IPC IPC1.03 User Manual page 19

A. Protocol
H H
Use the up and down arrow keys to move the yellow cursor to the "
Protocol and support more than thirty PTZ protocols. Such as
H H
Pelco-D,Samsung,Yaan,LiLin,CSR600,Panasonic,Sony-EVI etc.
B. Port
Click and move, to "port" Select the communication port for the PTZ camera controlling (RS485)
C. Baud
Move the yellow cursor to "Baud", Select the baud rate according to baud rate of the PTZ
camera.(150/300/600/1200/2400/4800/9600/19200/57600/115200)
D. Address
Set the ID according the ID of PTZ camera (0~254), the setting address data must be consistent the
speed dome address.
E. Pan speed: Set the pan speed of PTZ camera (0~63)
F. Tilt speed: Set the tilt speed of PTZ camera (0~63)
G. Set preset position (Set PS)
Click and select "Set PS", set and save preset position number(1~128),
H. Call the preset position (Go ps)
Click and select "Set PS", set and save preset position number (1~128), click "sure" to save,
Call some special preset number,can call the dome camera menu
Check and set the protocols, address, interface and baud, all must be consistent with the dome camera,
dome camera, then the IPC tester can test .After setting the parameter, the tester can control the PTZ
and lens
To control PTZ by screen touch:
Tap left, right, upward and downward on the touch screen to control the PTZ rotation direction. By two
fingers move outward and inward on the touch screen to zoom in and out the PTZ.
Page.15.
protocol ", set corresponding
