- Page 1 StorageTek Dual 8Gb FC Dual GbE HBA, ExpressModule, Emulex Installation Guide For HBA Models SG-XPCIEFCGBE- E8-Z, SG-PCIEFCGBE-E8-Z, SG- XPCIEFCGBE-E8-N, SG-PCIEFCGBE-E8- N and 7105393 Part No: E20756-06 August 2018...
- Page 3 Oracle. Oracle Corporation and its affiliates will not be responsible for any loss, costs, or damages incurred due to your access to or use of third-party content, products, or services, except as set forth in an applicable agreement between you and Oracle.
- Page 4 Oracle Corporation et ses affiliés déclinent toute responsabilité ou garantie expresse quant aux contenus, produits ou services émanant de tiers, sauf mention contraire stipulée dans un contrat entre vous et Oracle. En aucun cas, Oracle Corporation et ses affiliés ne sauraient être tenus pour responsables des pertes subies, des coûts occasionnés ou des dommages causés par l'accès à...
-
Page 5: Table Of Contents
Installing the Hardware .................. 20 ▼ To Install the HBA ................ 21 ▼ To Connect the Optical Cables ............ 23 ▼ To Install the Ethernet Cables ............. 25 ▼ To Apply Power ................ 25 Testing the Installation ................... 28 ▼ To Verify Proper Installation (Oracle Solaris) ........ 28... - Page 6 Removing the Hardware ................. 29 ▼ To Prepare the HBA for Removal Using the HBA Attention Button ... 30 ▼ To Prepare the HBA for Hot-Plug Removal (Oracle Solaris) ..... 30 ▼ To Remove the HBA Hardware ............ 31 3 HBA Software Installation ................ 33 Installing Utilities for Updating the BIOS and Firmware ........ 33...
-
Page 7: Using This Documentation
Audience – Technicians, system administrators, and authorized service providers ■ Required knowledge – Advanced experience troubleshooting and replacing hardware ■ Product Documentation Library Documentation and resources for this product and related products are available at http:// docs.oracle.com/cd/E19353-01/index.html. Feedback Provide feedback about this documentation at http://www.oracle.com/goto/docfeedback. Using This Documentation... - Page 8 StorageTek Dual 8Gb FC Dual GbE HBA, ExpressModule, Emulex Installation Guide For HBA Models SG- XPCIEFCGBE-E8-Z, SG-PCIEFCGBE-E8-Z, SG-XPCIEFCGBE-E8-N, SG-PCIEFCGBE-E8-N and 7105393 • August 2018...
-
Page 9: Hba Overview
C H A P T E R HBA Overview This chapter provides a basic overview of Oracle's StorageTek Dual 8Gb FC Dual GbE ExpressModule HBA, which uses Emulex (now Broadcom) technology. This chapter also describes the various operating systems, host platforms, storage, and infrastructure configurations that support the HBA. - Page 10 HBA Features and Specifications The HBA is also backward compatible with FC ports that operate at 4 and 2 Gbit/second. The Gigabit Ethernet ports can be configured to operate in 10-, 100-, or 1000-Mbit/second Ethernet networks. Table 1, “HBA Features and Specifications,” on page 10 for a list of the HBA features.
-
Page 11: Operating System And Technology Requirements
Table 2, “Supported Operating System/Technology Versions (Minimum) ,” on page If you need to contact Oracle Support, first verify that you have a supported OS installed Note - on the host system, and install the latest HBA driver, utility, and firmware versions. Updating the system and HBA to the latest OS, driver, utility, and firmware versions might address the issue, preventing the need to contact Oracle Support about an issue that has already been fixed. -
Page 12: System Interoperability
Sun Blade T6340 Oracle Solaris Oracle x86 Servers Sun Blade X3-2B Oracle Solaris, Linux, VMware, and Windows StorageTek Dual 8Gb FC Dual GbE HBA, ExpressModule, Emulex Installation Guide For HBA Models SG- XPCIEFCGBE-E8-Z, SG-PCIEFCGBE-E8-Z, SG-XPCIEFCGBE-E8-N, SG-PCIEFCGBE-E8-N and 7105393 • August 2018... -
Page 13: Storage Support
System Interoperability Platform Supported OS/Technology Sun Blade X4-2B Oracle Solaris, Linux, VMware, and Windows Sun Blade X6220 Oracle Solaris, Linux, VMware, and Windows Sun Blade X6240 Oracle Solaris, Linux, VMware, and Windows Sun Blade X6250 Oracle Solaris, Linux, VMware, and Windows... -
Page 14: Switch Support
Table 4, “Software Support ,” on page TABLE 4 Software Support Software (minimum version) Supported OS Sun Cluster 3.x Oracle Solaris StorageTek Dual 8Gb FC Dual GbE HBA, ExpressModule, Emulex Installation Guide For HBA Models SG- XPCIEFCGBE-E8-Z, SG-PCIEFCGBE-E8-Z, SG-XPCIEFCGBE-E8-N, SG-PCIEFCGBE-E8-N and 7105393 • August 2018... -
Page 15: Boot Support
AutoPilot Installer Windows Boot Support The HBA supports booting through the HBA in the following environments: Oracle Solaris 10 01/13 for the x86 and SPARC environments ■ Oracle Solaris 11.1 for the x86 and SPARC environments ■ Preboot Execution Environment (PXE) boot capable (for x86 systems) ■... - Page 16 Environmental Requirements Specification Operating Non-Operating Humidity 10% to 90% relative humidity (RH), 93% RH, noncondensing, 38˚C max wet bulb noncondensing Altitude up to 3000 meters 12,000 meters Vibration 0.20G in all axes, 5-500 Hz sine 1.0G in all axes, 5-500 Hz sine Shock 5G, 11 ms half-sine 30G 11 ms half-sine...
-
Page 17: Hardware Installation And Removal
♦ ♦ ♦ C H A P T E R Hardware Installation and Removal This chapter describes the tasks required to install and remove the HBA. Refer to your system installation or service manual for detailed instructions. This chapter contains the following topics: “Observing ESD and Handling Precautions”... -
Page 18: Best Practices For Installing The Hba
The location of dump files varies, based on your operating system: Windows: OneCommandManager-installation-directory\Util\Dump ■ Oracle Solaris: /opt/ELXocm/Dump ■ Linux: /var/log/emulex/ocmanager/Dump ■ Keep in mind that manual firmware dumps do not collect fatal firmware errors. If the... -
Page 19: Best Practices For Switches And Zoning
Best Practices for Installing the HBA fatal error, and then notifies the HBA driver of the error. The driver then notifies the OneCommand Manager utility (via the elxhbamgrd daemon process) to start the firmware dump. This firmware dump starts automatically, and the dump file is stored in the default dump location, based on your operating system. -
Page 20: Best Practices For Testing The Environment
Installing the Hardware Legacy BIOS issues - many tweaks and patches have been added over the years to resolve ■ various issues, and not all were done with the larger ecosystem (many different types of servers, HBAs, OSes, and so on) in mind. Secure Boot (a UEFI-specific feature) can help you control the boot process, preventing ■... -
Page 21: To Install The Hba
“To Install the Ethernet Cables” on page 25 ■ “To Apply Power” on page 25 ■ “To Verify Proper Installation (Oracle Solaris)” on page 28 ■ “To Verify Attached Storage (Oracle Solaris)” on page 28 ■ To Install the HBA Attach an antistatic wrist strap (refer to “Observing ESD and Handling... - Page 22 To Install the HBA Press down on the plastic tab to release the ExpressModule latch and pull the lever out until it is nearly perpendicular to the ExpressModule front panel. Insert the HBA into its slot, being careful that the extension on the bottom of the lever does not come into contact with the chassis sheet metal during insertion.
-
Page 23: To Connect The Optical Cables
To Connect the Optical Cables To Connect the Optical Cables The HBA does not allow normal data transmission on an optical link unless it is Note - connected to another similar or compatible Fibre Channel (FC) product (that is, multimode to multimode). - Page 24 To Connect the Optical Cables Connect the fiber-optic cable to an LC connector on the HBA. Cable Description Orange Fiber-optic (FC) cable Blue Ethernet (GbE) cable Connect the other end of the cable to the FC device. After the optical cable is connected to the HBA, you are ready to connect the Ethernet cable(s). StorageTek Dual 8Gb FC Dual GbE HBA, ExpressModule, Emulex Installation Guide For HBA Models SG- XPCIEFCGBE-E8-Z, SG-PCIEFCGBE-E8-Z, SG-XPCIEFCGBE-E8-N, SG-PCIEFCGBE-E8-N and 7105393 •...
-
Page 25: To Install The Ethernet Cables
To Install the Ethernet Cables To Install the Ethernet Cables Use high-quality Ethernet cable, category 5e or category 6, that adheres to the specifications in the following table. Ethernet Cable Maximum Length Connector Cat5e UTP 100 meters 8P8C Cat6 UTP 100 meters 8P8C Connect the Ethernet cable to RJ-45 connectors on the HBA. - Page 26 To Apply Power Green LED Yellow LED State Wake-up failure (failed board) POST failure (failed board) Slow blink Wake-up failure monitor Fast blink Failure in POST Flashing POST processing in progress Failure while functioning Failure while functioning Slow blink Normal - link down Slow blink Not defined Slow blink...
- Page 27 To Apply Power Chapter 2 • Hardware Installation and Removal...
-
Page 28: Testing The Installation
Testing the Installation Testing the Installation This section contains the following topics: “To Verify Proper Installation (Oracle Solaris)” on page 28 ■ “To Verify Attached Storage (Oracle Solaris)” on page 28 ■ To Verify Proper Installation (Oracle Solaris) Use the cfgadm command to verify proper HBA installation. -
Page 29: Configuring The Hba For Hot-Plug Operation
Configuring the HBA for Hot-Plug Operation c2 fc connected unconfigured unknown pcie1 pci-pci/hp connected configured If an HBA is shown as unconfigured, use the cfgadm -c configure command to configure it. To view more information about the HBA, use the fcinfo hba-port command. Configuring the HBA for Hot-Plug Operation To Configure the HBA for Hot-Plug Operation Locate the green Power OK LED indicator near the bottom of the HBA front... -
Page 30: To Prepare The Hba For Removal Using The Hba Attention Button
If you want to cancel the operation, press the Attention button again before the LED stops blinking. After the Power OK LED turns off, remove the HBA. To Prepare the HBA for Hot-Plug Removal (Oracle Solaris) If you want to remove the HBA without first halting the operating system and removing power from the associated server blade, prepare the HBA for removal as follows: Use the cfgadm command to identify the HBA to be removed. -
Page 31: To Remove The Hba Hardware
To Remove the HBA Hardware Use the cfgadm -c disconnect command to prepare the HBA for removal. A flashing Power OK LED indicates that the HBA is being prepared for removal. An off Power OK LED indicates that the HBA is ready to be removed. To Remove the HBA Hardware Disconnect all cables. - Page 32 StorageTek Dual 8Gb FC Dual GbE HBA, ExpressModule, Emulex Installation Guide For HBA Models SG- XPCIEFCGBE-E8-Z, SG-PCIEFCGBE-E8-Z, SG-XPCIEFCGBE-E8-N, SG-PCIEFCGBE-E8-N and 7105393 • August 2018...
-
Page 33: Hba Software Installation
HBA utilities, firmware, and operating system- specific drivers, in that order, that might be required by the HBA. Software listed in this chapter as being located at the Oracle designated web site will Note - only be available at the web site if required by the HBA. -
Page 34: To Install Utilities For Updating The Bios Or Firmware
“Using the OneCommand Manager CLI for Troubleshooting a Fatal Error” on page 36 ■ Diagnostic Support for the Oracle Solaris OS Diagnostic support for the HBA is included in the Oracle VTS software. The Oracle VTS software is available for download at: https://support.oracle.com/... -
Page 35: Diagnostic Support For All Other Supported Operating Systems
To Install Diagnostic Support Utilities for a Supported OS Other Than the Oracle Solaris OS: External ■ Internal, single-bit ■ Internal, 10-bit ■ Mailbox ■ Diagnostic Support for All Other Supported Operating Systems Diagnostic support for the HBA with all supported operating systems other than the Oracle Solaris OS is available through version 11.1.218.x, or newer, of the OneCommand Manager... -
Page 36: Using The Onecommand Manager Cli For Troubleshooting A Fatal Error
■ system. Installing Drivers This section contains the following topics: “Installing Drivers for the Oracle Solaris OS” on page 37 ■ “Installing Drivers for All Other Supported Operating Systems” on page 37 ■ StorageTek Dual 8Gb FC Dual GbE HBA, ExpressModule, Emulex Installation Guide For HBA Models SG- XPCIEFCGBE-E8-Z, SG-PCIEFCGBE-E8-Z, SG-XPCIEFCGBE-E8-N, SG-PCIEFCGBE-E8-N and 7105393 •... -
Page 37: Installing Drivers For The Oracle Solaris Os
Installing Drivers for All Other Supported Operating Systems Installing Drivers for the Oracle Solaris OS The HBA driver is included with the Oracle Solaris OS versions supported by the HBA (see “Operating System and Technology Requirements” on page 11). The following additional... - Page 38 StorageTek Dual 8Gb FC Dual GbE HBA, ExpressModule, Emulex Installation Guide For HBA Models SG- XPCIEFCGBE-E8-Z, SG-PCIEFCGBE-E8-Z, SG-XPCIEFCGBE-E8-N, SG-PCIEFCGBE-E8-N and 7105393 • August 2018...
-
Page 39: Known Issues
♦ ♦ ♦ C H A P T E R Known Issues This chapter provides supplementary and workaround information about the HBA. Specific bug identification numbers are provided for service personnel. This chapter contains the following topic: “Server Compatibility Issues” on page 39 ■... -
Page 40: Cannot Verify The Fcode Version Of The Hba On The Sun Blade T6300 And T6320 Systems
To Modify the BIOS Menu Workaround: Reboot the system. Cannot Verify the FCode Version of the HBA on the Sun Blade T6300 and T6320 Systems Bug 15471696 Issue: The FCode version is not displayed when you issue the luxadm fcode -p command from either a Sun Blade T6300 or T6320 system. -
Page 41: Hba Fails To Properly Disconnect During A Hot-Plug Operation On A Sun Blade T6320 System
Sun Blade X6250 System Bug 15593314 Issue: If you install the HBA in a Sun Blade X6250 system (32-bit) that uses the Oracle Solaris 10 01/13 OS, the Ethernet port mapping in the HBA will be incorrect, based on the listed order described in the Sun Blade X6250 system documentation. -
Page 42: On The Sun Blade X6275 System, Default Hba Settings Do Not Allow Boot-From-San Through Fc Ports
To Enable Boot-From-SAN Through the FC Ports of the HBA This will help you identify whether the device is an HBA Ethernet port or any other Ethernet port. ifconfig -a The designator for the HBA Ethernet port has a MAC address of 00:00:C9:xx:xx:xx. On the Sun Blade X6275 System, Default HBA Settings Do Not Allow Boot-From-SAN Through FC Ports...
