the sensor Setting the clock display Speed/Cadence sensor Move the magnet through the sensor (ISC-12) zone several times.
  • Page 9 Formatting operation Once pairing is complete, the name of the paired sensor Setting the speed unit is shown in the upper display. Display CATEYE sensors Pairing with a sensor (2/3) Speed/Cadence sensor (ISC-12) Entering the tire circumference Heart rate sensor (HR-12)
  • Page 10 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual Setup with the PADRONE DIGITAL Pairing with a sensor (3/3) Formatting operation If you have multiple sensors, press and hold the MODE Setting the speed unit button to go back to the Pairing standby screen.
  • Page 11 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual Setup with the PADRONE DIGITAL Entering the tire circumference Formatting operation Refer to the tire circumference reference table and enter the 4 digits for the tire circumference of the tire on which the sensor is installed.
  • Page 12 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual Setup with the PADRONE DIGITAL Setting the clock display Formatting operation When the MODE button is pressed, either “12h” or “24h” is selected for the clock display. Select the display of Setting the speed unit your choice.
  • Page 13 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual Setup with the PADRONE DIGITAL Setting A.M./P.M. Formatting operation You can switch between “A (a.m.) and P (p.m.)” every time you press the MODE button. Setting the speed unit Press and hold the MODE button to confirm and proceed Pairing with a sensor to the next step “Setting the hour”.
  • Page 14 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual Setup with the PADRONE DIGITAL Setting the hour Formatting operation Pressing the MODE button increases the value flashing (“Hour” of the clock). Enter any value. Setting the speed unit Press and hold the MODE button to confirm and proceed Pairing with a sensor to the next step “Setting the minute”.
  • Page 15 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual Setup with the PADRONE DIGITAL Setting the minute Formatting operation Pressing the MODE button increases the value flashing (“Minute” of the clock). Enter any value. Setting the speed unit Press the MENU button to confirm and switch to the Pairing with a sensor measurement screen.
  • Page 16 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual Setup with the PADRONE DIGITAL Now, setup of the PADRONE DIGITAL is completed. Formatting operation Setting the speed unit If the bracket and speed sensor are not installed on your bicycle, go back to Contents and click the movies of how Pairing with a sensor to install the bracket and speed sensor.
  • Page 17 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual Setup with the PADRONE DIGITAL Setting the hour Formatting operation Pressing the MODE button increases the value flashing (“Hour” of the clock). Enter any value. Setting the speed unit Press and hold the MODE button to proceed to confirm Pairing with a sensor and the next step “Setting the minute”.
  • Page 18 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual Setup with the PADRONE DIGITAL Setting the minute Formatting operation Pressing the MODE button increases the value flashing (“Minute” of the clock). Enter any value. Setting the speed unit After entering, press the MENU button to confirm and Pairing with a sensor switch to the measurement screen.
  • Page 19 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual Setup with the PADRONE DIGITAL Now, setup of the PADRONE DIGITAL is completed. Formatting operation Setting the speed unit If the bracket and speed sensor are not installed on your bicycle, go back to Contents and click the movies of how Pairing with a sensor to install the bracket and speed sensor.
  • Page 20 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual Setup with the PADRONE DIGITAL Tire circumference reference table * Generally, the tire size or ETRTO is indicated on the side of the tire. * Enter values for the rear wheel for the included speed/cadence sensor.
  • Page 21 Operation of buttons Set up the PADRONE DIGITAL by operating the buttons as follows. Check the button position before you start setting up. Back MENU MODE Press the MENU button and the MODE button on the back of the PADRONE DIGITAL. Next...
  • Page 22 Cateye Cycling™. Pairing with a sensor For Android phone For iPhone Entering the tire circumference Other, Changing settings Setup completed * The screen and the functions for Cateye Cycling™ are subject to change. Back Next...
  • Page 23 Pairing of PADRONE DIGITAL * At the moment you turn on the smartphone Bluetooth, the smartphone OS will search for devices, but do not configure settings there. Go back to Cateye Cycling™ Pairing with a sensor and follow the procedure below.
  • Page 24 Back to Contents Quick Start Manual Setup with a smartphone Pairing of PADRONE DIGITAL (1/3) Installing Cateye Cycling™ While holding down the MENU button on the back of the PADRONE DIGITAL, press and release the AC button. (Formatting operation) Pairing of PADRONE DIGITAL...
  • Page 25 Quick Start Manual Setup with a smartphone Pairing of PADRONE DIGITAL (2/3) Installing Cateye Cycling™ From (Menu) at the top left of the Cateye Cycling™ screen, turn on [Connect] and tap [Device]. Pairing of PADRONE DIGITAL (2/3) Pairing with a sensor...
  • Page 26 Quick Start Manual Setup with a smartphone Pairing of PADRONE DIGITAL (3/3) Installing Cateye Cycling™ Tap [Pair to Device]. When Cateye Cycling™ detects PADRONE DIGITAL, a Pairing of PADRONE DIGITAL message is displayed on the smartphone. (3/3) PADRONE DIGITAL Pairing with a sensor...
  • Page 27 Back to Contents Quick Start Manual Setup with a smartphone Pairing with a sensor (1/2) Installing Cateye Cycling™ To use this device, you have to pair it with a sensor that supports the Bluetooth® SMART standard. Pairing of PADRONE DIGITAL...
  • Page 28 Pairing with a sensor (2/2) Tap [Pairing]. The paired sensor is displayed under [Device] and pairing is completed. * When pairing a sensor with Cateye Cycling™, an “A” is dis- Entering the tire circumference played after the sensor name. Repeat the previous procedure to pair different sensors with Cat- eye Cycling™.
  • Page 29 Quick Start Manual Setup with a smartphone Entering the tire circumference Installing Cateye Cycling™ Tap [ISC sensor] displayed under [Device], and then tap [Tire Circumference] (the outer circumference of the tire) to select the tire circumference according to the tire size Pairing of PADRONE DIGITAL written on the side of the tire.
  • Page 30 Quick Start Manual Setup with a smartphone Other, Changing settings Installing Cateye Cycling™ Cateye Cycling™ can configure the following settings when necessary. * Each setting can also be changed after setup has been completed. Pairing of PADRONE DIGITAL Purpose Display Changing the measurement unit (km/h or mph) (Menu) >...
  • Page 31 Back to Contents Quick Start Manual Setup with a smartphone From (Menu) at the top left of the Cateye Cycling™ Installing Cateye Cycling™ screen, set [Connect] to OFF. Setup of the PADRONE DIGITAL will be completed and the display will switch to a measurement screen to which Pairing of PADRONE DIGITAL the setup details have been applied.
  • Page 32 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual How to install the bracket...
  • Page 33 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual How to install the speed sensor (ISC-12)
  • Page 34 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual How to wear the heart rate sensor (HR-12)
  • Page 35 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual Importing measurement results to a smartphone Reset operation (saving of summary data) Reset operation (saving of summary data) After measurement, display data other than Dst2 on the measurement screen and press the MODE button for 2 second.
  • Page 36 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual Importing measurement results to a smartphone Connecting with a smartphone (1/2) Reset operation (saving of summary data) On the measurement screen, press MENU button to dis- play the smartphone search screen.
  • Page 37 Importing measurement results to a smartphone Connecting with a smartphone (2/2) Reset operation (saving of summary data) Launch Cateye Cycling™, and then set [Connect] to ON from (Menu). Connecting with a smartphone When the PADRONE DIGITAL connects to a smartphone, (2/2) it switches to the smartphone connection screen.
  • Page 38 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual Importing measurement results to a smartphone Importing summary data (1/2) Reset operation (saving of summary data) Tap [Activity List] in (Menu) again. Connecting with a smartphone Importing summary data (1/2) Completing import...
  • Page 39 CATEYE PADRONE DIGITAL Back to Contents Quick Start Manual Importing measurement results to a smartphone Importing summary data (2/2) Reset operation (saving of summary data) Tapping the (import from CC) button imports sum- mary data to your smartphone and updates the Activity List.
  • Page 40 Reset operation (saving of summary data) After importing, set [Connect] to OFF from (Menu) at the top left of the Cateye Cycling™ screen. Connecting with a smartphone The PADRONE DIGITAL disconnects from the smartphone and switches to the measurement screen.
  • Page 41 Activity List, the details of the measurement data can be checked and uploaded to service sites such as Connecting with a smartphone CATEYE Atlas™. * To upload data, you must have a registered account Importing summary data with the relevant service site and settings for (Menu) >...
