Summary of Contents for YOKOGAWA MX100

  • Page 1 User’s Manual MX100 Data Acquisition Unit IM MX100-01E 3rd Edition...
  • Page 2 Foreword Thank you for purchasing the MX100 Data Acquisition Unit. This user’s manual contains useful information about the instrument’s functions, installation and wiring procedures, operating procedures, and handling precautions. To ensure correct use, please read this manual thoroughly before beginning operation. The four manuals below are also provided in addition to this manual.
  • Page 3 Take special note that if you handle the product in a manner that violates these instructions, the protection functionality of the product may be damaged or impaired. In such cases, YOKOGAWA does not guarantee the quality, performance, function, and safety of product.
  • Page 4 • YOKOGAWA makes no warranties regarding the product except those stated in the WARRANTY that is provided separately. • YOKOGAWA assumes no liability to any party for any loss or damage, direct or indirect, caused by the user or any unpredictable defect of the product.
  • Page 5 NO. (instrument number) on the name plate. Main Module Model Suffix Code Description MX100 MX100 main module Manual language English (comes with an English manual) Supply voltage 100 VAC-240 VAC Power supply and power cord 3-pin inlet, UL/CSA Standard power cord [Maximum rated voltage: 125 V;...
  • Page 6 Base Plate Model Suffix Code Description MX150 MX100 base plate (includes two brackets for DIN rail mount) Base type -1-6 The value of the suffix code corresponds to the maximum number of input/output modules that can be installed. MX150-6 is for one main module, and six input/output modules.
  • Page 7 User’s Manual (IM MX180-01E). Paper Manuals • MX100 Data Acquisition Unit Operation Guide (IM MX100-02E) • Precautions on the Use of the MX100 Data Acquisition Unit (IM MX100-71E) • MX100 Data Acquisition Unit Installation and Connection Guide (IM MX100-72E) IM MX100-01E...
  • Page 8 No. Name Model Minimum Q’ty Note MX100 version 772050-01 Available only for non-customized upgrade kit versions of the MX100. The /DS cannot be added. 10-CH screw terminal 772061 Dedicated to the MX110-UNV-M10/ block (with RJC) MX115-D05-H10/MX115-D24-H10 Connection cable 772062-050 1...
  • Page 9 Calls attentions to actions or conditions that could cause light injury to the user or damage to the instrument or user’s data, and precautions that can be taken to prevent such occurrences. Note Calls attention to information that is important for proper operation of the instrument. viii IM MX100-01E...
  • Page 10 Checking the Contents of the Package ................... iv Conventions Used in This Manual ....................viii Chapter 1 Explanation of Functions Overview of the MX100 Data Acquisition Unit..............1-1 Main Module ........................1-2 Input/Output Modules ....................... 1-2 Base Plate ........................1-4 PC Software ........................
  • Page 11 Wiring the 4-Wire RTD Resistance Input Modules ............2-11 Wiring the Strain Input Modules..................2-11 Wiring the Digital Input Modules (-D05, -D24) ..............2-14 Wiring the Analog Output Modules ................. 2-15 Wiring the PWM Output Modules ................... 2-15 Wiring the Digital Output Modules .................. 2-16 IM MX100-01E...
  • Page 12 Connection Procedure ....................2-20 Checking the Communication Status................2-21 Initializing the Settings ....................2-21 Measures against Noise on the MX100 Data Acquisition Unit ........2-22 Integrating A/D Converter ....................2-22 First-Order Lag Filter ...................... 2-23 Handling of the CF Card ....................2-24 Handling Precautions of the CF Card ................
  • Page 13 Contents Chapter 5 Dual Save Functions (/DS option only) Overview of Functions ....................... 5-1 Dip Switch Settings ......................5-2 Explanation of Functions ....................5-3 CF Card Data File ......................5-11 Index IM MX100-01E...
  • Page 14 PC as well as monitor and acquire the measured data on the PC. One to twenty MX100 Data Acquisition Units can be connected to a single PC (one unit using the MX100 Standard Software, or one to twenty units (or up to 1200 input channels) using MXLOGGER).

  • Page 15: Main Module

    1.1 Overview of the MX100 Data Acquisition Unit Main Module The main module is equipped with a power supply connector, a power switch, an Ethernet port, a CF card slot, and other parts. It controls the power supply to and the control of each input/output module, communications with a PC, data storage to the CF card when communication is disconnected, and other functions.
  • Page 16 1.1 Overview of the MX100 Data Acquisition Unit 4-CH, Medium-Speed Strain Input Module (MX112-B12-M04, MX112-B35-M04) • Minimum measurement interval: 100 ms • Maximum number of inputs: 4 inputs • Input system: floating balanced input (isolation between channels) 4-CH, Medium-Speed Strain Input Module (MX112-NDI-M04) •...

  • Page 17: Base Plate

    The base plate is equipped with connectors for connecting the main module and input/ output modules. There are six types of base plates available (allowing connection of one to six input/output modules). You can rack-mount or panel-mount the MX100 by attaching a DIN rail mount bracket to this base plate.
  • Page 18 PC Software The MX100 Standard Software comes standard. It allows one MX100 Data Acquisition Unit to be connected to a PC and performs measurement data acquisition. The MX100 Standard Software consists of the three software programs below. For details about the software functions and operating procedures, see the MX100 Standard Software User’s...

  • Page 19: Communications

    Main Module Functions The main module is the heart of the MX100 Data Acquisition Unit. Ethernet port 7-segment LED DATA ACQUISITION UNIT * Normally all switches are ON. ETHERNET Dipswitch* Used when initializing settings 1 2 3 4 5 6 7 8...

  • Page 20: Filters

    PC’s time information is stored along with the measurement time information on the main module. When the Viewer of the MX100 Standard Software is used to open the recorded measurement data, the “time synchronization” function can be used to correct the measurement time relative to the PC’s time based on the PC’s time information.

  • Page 21: Alarms

    MX100 Data Acquisition Unit. Unit Number Display Since a single MX100 Data Acquisition Unit can be connected to a PC on the MX100 Standard Software, the unit number is fixed to 00 and displayed as .
  • Page 22 Unit Confirmation Display The figure below shows the display that appears when you confirm the MX100 Data Acquisition Unit that is connected using the MX100 Standard Software or MXLOGGER (software sold separately). The word –CALL– flows through the display from left to right.

  • Page 23: Saving Data To The Cf Card

    The table below shows the interval (a guideline) over which data can be saved to the CF card when one type of measurement interval is used. * The time from the point when the communication between the PC and MX100 is disconnected and acquisition of measured data is stopped to the point when data storage to the CF card starts.
  • Page 24 1.2 Main Module Functions Precautions When Using the CF Card On the MX100, measured data can only be saved to the CF card (backed up) when recording of measured data to the PC via communications is turned OFF (unless the /DS option function is active).
  • Page 25 MX100 (2003/01/01 00:00:00). Then, when the PC software is started and connection to the MX100 is made, the current date/time on the PC is transmitted to the MX100. The MX100 is reset to the received date/time.

  • Page 26: Functions Of The 4-Ch, High-Speed Universal Input Module

    -200.0 to 300.0°C Cu10 L&N -200.0 to 300.0°C Cu10 WEED -200.0 to 300.0°C Cu10 BAILEY -200.0 to 300.0°C J263B 0.0 to 300.0K Level Vth = 2.4V Contact input ON: 100 Ω or less, OFF: 10 kΩ or more 1-13 IM MX100-01E...

  • Page 27: Measurement Interval, Integration Time, And Filter

    For details about the relationship between noise and integration time, see section 2.7, “Measures against Noise on the MX100 Data Acquisition Unit.”In addition, the type of noise rejection filter switches as shown in the table below.

  • Page 28: Functions Of The 10-Ch, Medium-Speed Universal Input Module

    Cu10 WEED -200.0 to 300.0°C Cu10 BAILEY -200.0 to 300.0°C J263B 0.0 to 300.0K Level Vth = 2.4 V ON: 1 kΩ or less, OFF: 100 kΩ or more Contact input (parallel capacitance: 0.01 µF or less) 1-15 IM MX100-01E...

  • Page 29: Measurement Interval, Integration Time, And Filter

    1.4 Functions of the 10-CH, Medium-Speed Universal Input Module The following inputs can be used on MXLOGGER or the MX100/DARWIN API (sold separately). These inputs cannot be used on the MX100 Standard Software. Input Measurement Range Type Rated Measurement Range 60mV (high resolution) 0.000 to 60.000 mV...

  • Page 30: Functions Of The 6-Ch, Medium-Speed Four-Wire Rtd Resistance Input Module

    ON: 1 kΩ or less, OFF: 100 kΩ or more Contact input (parallel capacitance: 0.01 mF or less) RTD and resistance are all 4-wire measument The Pt500 resistance table is Pt100 × 5, and the resistance table for Pt1000 is Pt100 × 10 1-17 IM MX100-01E...

  • Page 31: Measurement Interval, Integration Time, And Filter

    For details about the relationship between noise and integration time, see section 2.7, “Measures against Noise on the MX100 Data Acquisition Unit.” In addition, the type of noise rejection filter switches as shown in the table below.

  • Page 32: Functions Of The 4-Ch, Medium-Speed Strain Input Module (-B12, -B35, And -Ndi)

    30 VACrms, or 250 VACrms between input and ground. For -NDI The common mode voltage between channels in a single module when applied continuously is 30 VACrms, and 30 VACrms between input and ground (shell is non- isolated). 1-19 IM MX100-01E...

  • Page 33: Initial Balancing (Initial Unbalance Value Adjustment)

    Initial unbalanced value Strain Reset With the MX100, initial balancing is performed in the ±10000 µ strain range. Initial balance: The value when the command is executed is taken as the initial unbalanced value, and the measured value is set to zero.

  • Page 34: Scaling Settings When Using A Strain Gauge Type Sensor

    Using the symbols that have appeared in the explanation thus far, after setting the scale maximum and minimum, the values are as follows. Span minimum = [(K(mV/V) × 2000) / Y(unit)] × Smin ([µ]Str) Span maximum = [(K(mV/V) × 2000) / Y(unit)] × Smax ([µ]Str) 1-21 IM MX100-01E...

  • Page 35: Compensation When The Gauge Factor Differs

    Span maximum: 15 × 500.25 µStr/mm = 7503.75 µStr would be appropriate settings. The measuring range becomes 20000 µStr, making the resolution on the MX100 1 mStr, therefore we can round as follows. Span minimum: 1001 µStr Span maximum: 7504 µStr Compensation When the Gauge Factor Differs If the gauge factor of the gauge being used differs from 2.00, it can be...

  • Page 36: Functions Of The 10-Ch, High-Speed Digital Input Module (-D05, -D24)

    Detection Detection Detection interval interval interval Detection interval = Measurement interval × 75% to 90% Chattering • Measurement interval of 5 s or more: Use the wider of the ON/OFF width of approximately 4.5 s 1-23 IM MX100-01E...

  • Page 37: Functions Of The 8-Ch, Medium-Speed Analog Output Module

    Holds the last calibration command output value* Non-calibrated channels Holds the output value (holds the last output value during steady operation (see section 1.10)) * Holds the last calibration command output value until the next output update. 1-24 IM MX100-01E...

  • Page 38: Functions Of The 8-Ch, Medium-Speed Pwm Output Module

    10 ms interval setting rng: 10 ms to 300.00 s Can be set in units of 10 ms Output Update Interval 100 ms (minimum). It is not synchronized to the measurement interval. Output Range 0.000% to 100.000% Operation When Errors Occur upon Startup See section 1.10. 1-25 IM MX100-01E...

  • Page 39: Operation Of The 8-Ch Medium-Speed Analog Output Module And The 8-Ch Medium Speed Pwm Output Module

    Operation upon startup (Command output) Output requested Command output Pattern output Before pattern output starts Operation upon startup (Command output) Pattern output starts Command output * Monitor “Off” on the PC software, and “Skip” on the MX100/DARWIN API. 1-26 IM MX100-01E...
  • Page 40 PWM: 1 ms ↔10 ms or interval (until next output event) (cmd. output) Op. setting chng. Trans. between units → trans. within units Trans. between units → manual output Trans. between units → pattern output Manual output R ange setting chng. AO: V ↔ mA Output value held (cmd. output) PWM: 1 ms ↔10 ms or interval (until next output event) Op. setting chng. Manual output → trans. within units Manual output → trans. between units Manual output → pattern output Span setting changes Pattern output Range setting chng. AO: V ↔ mA Output value held (cmd. output) PWM: 1 ms ↔10 ms or interval (until next output event) Op. setting changes Pattern output → trans. within units Pattern output → trans. between units Pattern output → manual output Span setting changes 1-27 IM MX100-01E...

  • Page 41: Steady Output Operation

    * on: enabled off: disabled Transmission output execute enabled: when “Transmit” under the Action menu of the PC software is selected Transmission output execute disabled: when “Transmit” under the Action menu of the PC software is not selected 1-28 IM MX100-01E...

  • Page 42: Output When Abnormal, Or After Recovery From Abnormality

    Range information error Operation upon errors occurrence (except for transmission within Calibration value error units, since the transmission Unusable modules source input channel is illegal) Initial balance error No effect (±Over is likely) * [SQR] is a placeholder for the number corresponding to the error. 1-29 IM MX100-01E...
  • Page 43 CPU abnormality Operation upon errors * See “Output Operation after Recovery from Abnormality” on the next page. ** However, only within the range that can be output. Ex.: If the span for PWM is set to 0-100%, +Over is +100% and -Over is 0%. 1-30 IM MX100-01E...
  • Page 44 If the error recovery time is 10 s or more; operation error occurrence → operation upon startup → command output If the error recovery time is within 10 s, Operation upon startup → command output CPU abnormality (does not recover) Operation upon errors * Executes the command output from the PC software after recovery from errors. 1-31 IM MX100-01E...

  • Page 45: Functions Of The 10-Ch, Medium-Speed Digital Output Module

    MX100 main module Failure: Deenergized * Below are the errors that can occur in the MX100. • A data output request timeout (60 s) occurs while recording data. • An input module detected at power-on that is able to make measurements is removed.

  • Page 46: Handling Precautions

    • Do not bring charged objects near the signal terminals. Doing so can lead to malfunction. • Do not pour volatile agents on the MX100 or leave it in contact with rubber or PVC products for an extended time. Doing so can lead to malfunction.

  • Page 47: Installation

    The MX100 Data Acquisition Unit can be used on a desktop, on a floor, in a rack mount, or in a panel mount. In all cases, be sure to install the instrument in a vertical position.
  • Page 48 Index Attachment to a DIN Rail As shown in the figure below, you can rack-mount or panel-mount the MX100 Data Acquisition Unit by attaching a DIN rail mount bracket to the base plate. • Attachment of the DIN rail mount bracket •...

  • Page 49: Attaching The Modules

    Main module Input/Output module Latch lever (pull up to remove the Module attachment screw Base plate module from the base plate) Note The main module can only be attached to the right end of the base plate. IM MX100-01E...

  • Page 50: Attachment Positions And Channel Numbers

    The figure below shows how the channel numbers are identified on the PC. Representation of channel numbers: Channel numbers in a unit (001 to 060) Unit number (00 to 19) * When connecting to the module using the MX100 Standard Slot number Software, the number is fixed to 00. MX100...

  • Page 51: Connecting The Signal Wires

    4-CH, High-Speed Universal 4-CH, Medium-Speed Strain Input Module Input Module (-B12, -B35) Pull-out handle The terminal block can The terminal plate can be be attached and attached and detached. detached. Attachment screw (Loosen before removing the terminal plate.) IM MX100-01E...

  • Page 52: Screw Terminal Block

    Attachment to a DIN Rail for connector cover Attachment screw Connector cover DIN rail Connection cable between the input module and screw terminal block (772062-0XXX*) Latch lever * Length: 050 or 100 cm. (Pull down to detach.) Terminal cover Attachment screw IM MX100-01E...

  • Page 53: General Precautions When Wiring The Input/Output Signal Wires

    CAUTION • If a large pulling force is applied to the input/output signal wires connected to the MX100, the terminal or signal wire may break. To prevent this from happening, fix all the wiring cables to the installation panel. • Wiring of the Strain Input Module (-NDI) When connecting a bridge head, in order that the empty weight of the cable does not exceed 5 kg, ensure that the cable does not hang down more than 1.5...
  • Page 54 Consider the points indicated below to prevent noise from entering the measurement circuit. For a description of the measures against noise on the MX100, see section 2.7. • Keep the measurement circuit away from the power supply cable (power supply circuit) and ground circuit.

  • Page 55: Wiring Procedure

    Note that RTDs and resistors cannot be connected in parallel. Wiring Procedure 1. Turn OFF the power to the MX100. 2. Loosen the terminal cover attachment screw and lift up the terminal cover. 3. Connect the signal wires to the terminals.

  • Page 56: Wiring The 4-Wire Rtd Resistance Input Modules

    D( H) Bridge head (319300) No.1 No.2 No.3 No.4 No.5 • One-Gauge Three-Wire Method R: fixed resistance resistance value of lead wire Rg: resistance value of strain gauge e: output voltage from bridge E: voltage applied to bridge 2-11 IM MX100-01E...
  • Page 57 E: voltage applied to bridge -B12, -B35 -NDI Jumper setting switch A(+V) 319300 dose not support the opposing 2-gauge method. No.1 No.2 B( L) No.3 C(-V) No.4 No.5 D( H) No.3 No.1 No.2 No.4 No.5 2-12 IM MX100-01E...
  • Page 58 E: voltage applied to bridge Rg1, Rg3 Rg2, Rg4 Rg1, Rg2 Rg3, Rg4 -B12, -B35 -NDI Jumper setting switch A(+V) No.1 No.2 B( L) No.3 C(-V) No.4 No.5 D( H) Bridge head (319300) No.1 No.2 No.3 No.4 No.5 2-13 IM MX100-01E...

  • Page 59: Wiring The Digital Input Modules (-D05, -D24)

    Twice the sampling interval or more Input threshold level: 24 V logic: OFF at 6 V or less and ON at 16 V or greater Terminal type: Clamp Applicable wire size: 0.14 to 1.5 mm (AWG26 to 16) 2-14 IM MX100-01E...

  • Page 60: Wiring The Analog Output Modules

    OFF. ** This module has a built-in fuse. The built-in fuse protects against fires or abnormal emissions of heat due to load shortages or other abnormalities. It does not protect against damage to internal circuits. 2-15 IM MX100-01E...

  • Page 61: Wiring The Digital Output Modules

    250 VDC/0.1 A, 250 VAC/2 A, or 30 VDC/2 A (resistance load) Terminal type: Clamp, attached and removed in units of 5 channels Applicable wire size: 0.08 to 2.5 mm (AWG28 to 12) Note Do not connect anything to the empty terminals of the digital output module. 2-16 IM MX100-01E...
  • Page 62 Power Supply and Power Cord Is M) 1. Check that the power switch of the main module is OFF. 2. Connect the power cord plug to the power connector of the MX100 Data Acquisition Unit. (Use the power cord that came with the package.) 3.
  • Page 63 4. Close the power supply terminal cover and secure it with the screw. Power supply terminal cover Protective grounding cord Power cord Protective grounding cord crimp-on lugs with isolation sleeves Power cord 2-18 IM MX100-01E...

  • Page 64: Turning On/Off The Power Switch

    When turned ON, the 7-segment LED (see page 1-8) illuminates. When the instrument is ready (after completing the self-test), the unit number is displayed. When using the MX100 Standard Software, the unit number is fixed at 00 (displayed as “ ”.

  • Page 65: Connection Procedure

    100BASE-TX), but connection may fail on some hubs due to the hub not recognizing the signal output from the MX100. If this happens, you can turn only dip switch 6 of the main module OFF to fix the data rate to 10 Mbps. Operate the dip switch only when the power is turned OFF.

  • Page 66: Initializing The Settings

    8), and then displays bF. Check the status of step 3, then turn the power OFF. Turn dip switch 5 back ON. Check that the settings have been initialized (using the MX100 Standard Software, for example). • Normal setting 7-segment LED...

  • Page 67: Measures Against Noise On The Mx100 Data Acquisition Unit

    • MX100 Performance Specifications (TI 04M08B01-00E) Describes in detail the functions related to noise rejection specific to the MX100 Data Acquisition Unit. This section briefly describes the integrating A/D converter and the first-order lag filter that the MX100 Data Acquisition Unit employs as measures against noise.

  • Page 68: First-Order Lag Filter

    In such cases, set the measurement interval to 200 ms or more. First-Order Lag Filter For noise sources other than power supply noise, the MX100 Data Acquisition Unit is equipped with a first-order lag filter having output characteristics indicated in the figure below against step input.

  • Page 69: Inserting The Cf Card

    (see the figure above) at the top section of the slot. After the data save operation to the CF card stops (the operation mode on the 7-segment LED described on page 1-8 changes from backup to measurement), eject the CF card. 2-24 IM MX100-01E...

  • Page 70: Error Display On The 7-Segment Led And Corrective Actions

    Index If servicing is necessary, or if the instrument is not operating correctly after performing the corrective actions below, contact your nearest YOKOGAWA dealer. Errors at Power ON The left and right digits of the 7-segment LED display “b” and an error code, respectively.

  • Page 71: Module Errors

    Delete unneeded data to increase the free space, or format the CF card. If you are using a software application through the MX100/ DARWIN API, the timeout setting may not be appropriate. If so, change the value to an appropriate value.

  • Page 72: Troubleshooting

    The power supply is shorted inside Replace the main module. the main module. (Servicing required.) The MX100 cannot be detected from the PC or cannot be detected with the Search button. Probable Cause Corrective Action Ref. Page The LINK LED does not turn ON.
  • Page 73 3.2 Troubleshooting The MX100 can be detected using the Search button, but connection fails. Probable Cause Corrective Action Ref. Page The IP address is set to the default Set the correct IP address. value. The default value cannot be used to make the connection.
  • Page 74 The temperature error is large or is unstable. Suppress changes in the ambient temperature The ambient temperature change is drastic. such as by placing the MX100 in a box. The temperature error is large or is unstable. Match the thickness and length of the three wires.

  • Page 75: Calibration

    Calibration It is recommended that the MX100 be calibrated once a year to assure its measurement accuracy. A calibration instrument with an appropriate accuracy and resolution is required for calibrating the MX100. Range Calibration of DC Voltage, RTD, Resistance, Strain, and Analog Output Required Instruments •...
  • Page 76 * When calibrating the RTD (1 mA) 60 mV range, connect 60 Ω to the input terminal of CH6. When calibrating the RTD (1 mA) 200 mV range, connect 200 Ω to the input terminal of CH4. Resistance standard IM MX100-01E...
  • Page 77 * The Full calibration value of 2000 µstrain range is approximately to 12000 µstrain The Full calibration value of 20000 µstrain range is approximately to 30000 µstrain The Full calibration value of 200000 µstrain range is approximately 200000 µstrain IM MX100-01E...
  • Page 78 Index For -NDI Connect CH2 only Bridge head (319300) • When calibrating the output range of the 8-CH, Medium-Speed Analog Output module All channels are calibrated at Zero (0 V) and Full (10 V). Digital multimeter YOKOGAWA 7562 IM MX100-01E...

  • Page 79: Calibration Of Temperature Measurements Using Thermocouples

    • Unlike the range calibration of DC voltage or RTD, the input section cannot be adjusted for calibration of temperature measurement on the MX100 Data Acquisition Unit using a thermocouple. If accuracy specifications are not upheld after calibration of temperature measurement using thermocouples (see sections 4.4 and 4.5), check for input error and...

  • Page 80: Maintenance Of Parts

    There are no replacement services for the parts listed. If you are to use the MX100 for an extended time, repair or repurchase the main module by referring to the service life of the parts and taking into consideration the actual usage conditions.

  • Page 81: Mx100 Maintenance And Test Using Communication Commands

    Ethernet cable, and using a terminal emulator such as Telnet on the PC. The communication method is a command and response type (a command is sent from the PC to the MX100 and a response is returned from the MX100 to the PC). Only a single PC can connect to a single MX100.
  • Page 82 Output Ethernet statistical information Function Outputs statistical information of the packets that flowed through the MX100 interface (lo0: loopback device, lan0: network device). The output value is a summed value after the MX100 is powered up. Setting Example 03/01/01 00:02:45.490 Ethernet Statistics...
  • Page 83 Output other network information Function Outputs settings and statistical information (APP, TCP, and DLC) specific to the MX100. The output value is a value at the time the MX100 is powered up or a summed value after the MX100 is powered up. Setting Example 03/01/01 00:02:45.490...
  • Page 84 3.5 MX100 Maintenance and Test Using Communication Commands Description Outputs settings and statistical information specific to the MX100 in a form enclosed by EA and EN. APP: applalive: APP keepalive check cycle. TCP: keepalive: TCP keepalive check cycle. TCP: connects: Total number of connections established.

  • Page 85: Common Specifications

    Indicates the degree of adherence by a solid, liquid, or vapor that reduces the withstand voltage or surface resistance (applies only to normal indoor atmospheres (with non-conductive pollution). Measurement category II: Applies to electrical instruments that are powered by wall outlets and other fixed installations that are wired to distribution boards, or measurements of such wires. IM MX100-01E...

  • Page 86: Main Module Specifications

    Difference computation between arbitrary channels (DC voltage, TC, RTD, DI, strain, resistance, and scaling) Linear scaling: Possible scaling ranges: DC voltage, TC, RTD, DI, strain, and resistance Scaling range: -30000 to 30000 Scaling display range: -32000 to 32000 Decimal point position: Arbitrary IM MX100-01E...
  • Page 87 (subdirectories are not applicable). The data that is deleted is not necessarily a MX100 file. If free space cannot be secured or when securing of free space takes extended time, an error is indicated on the 7-segment LED.
  • Page 88 Timeout time: Initial value 60 s (settings can be changed using the MXLOGGER or MX100/DARWIN API (sold separately)). To save the data so that no dropouts occur, the timeout time* must be set appropriately.If the setting is inappropriate, an error is indicated on the 7-segment LED, and data storage is not performed.
  • Page 89 6 days 12.5 days 25 days 50 days Display LED: Ethernet communication status (LINK, ACT) Two-digit 7-segment LED: Status of the MX100 Data Acquisition Unit (unit number, operation status, and error indication) Communications Interface: Ethernet (10BASE-T/100BASE-TX) Connector type: RJ-45 Protocol:...
  • Page 90 1500 VAC (50/60 Hz) for one minute between the power supply terminal and earth terminal External dimensions: Approximately 92 (W) × 131 (H) × 137 (D) mm Weight: Approximately 0.85 kg External Dimensions Unit: mm 136.7 If not specified, the tolerance is ±3%. However, in cases of less than 10 mm, the tolerance is ±0.3 mm. IM MX100-01E...

  • Page 91: Base Plate Specifications

    External Dimensions Unit: mm MX150-1, -2, -3, -4, -5, -6 Index 407.5 (1 main module, for connecting six input/output modules) 58 pitches in between 117.5 (1 main module, for connecting one input/output module) 22.5 34.6 If not specified, the tolerance is ±3%. However, in cases of less than 10 mm, the tolerance is ±0.3 mm. IM MX100-01E...

  • Page 92: Ch, High-Speed Universal Input Module Specifications

    8 Guaranteed accuracy range Cu10 GE: -84.4 to 170.0°C/Cu10 L&N: -75.0 to 150.0°C/Cu10 WEED: -20.0 to 250.0°C/ Cu10 BAILEY: -20.0 to 250.0°C 9 Measured using a measurement current of approximately 1 mA at 1-V range. Threshold level is approximately 0.8 V. IM MX100-01E...
  • Page 93 4.4 4-CH, High-Speed Universal Input Module Specifications The inputs indicated below can be used on MXLOGGER or the MX100/DARWIN API (software sold separately). Measurement Accuracy Measurement Highest Rated Measurement Accuracy Range Integration Time: 16.67 ms Input Measurement Resolution Integration Time: 1.67 ms...
  • Page 94 External dimensions: Approximately 57 (W) × 131 (H) × 151 (D) mm (including the terminal cover) Weight: Approximately 0.5 kg Terminal type: Clamp, detachable on each channel Applicable wire size: 0.2 to 2.5 mm (AWG24 to 12) 4-10 IM MX100-01E...
  • Page 95 Effects of vibration: The fluctuation that results by applying a sinusoidal vibration along all three axis at a frequency between 10 to 60 Hz and an acceleration of 0.2 m/s is ±(0.1% of rdg + 1 digit) or less External Dimensions Unit: mm 150.8 If not specified, the tolerance is ±3%. However, in cases of less than 10 mm, the tolerance is ±0.3 mm. 4-11 IM MX100-01E...

  • Page 96: Ch, Medium-Speed Universal Input Module Specifications

    Guaranteed accuracy range Cu10 GE: -84.4 to 170.0°C/Cu10 L&N: -75.0 to 150.0°C/Cu10 WEED: -20.0 to 250.0°C/ Cu10 BAILEY: -20.0 to 250.0°C Measured using a measurement current of approximately 10 µA at 200-mV range. The threshold level is 0.1 V. 4-12 IM MX100-01E...
  • Page 97 4.5 10-CH, Medium-Speed Universal Input Module Specifications The inputs indicated below can be used on MXLOGGER or the MX100/DARWIN API (software sold separately). Measurement Measurement Accuracy Rated Highest Measurement Accuracy Integration Time: 16.67 ms Range Input Measurement Resolution Integration Time: 1.667 ms...
  • Page 98 External dimensions: Approximately 57 (W) × 131 (H) × 151 (D) mm (including the terminal cover) Weight: Approximately 0.5 kg Terminal type: Clamp, terminal board is detachable Applicable wire size: 0.14 to 1.5 mm (AWG26 to 16) 4-14 IM MX100-01E...
  • Page 99 Horizontal with the feet at the bottom is the rule. Effects of vibration: The fluctuation that results by applying a sinusoidal vibration along all three axis at a frequency between 10 to 60 Hz and an acceleration of 0.2 m/s is ±(0.1% of rdg + 1 digit) or less External Dimensions Unit: mm 150.8 If not specified, the tolerance is ±3%. However, in cases of less than 10 mm, the tolerance is ±0.3 mm. 4-15 IM MX100-01E...

  • Page 100: Ch, Medium-Speed 4-Wire Rtd Resistance Input Module Specifications

    5 Measured using a measurement current of approximately 10 µA at 200 V range. Threshold level is approximately 0.1 V. 6. The Pt500 resistance table is Pt100 × 5, and the resistance table for Pt1000 is Pt100 × 10. 7. 4-wire RTD, 4-wire resistance 4-16 IM MX100-01E...
  • Page 101 4.6 6-CH, Medium-Speed 4-Wire RTD Resistance Input Module Specifications The inputs indicated below can be used on MXLOGGER or the MX100/DARWIN API (software sold separately). Measurement Measurement Accuracy Rated Highest Measurement Accuracy Integration Time: 16.67 ms Range Resolution Input Measurement Integration Time: 1.67 ms...
  • Page 102 Horizontal with the feet at the bottom is the rule. Effects of vibration: The fluctuation that results by applying a sinusoidal vibration along all three axis at a frequency between 10 to 60 Hz and an acceleration of 0.2 m/s is ±(0.1% of rdg + 1 digit) or less External Dimensions Unit: mm 150.8 If not specified, the tolerance is ±3%. However, in cases of less than 10 mm, the tolerance is ±0.3 mm. 4-18 IM MX100-01E...

  • Page 103: Ch, Medium-Speed Strain Input Module Specifications

    Fixed at 2.0. Gauge factor can be compensated with the scaling function. Balance adjustment: Automatic, digital calculation methods Balance adjustment range: ±10000 µstrain (1-gauge method conversion) Balance adjustment accuracy: The measurement accuracy or less: Resistance accuracy for bridge: ±0.01% ±5ppm/°C Input resistance: 1 MΩ or more Allowable wiring resistance: 100 Ω or less Effect of wiring resistance: NDIS 50 ppm of rdg/Ω (when using remote sensing wire). Does not compensate for clamp wiring resistance. Depends on the gauge resistance. 4-19 IM MX100-01E...
  • Page 104 90 to 132 V and 180 to 250 V Effects of magnetic field: The fluctuation in external magnetic fields for AC (50/60 Hz) 400 A/m is ±2% or range or less Effect of position: Horizontal with the feet at the bottom is the rule. External Dimensions Unit: mm -B12, -B35 -NDI 150.8 133.8 If not specified, the tolerance is ±3%. However, in cases of less than 10 mm, the tolerance is ±0.3 mm. 4-20 IM MX100-01E...

  • Page 105: Ch, High-Speed Digital Input Module Specifications

    Applicable wire size: 0.14 to 1.5 mm (AWG26 to 16) External dimensions: Approx. 57 (W) × 131 (H) × 151 (D) mm (including the terminal cover) Weight: Approximately 0.5 kg External Dimensions Unit: mm 150.8 If not specified, the tolerance is ±3%. However, in cases of less than 10 mm, the tolerance is ±0.3 mm. 4-21 IM MX100-01E...

  • Page 106: Ch, Medium-Speed Analog Output Module Specifications

    Applicable wire size: 0.08 to 2.5 mm (AWG28 to 12) External dimensions: Approx. 57 (W) × 131 (H) × 151 (D) mm (including the terminal cover) Weight: Approximately 0.5 kg External Dimensions Unit: mm 150.8 If not specified, the tolerance is ±3%. However, in cases of less than 10 mm, the tolerance is ±0.3 mm. 4-22 IM MX100-01E...
  • Page 107 - 10000 10000 * PC data refers to internal data between the PC and MX100 main unit, and on the PC software, the output value is expressed in the same manner with 3 digits after the decimal point. mA mode Output voltage [mA] 0.000...

  • Page 108: Ch, Medium-Speed Pwm Output Module Specificaions

    Clamp, attached and removed in units of 4 channels Applicable wire size: 0.08 to 2.5 mm (AWG28 to 12) External dimensions: Approx. 57 (W) × 131 (H) × 151 (D) mm (including the terminal cover) Weight: Approximately 0.5 kg 4-24 IM MX100-01E...
  • Page 109 50.000 100.000 PC data* 50000 100000 PC data refers to internal data between the PC and the MX100 main unit. Handling Abnormal Data Types of Abnormal Data Output Values Abnormal data upon startup Preset value or previously held value can be selected...
  • Page 110 Command Output Setting Value by Pulse Interval When the pulse interval is 10 ms Pulse interval PC setting value 10 ms 20 ms 300.00 s 30000 When the pulse interval is 1 ms Pulse interval PC setting value 30.000 s 30000 4-26 IM MX100-01E...

  • Page 111: Medium Speed Pwm Output Module

    Overview of Output Operation When Setting Holding of Previous Value of Transmission Output Previous value (held) Value held Output value Power ON Measurement Measurement Measurement stop restarts start (or Transmission output (or Transmission output execute disabled) execute enabled) 4-27 IM MX100-01E...

  • Page 112: Ch, Medium-Speed Digital Output Module Specifications

    Applicable wire size: 0.08 to 2.5 mm (AWG28 to 12) External dimensions: Approx. 57 (W) × 131 (H) × 151 (D) mm (including the terminal cover) Weight: Approximately 0.5 kg External Dimensions Unit: mm 150.8 If not specified, the tolerance is ±3%. However, in cases of less than 10 mm, the tolerance is ±0.3 mm. 4-28 IM MX100-01E...

  • Page 113: Overview Of Functions

    Output of data to the PC via communications and saving of data to the CF card in the MX100 main unit can be carried out simultaneously. Saving of data to the CF card is linked with record start/stop commands from the PC. By combining commands for data acquisition on the PC and saving of data to the CF card, it is possible to save measured data to the PC and the CF card at the same time (the Dual Save function).

  • Page 114: Dip Switch Settings

    Dip Switch Settings To enable the /DS option functions, make sure the MX100 main unit is OFF, then set the following dip switch settings. SW1 to 4: ON SW5 to 8: OFF Unless the dip switches are set as shown, the /DS option functions are unavailable, and the instrument operates using the standard functions.

  • Page 115: Explanation Of Functions

    Explanation of Functions The software programs referred to in this chapter are the MX100 Standard Software and MXLOGGER (sold separately). In the explanatory figures provided, Idle, Measure, and Backup refer to idling mode, measurement mode, and backup mode respectively, and AlarmDO refers to alarm output (see page 1-7).
  • Page 116 CF card not inserted AlarmDO 5s-SW Idle Measrue 5s-SW Immediately CF card inserted AlarmDO AlarmDO 5s-SW (after 1 s) Idle Measrue Backup 5s-SW If measurement fails to start, [ ] appears on the 7-segment LED for one second. IM MX100-01E...
  • Page 117 • Operation When Power Cut and PC Software Connected Connect to PC software Auto restore Mode Measure Measure Measure Idle Record Stop Start (Start) Power On 5s-SW Power Off On Data Data AlarmDO AlarmDO Update Update Update Hold PC File Save on PC IM MX100-01E...
  • Page 118 FileNo.=0 FileNo.=1 FileNo.=2 Info Start Abnormality New file New file • When Operating the Access Stop Switch (CF-SW) Backup Measure Mode Idle Measure 5s-SW CF -SW 5s-SW 5s-SW Data (60s) CF Write CF File lost FileNo.=0 Start Info IM MX100-01E...
  • Page 119 Connect to PC software Backup Backup Mode Measure Measure Record Record 5s-SW Stop Start (Start) (Stop) Data (60s) CF Write Save on CF CF File File.No=0 File.No=1 FileNo.=0 Start New fie Start Info Save on PC PC File IM MX100-01E...
  • Page 120 Simultaneous Output of Measured Data via Communications and Saving to CF Card Output of data to the PC and saving of data to the CF card in the MX100 main unit can be carried out simultaneously. Saving of data to the CF card occurs according to record start/stop command (Backup command) from the PC.
  • Page 121 Recording operation Index starts stops Note When using the MX100 Standard Software, the data saved to the PC and CF card depends on the following. Setting Screen and Items Data saved to PC Data saved to the CF Card Save interval [Log.
  • Page 122 (Backup ON/OFF). Saving of data to the CF card can be linked with the Start/Stop function. Note The file number of a data file saved to the CF card using an MX100/DARWIN API application is the consecutive number assigned during use of the API application. Dual Save Function If the dual save function is used, command output of digital output, analog output, and PWM output may experience delay when data is being saved to the CF card.

  • Page 123: Cf Card Data File

    Meas. interval number 0 to 2 XXXX: Sequence number (incremented by 1 each time new file created) 0000-9999 MXD: Extension (uppercase characters) specific to the MX100 Index The month and date of backup start is used during normal functioning (see page 4-4). File Name...
  • Page 124 ............... 1-8 alarm value hysteresis ............1-8 file name ................5-11 API for the MX100/DARWIN ........... vii file structure and saved channels ........1-10 attaching the modules ............2-3 filter ......... 1-7, 1-14, 1-16, 1-18, 1-19, 1-23 attachment procedure............
  • Page 125 ..................iv specifications module errors ............... 3-2 10-CH, High-Speed Digital Input Module ..... 4-21 MX100 Operation and Status Relative to CF Card 10-CH, Medium-Speed Digital Output Module ..... 4-28 Operation ................1-11 10-CH, Medium-Speed Universal Input Module ... 4-12 MX100 Standard Software ..........
  • Page 126 Digital Input Modules ............ 2-14 Digital Output Modules ..........2-16 PWM Output Modules ..........2-15 Strain Input Modules ............. 2-11 Universal Input Modules ..........2-10 wiring procedure ..............2-10 wiring the universal input modules ........2-10 Index Index-3 IM MX100-01E...

This manual is also suitable for:

Mx115Mx125Mx112Mx150Mx120

Table of Contents
