(1) The camera or dome video output is connected to CCTV IP Tester VIDEO IN,the image
display on the tester .
(2) IP Tester "VIDEO OUT" interface connect to the Video input of monitor and
transmitter and receiver , the image display on the tester and monitor
H
(3) Connect the camera or the speed dome RS485 controller cable to the tester RS485
interface ,(Note positive and negative connection of the cable).

3.3 OSD menu

11B
Press the key 2 seconds to turn on
Press the key 2 seconds to turn off
short press the key to enter sleep mode,press it again to test if tester work abnormally
and cannot be turned off , Press the key
Select Icons to enter, if quit, Please click
Page.11.
optical video
H
several seconds to turn off, the tester reset
