2.IP Camera Tester Introduction

1B
2.1
General
2B
IP camera tester is designed for maintenance and installation of IP cameras and analog cameras as well
as other security equipment. The 3.5 inch touch screen enables it to display network HD cameras and
analog cameras image, The unit supports many ONVIF PTZ and analog PTZ control. The combination
of touch screen and key buttons make the IP camera tester very user- friendly.
Built in PING, and IP address searching etc network functions, and with DC 12V power output etc
functions, Its portability, user-friendly design and many other functions make the IP tester an essential
tool for all installers or technicians.
2.2 Features
5B
3.5inch 320×240 touch screen, easy to operate.
ONVIF IP camera video testing.
Compatible with H.264/MPEG4/MJPEG IP cameras, such as Dahua, HIKVISION, and ACTI.
Customized service is available.
Built in Wi-Fi: receives video from wireless cameras or ONVIF cameras connected to the
network.
Analog camera video display. Auto adapts and displays the video in NTSC/PAL formats
Support more than 30 protocols, such as PELCO-P，PELCO-D,SAMSUNG etc
Snapshot function allows you to save the current image as a JPG file in the SD card.
Video recording and playback.
LCD screen brightness/contrast/color Saturation adjustable
Ping test: PING is the most conventional network debugging tool; it is used for testing if the
connected IP camera or other network equipment's Ethernet port is working normally and the
IP address is correct.
In digital IP surveillance applications, if the IP camera's IP address is not known; the device
cannot be used. An IP address scan can quickly search for the connected IP camera or other
