- Page 1 HUAWEI E510 HSPA/DVB-T USB Modem Quick Start...
- Page 2 No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. Trademarks and Permissions and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd. All other trademarks and trade names mentioned in this document are the property of their respective holders.
- Page 3 Table of Contents Getting to Know the E510....................1 Requirements for the PC..................... 4 Preparing the E510......................5 Installation Guide ....................... 7 Safety Information......................9...
-
Page 4: Getting To Know The E510
Huawei E510 HSPA/DVB-T USB Modem (hereinafter referred to as the E510). You are recommended to read the manual before using the E510. Getting to Know the E510 The following figures show the appearance of the E510. The actual product may differ. - Page 5 Internal Antenna You can pull out the internal antenna as shown in the following figure. To receive stronger signals, you can adjust the direction of the internal antenna. Mini-USB interface You can connect the mini-USB connector of the USB extension cable to the mini-USB interface. USIM/SIM card slot Holds the USIM/SIM card.
- Page 6 The internal and the external antennas cannot be used at the same time. When the external antenna is connected to the E510, you are not recommended to pull out the internal antenna. It is recommended to use the external antenna at the site with weak signals.
-
Page 7: Requirements For The Pc
Indicates the status of the E510. Green, blinking twice every 3s: The E510 is powered on. Green, blinking once every 3s: The E510 is registered to the GSM/GPRS/EDGE network. Blue, blinking once every 3s: The E510 is registered to the WCDMA/HSDPA/HSUPA network. -
Page 8: Preparing The E510
Insert the USIM/SIM card into the card slot. Make sure that the USIM/SIM card is properly inserted. Connecting the E510 with a PC Note: Power on your PC before connecting the E510 with the PC. Otherwise, the normal installation of the E510 may be affected. - Page 9 Auxiliary USB power cable Main-USB extension cable Mini-USB connector Connect the Mini-USB connector to the E510. Connect the USB connector(s) to the USB interface(s) of the PC. Note: When you enjoy the data service and the TV service simultaneously, connect the USB...
-
Page 10: Installation Guide
Launching the Management Program After the E510 is installed, the management program is launched automatically. Then every time the E510 is connected to the PC, the management program is launched automatically. You can also double-click the shortcut icon on the desktop to launch the management program. -
Page 11: Removing The E
The Unplug or Eject Hardware interface is displayed. Select the hardware related to the E510 and click Stop. When the prompt "It is safe to remove the device" is displayed, remove the E510. Note: Before removing the E510, exit the management program. -
Page 12: Safety Information
Safety Information Read the safety information carefully to ensure the correct and safe use of your wireless device. Interference Do not use your wireless device if using the device is prohibited or when it causes danger or interference with electric devices. Medical Device Do not use your wireless device and follow the rules and regulations set forth by the hospitals and health care facilities. -
Page 13: Weee Approval
Area indicated with the "Power off bi-direction wireless equipment" sign Area where you are generally suggested to stop the engine of a vehicle Traffic Security Observe local laws and regulations while using the wireless device. To prevent accidents, do not use your wireless device while driving. RF signals may affect electronic systems of motor vehicles. -
Page 14: Rohs Approval
RoHS Approval The wireless device is in compliance with the restriction of the use of certain hazardous substances in electrical and electronic equipment Directive 2002/95/EC (RoHS Directive). Laws and Regulations Observance Observe laws and regulations when using your wireless device. Respect the privacy and legal rights of the others. -
Page 15: Body Worn Operation
Federal Communication Commission Interference Statement Specific Absorption Rate (SAR) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide Your wireless device is a radio transmitter and receiver. - Page 16 Huawei Technologies Co., Ltd. Huawei Industrial Base, Bantian, Longgang Shenzhen 518129 People's Republic of China Website: www.huawei.com...
