Battery Maintenance - Skyjack SJIII 3219 Operating Manual

Section 3 - Operation

3.13 Battery Maintenance

This section provides the operator with procedures on
how to service and charge the battery. This also provides
charger operation instructions.
3.13-1 Battery Service Procedures
WARNING
Explosion Hazard - Keep flames and
sparks away. Do not smoke near
batteries.
WARNING
Battery acid is extremely corrosive - Wear
proper eye and facial protection as well as
appropriate protective clothing. If contact
occurs, immediately flush with cold water
and seek medical attention.
1. Turn main power disconnect switch to "
position.
2. Check battery case for damage.
3. Check battery fluid level in each battery. If plates
are not covered by at least 13 mm of solution, add
distilled or demineralized water.
4. Clean battery terminals and cable ends thoroughly
with a terminal cleaning tool or wire brush.
5. Make sure all battery connections are tight.
6. Replace any battery that is damaged or incapable
of holding a lasting charge.
7. Do not use any batteries other than flooded lead-
acid batteries of the proper AH rating.
WARNING
Use original or equivalent to the original
parts and components for the MEWP .
SJIII DC Electric
3.13-2 Battery Charging Operation
1.
" off
2.
December 2007
Figure 3-17. Battery Charger
DANGER
Risk of electric shock - Do not immerse
the charger in water. Though the charger
is highly resistant to water, it is not
designed for immersion and an electric
shock can occur.
Provide adequate ventilation for the batteries and
charger. The convection cooled design requires
access to cooling air for proper operation. Do
not allow blankets or other materials to cover
the charger. Although the charger protects itself
against overheating, the charger cooling fins
should be cleaned if clogged with debris for best
performance.
WARNING
There could be a spark during charging.
Be careful when using fuels, solvents or
other flammables near the charger or
batteries.
Connect the power supply cord to a properly
grounded 100V/50 or 60Hz, 115V/50 or 60Hz, or
230V/50 or 60Hz socket. This charger automatically
senses and adjusts to the AC input voltage
range.
