Each HBA is shipped with several numbers clearly marked on the board. These numbers
indicate the following:
IEEE Address
■
World Wide Name (WWN)
■
Serial number
■
The IEEE address is a unique 64-bit identifier that you use when configuring your system.
The FC industry uses the World Wide Name (WWN) derived from the IEEE address for FC
connectivity. If the adapter has two ports, there are two IEEE addresses and two WWNs. Use
the serial number when communicating with Oracle Service.
2. Attach an antistatic strap to your wrist.
Refer to "Observing ESD and Handling Precautions" on page
3. Refer to your system installation or service manual to determine an appropriate
ExpressModule slot in which to install the HBA.
4. Remove power from the system if hot plugging is not supported on the system.
To see if your system supports hot plugging/hot swapping of PCIe adapter cards, refer to your
system documentation.

To Install the HBA

After you have performed the steps in
can install the adapter in your system.
1. Attach an antistatic strap to your wrist.
Refer to "Observing ESD and Handling Precautions" on page
2. Refer to your system installation or service manual to determine an appropriate
ExpressModule slot in which to install the HBA.
17.
"To Prepare for HBA Installation" on page
17.
Chapter 2 • HBA Installation, Configuration, and Removal
To Install the HBA
20, you
21
