Skyjack SJIII 3219 Operating Manual

Dc electric scissors
Hide thumbs Also See for SJIII 3219:
Table of Contents

Advertisement

Quick Links

See also: Service Manual , Operating Manual
OPERATING MANUAL (AS)
DC ELECTRIC SCISSORS
MODELS
SJIII 3215 SJIII 3219 SJIII 3220 SJIII 3226 SJIII 4626 SJIII 4632
158002AG-A February 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SJIII 3219 and is the answer not in the manual?

Questions and answers

Related Manuals for Skyjack SJIII 3219

Summary of Contents for Skyjack SJIII 3219

  • Page 1 OPERATING MANUAL (AS) DC ELECTRIC SCISSORS MODELS SJIII 3215 SJIII 3219 SJIII 3220 SJIII 3226 SJIII 4626 SJIII 4632 158002AG-A February 2014...
  • Page 2 This manual is based on Serial Number(s): SJIII 3215 10 000 839 - 10 000 995 SJIII 3219 22 032 963, 22 032 964, 22 035 881, 22 037 437 - 22 057 771 SJIII 3220 60 003 131 - 60 004 188...
  • Page 3 The Safety Alert Symbol identifies important safety messages on MEWP , safety signs in This Safety Alert Symbol means attention! manuals or elsewhere. When you see this symbol, be alert to the possibility of personal Become alert! Your safety is involved. injury or death.
  • Page 4 Table of Contents Section 1 - About Your Mobile elevating work platform (MEWP) ............5 Read and Heed ..............................5 Safety Rules ................................6 Section 2 - Familiarization ........................11 Familiarization of SJIII Series ......................11 Component Identification ........................12 Visual & Daily Maintenance Inspections ..................16 Function Tests ..........................23 Winching and Towing Procedures ....................31 Emergency Lowering Procedure .....................33...

  • Page 5: Read And Heed

    SKYJACK warrants each new SJIII Series work platform to be free of defective parts and workmanship for the first 24 months. Any defective part will be replaced or repaired by your local SKYJACK dealer at no charge for parts or labor.

  • Page 6: Safety Rules

    Common sense dictates the use of protective clothing when working on or near machinery. Use appropriate safety devices to protect your eyes, ears, hands, feet and body. Any modifications from the original design are strictly forbidden without written permission from SKYJACK. Electrocution Hazard This MEWP is not electrically insulated.
  • Page 7 Section 1 - About Your Aerial Platform Safety Rules Safety Precautions Know and understand the safety precautions before going on to next section. WARNING • DO NOT increase the lateral Failure to heed the following safety surface area of the platform. precautions could result in tip over, Increasing the area exposed falling, crushing, or other hazards leading...
  • Page 8 Safety Rules Section 1 - About Your Aerial Platform Safety Precautions (Continued) Know and understand the safety precautions before going on to next section. • DO NOT operate on surfaces not capable of • AVOID crushing hazards. Be holding the weight of the MEWP including the aware of crushing hazards rated load, e.g.
  • Page 9 Skyjack. WARNING Entering and exiting the MEWP should only be done using the three points of contact.
  • Page 10 Notes SJIII DC Electric Page 10 December 2007...

  • Page 11: Section 2 - Familiarization

    Section 2- Familiarization SJIII Series 2.1 Familiarization of SJIII Series WARNING MEWP Familiarization should be given only to individuals who are COMPETENT And TRAINED to operate a MEWP . Do not operate this MEWP without proper authorization and training. Failure to avoid this hazard could result in death or serious injury.

  • Page 12: Component Identification

    Control Functions Section 2 - Familiarization 2.2 Component Identification 2.2-4 Load Sensing System This system is a safety device that will prevent any The following descriptions are for identification, normal movement of the MEWP from a stationary explanation and locating purposes only. working position after the rated load is reached and 2.2-1 Main Power Disconnect Switch exceeded.
  • Page 13 Section 2 - Familiarization Control Functions 2.2-5 Base Control Console 2.2-6 Disc Brake System This control console is located at the rear of the base. The brake system is located at the rear of the base. The It contains the following controls: brakes must be manually disengaged before pushing, winching or towing.
  • Page 14 Control Functions Section 2 - Familiarization 2.2-7 Free-wheeling Valve 2.2-8 Emergency Lowering System This emergency lowering system allows platform lowering in the event of an emergency or an electrical system failure. Refer to Section 2.6 for the emergency lowering procedure. The system contains the following controls: Models 3220, 3226 and 46xx Figure 2-5.
  • Page 15 ” lift position energizes the lift circuit. Selecting “ ” drive position energizes the drive circuit. WARNING Skyjack scissor lifts are to be operated from the operator’s position on the Figure 2-6. Platform Control Console platform with the control box secured on with Toggle Switch the mounting bracket at the front right portion of the platform.

  • Page 16: Visual & Daily Maintenance Inspections

    Visual & Maintenance Inspection Section 2 - Familiarization High Speed Limit Switch High Speed Limit Switch Pothole Protection Limit Switch COMPACTS CONVENTIONALS 2.3 Visual & Daily Maintenance 2.3-1 Labels Refer to Section 5 - Labels in this manual and determine Inspections that all labels are in place and are legible.
  • Page 17 Section 2 - Familiarization Visual & Maintenance Inspection SJIII 3220, 3226 & 46xx SJIII 3215 & 3219 Free-wheeling (Back View) 220V Outlet Valve Receptacle CAUTION 106515AC Main Power Base Control Disconnect Console Ladder Switch Free-wheeling Valve SJIII 3215 & 3219 (Back View) 2.3-5 Entrance Side • 220V Outlet Receptacle...
  • Page 18 Visual & Maintenance Inspection Section 2 - Familiarization SJIII 3220, 3226 & 46xx SJIII 3215 & 3219 Battery Battery Charger Battery Charger Hydraulic/Electric Battery Fuse Box Battery Tray Battery Tray Pothole Protection Device Tray 2.3-6 Battery Tray Side WARNING Battery acid is extremely corrosive - • Pothole Protection Device Wear proper eye and facial protection as Ensure mechanisms have no sign of...
  • Page 19 • Wheel/Tire Assembly can adversely affect stability. Therefore, The MEWP is either equipped with solid replace tires only with the exact Skyjack- rubber tires or foam-filled tires. Tire and/or approved type. Failure to operate wheel failure could result in an MEWP tip- with matched approved tires in good over.
  • Page 20 Visual & Maintenance Inspection Section 2 - Familiarization SJIII 3215 & 3219 Emergency Lowering Greasing Point Access Rod Electrical Panel Load/Tilt Sensor Hydraulic/Electric Tray Main Manifold Greasing Point Hydraulic Pump and Motor Hydraulic Tank 2.3-7 Hydraulic/Electric Tray Side • Proportional and Main Manifolds Ensure tray latch is secure and in proper Ensure all fittings and hoses are properly working order.
  • Page 21 Section 2 - Familiarization Visual & Maintenance Inspection Platform Control Console Platform Railing Manual Storage Platform Assembly 2.3-8 Platform Assembly • Platform Control Console Ensure all switches and controller are returned to neutral and are properly WARNING secured. Ensure that you maintain three points Ensure there are no loose or missing of contact to mount/dismount platform.
  • Page 22 Visual & Maintenance Inspection Section 2 - Familiarization Powered Extension Control Console Maintenance Support Lift Cylinder Scissor Bumper Scissor Assembly Roller • Powered Extension Control Console • Scissor Bumpers (If Equipped) Ensure bumpers are secure and show no Ensure all switches are returned to sign of visible damage.

  • Page 23: Function Tests

    Section 2 - Familiarization Function Tests SJIII 3220, 3226 & 46xx SJIII 3215 & 3219 (Back View) (Back View) Free-wheeling Valve Lower/ Lower/ Neutral/Raise Neutral/Raise Switch Switch CAUTION 106515AC Emergency Stop Emergency Stop Off/Platform/Base Switch Button Button 2.4 Function Tests 2.4-2 Base Control Console Function tests are designed to discover any malfunctions before MEWP is put into service.
  • Page 24 Function Tests Section 2 - Familiarization SJIII 3220, 3226 & 46xx SJIII 3215 & 3219 (Back View) (Back View) Free-wheeling Valve Lower/ Lower/ Neutral/Raise Neutral/Raise Switch Switch CAUTION 106515AC Emergency Stop Emergency Stop Off/Platform/Base Switch Button Button • Test Base Emergency Stop 2.
  • Page 25 Section 2 - Familiarization Function Tests SJIII 3220, 3226 & 46xx SJIII 3215 & 3219 (Back View) (Back View) Free-wheeling Valve Lower/ Lower/ Neutral/Raise Neutral/Raise Switch Switch CAUTION 106515AC Emergency Stop Emergency Stop Off/Platform/Base Switch Button Button • Test Emergency Lowering • Test Free-wheeling 1.
  • Page 26 Function Tests Section 2 - Familiarization Platform Control Console Rocker Switch Controller Lift/Drive/Steer Enable Trigger Switch Inclined Drive/Level Drive Switch Emergency Stop Button/ Operation Light Lift/Off/Drive Switch Horn Pushbutton 2.4-3 Platform Control Console Result: All selected platform functions should not operate. 1.
  • Page 27 Section 2 - Familiarization Function Tests Platform Control Console Rocker Switch Controller Lift/Drive/Steer Enable Trigger Switch Inclined Drive/Level Drive Switch Emergency Stop Button/ Operation Light Lift/Off/Drive Switch Horn Pushbutton • Test Driving 1. Ensure path of intended motion is clear. 2.
  • Page 28 Function Tests Section 2 - Familiarization Platform Control Console Rocker Switch Controller Lift/Drive/Steer Enable Trigger Switch Inclined Drive/Level Drive Switch Emergency Stop Button/ Operation Light Lift/Off/Drive Switch Horn Pushbutton • Test Platform Raising/Lowering • Test Horn 1. Push “ ” horn pushbutton. WARNING Result: Horn should sound.
  • Page 29 Section 2 - Familiarization Function Tests Platform Control Console Rocker Switch Controller Lift/Drive/Steer Enable Trigger Switch Inclined Drive/Level Drive Switch Emergency Stop Button/ Operation Light Lift/Off/Drive Switch Horn Pushbutton • Test Elevated Drive Speed • Test Lowering Alarm WARNING WARNING Be aware of overhead obstructions Be aware of overhead obstructions or other possible hazards around the...
  • Page 30 Function Tests Section 2 - Familiarization Platform Control Console Rocker Switch Controller Lift/Drive/Steer Enable Trigger Switch Inclined Drive/Level Drive Switch Emergency Stop Button/ Operation Light Lift/Off/Drive Switch Horn Pushbutton • Test Load Sensing Activate and hold “ ” enable trigger switch. WARNING Pull controller handle and attempt Be aware of overhead obstructions...

  • Page 31: Winching And Towing Procedures

    Section 2 - Familiarization Procedures 2.5 Winching and Towing Procedures 2.5-1 To Release Free-wheeling Valve This section provides the operator with the Winching Ensure MEWP is on level ground. Chock or block and Towing procedure, which includes instructions on the wheels to keep MEWP from rolling. how to manually release the brakes.
  • Page 32 Procedures Section 2 - Familiarization 2.5-2 To Release Brakes Manually Remove wheel chocks or blocks, then push, winch or tow MEWP to desired location. WARNING WARNING Do not manually disengage brakes if the MEWP is on a slope. Brakes must be reengaged immediately after reaching the desired location.

  • Page 33: Emergency Lowering Procedure

    Section 2 - Familiarization Procedures 2.6 Emergency Lowering Procedure This section guides the operator on how to use the emergency lowering system. This system allows platform lowering in the event of an emergency or an electrical system failure. WARNING Keep clear of scissors mechanism when using emergency lowering valve.
  • Page 34 Notes SJIII DC Electric Page 34 December 2007...

  • Page 35: Section 3 - Operation

    Section 3 - Operation General 3.0 Operation • The operator must be sure that the MEWP has This section provides the necessary information needed been properly maintained and inspected before to operate the MEWP . It is important that the user reads using it.

  • Page 36: Major Components

    Major Components Section 3 - Operation 3.2 Major Components Platform Control Console Manual Storage Main Platform Extension Platform Maintenance Support Lifting Mechanism Base Battery Tray Hydraulic/Electric Tray Pothole Protection Device SKYJACK SJIII Series MEWP SJIII DC Electric Page 36 December 2007...

  • Page 37: Major Assemblies

    Section 3 - Operation Major Assemblies 3.3 Major Assemblies 3.4 Serial Number Nameplate The MEWP consists of three major assemblies: base, The serial number nameplate, located at the rear of the lifting mechanism and platform. MEWP , lists the following: 3.3-1 Base • Model number The base is a rigid, one-piece weldment which supports...

  • Page 38: Component Identification

    Component Identification Section 3 - Operation 3.5 Component Identification 3.5-3 Pothole Protection Device The following descriptions are for identification, explanation and locating purposes only. 3.5-1 Electrical Panel This panel is located in the hydraulic/electric tray. It contains the following controls: Figure 3-3.
  • Page 39 Section 3 - Operation Component Identification Maintenance of the Pothole Maintenance Support - The maintenance support Protection Device is a safety mechanism designed to support the scissor assembly. When properly positioned it As with all safety devices, periodic inspection can support the scissor assembly and empty and maintenance is required to ensure the platform.
  • Page 40 Component Identification Section 3 - Operation 3.5-5 Manual Storage Box 3.5-7 Lanyard Attachment Anchorage This weather-resistant box is mounted on the platform railings. It contains the operating manual, Certificate of Plant Design Registration 123628AE and other important documents. The operating manual for this make and model of MEWP must be stored in this box.

  • Page 41: Component Identification (Optional Equipment/Attachments)

    WARNING raised to access it. Skyjack scissor lifts are to be operated from the operator’s position on the platform with the control box secured on the mounting bracket at the front right portion of the platform.
  • Page 42 Component Identification (Special Options) Section 3 - Operation Ensure there are no personnel in the intended path of travel. WARNING • Ensure the operator and control box Notify those around the pathway that you will be console are properly oriented in the moving the MEWP .

  • Page 43: Operator's Responsibility

    Section 3 - Operation Operator’s Responsibility 3.7 Operator’s Responsibility Repairs to the MEWP may only be made by a competent service technician. After repairs are completed, the It is the responsibility of the operator, prior to each work operator must perform visual and daily maintenance shift, to perform the following: inspections &...

  • Page 44: Start Operation

    Start Operation Section 3 - Operation 3.8 Start Operation 3.8-1 To Activate Base Control Console Carefully read and completely understand the operating manual and all warnings and instruction labels (refer to WARNING Section 5 - Labels) on the MEWP . Ensure that you maintain three points of contact when using the ladder to mount/ WARNING...
  • Page 45 Section 3 - Operation Start Operation 3.8-3 To Activate Platform Control Console Select lift/off/drive switch to “ ” lift position. Turn main power disconnect switch to “ ” on position. Activate and hold “ ” enable trigger switch. Move controller handle forward or backward until On base control console, pull out “...
  • Page 46 Start Operation Section 3 - Operation 3.8-5 To Drive Forward or Backward 3.8-6 To Steer Activate platform control console (refer to WARNING Section 3.8-3). Be aware of blind spots when operating the MEWP . Select lift/off/drive switch to “ ” drive position. WARNING Activate and hold “...
  • Page 47 Section 3 - Operation Start Operation 3.8-7 To Select Level Drive or Inclined Drive 3.8-8 To Extend/Retract Manual Extension Mode Platform Level Drive Mode DANGER Select level drive mode when traveling on flat Crushing Hazard - Extension platform surface. must not be retracted manually from the ground.
  • Page 48 Start Operation Section 3 - Operation 3.8-9 To Extend/Retract Powered Extension 3.8-10 Electrical Inverter (If Equipped) Platform (If Equipped) Turn main power disconnect switch to “ ” on To extend/retract powered extension platform, position. ensure “ ” emergency stop button is pulled out.

  • Page 49: Guardrail Folding Procedure

    Section 3 - Operation Guardrail Folding Procedure 3.9 Guardrail Folding Procedure To fold the guardrail system down: When folded down, the folding guardrail system reduces the height of the retracted MEWP for transporting only. Ensure MEWP is on level ground. WARNING Ensure extension platform is fully retracted.
  • Page 50 Guardrail Folding Procedure Section 3 - Operation Remove remaining pins from all sides and carefully fold all guardrails in the following order: SJIII 32xx • Entrance Fold entrance bar to the left side and lock into place. Ensure that the detent ball of the pin is all the way through (Refer to Figure 3-12c).
  • Page 51 Section 3 - Operation Guardrail Folding Procedure To raise the guardrail system up: Ensure MEWP is on level ground. Ensure extension platform is fully retracted. Ensure Emergency Stop button is depressed. Turn main power disconnect switch to “ ” off position.

  • Page 52: Loading/Unloading

    Loading/Unloading Section 3 - Operation 3.10 Loading/Unloading 3.10-1 Lifting Know and heed all national, state or territorial/provincial and local rules which apply to your loading/unloading WARNING of MEWP . Only competent rigger shall operate machinery during lifting. Only competent personnel shall operate the MEWP during loading/unloading.
  • Page 53 • MEWP brake must be checked for proper The MEWP can be lifted with a forklift from operation. the sides but Skyjack does not recommend • MEWP speed should be on high torque setting. this use. Lift with forks in designated...

  • Page 54: Moving The Mewp Through A Doorway

    Moving the Aerial Platform Through a Doorway Section 3 - Operation 3.11 Moving the MEWP Through a NOTE On models 3215 and 3219, the connection Doorway is located beneath an access panel which requires that the scissor assembly be WARNING raised to access it.
  • Page 55 Section 3 - Operation Moving the Aerial Platform Through a Doorway WARNING Ensure that you maintain three points of contact when using the ladder to mount/ dismount platform. Return guardrails to upright position if folded. Refer Section 3.9 for guardrail folding procedure. WARNING Before operating this MEWP check the guardrail system for loose or missing...

  • Page 56: Maintenance Support Procedure

    Maintenance Support Procedure Section 3 - Operation 3.12 Maintenance Support Procedure To Store the Maintenance Support This section provides the operator with procedure regarding deployment and storage of maintenance Turn main power disconnect switch to “ ” on support. position. The maintenance support is a safety mechanism Raise platform until there is adequate clearance designed to support the scissor assembly.

  • Page 57: Battery Maintenance

    Section 3 - Operation Battery Maintenance 3.13 Battery Maintenance 3.13-2 Battery Charging Operation This section provides the operator with procedures on how to service and charge the battery. This also provides charger operation instructions. 3.13-1 Battery Service Procedures WARNING Explosion Hazard - Keep flames and Figure 3-17.
  • Page 58 Battery Maintenance Section 3 - Operation Charging State LED CAUTION When changing the input voltage wait State of charge until all the LEDs are OFF or wait a 0 to 50% Blinking 50% to 75% Blinking minimum of 20 seconds before switching 75% to 100% Blinking on the new voltage.
  • Page 59 Section 3 - Operation Battery Maintenance Batteries do not fully charge. If the batteries are charged overnight, make sure the AC supply is not being switched off at night with other building items. Check battery condition and for dead cells or reduced capacity. Replace charger only if other problems are not found.
  • Page 60 Notes SJIII DC Electric Page 60 December 2007...

  • Page 61: Section 4 - Tables

    Section 4 Tables Table 4.1 Standard and Optional Features Models 3215 3219 3220 3226 4626 4632 S T A N D A R D E Q U I P M E N T Base control console Color coded and numbered wiring system DC power (VDC) Dual holding brakes Forklift pockets/tie downs/lifting lugs...

  • Page 62: Table 4.2 Owner's Annual Inspection Record

    Tables Section 4 Table 4.2 Owner’s Annual Inspection Record Model Number: _________________ Serial Number:__________________ 20__ 20__ 20__ 20__ 20__ 20__ 20__ 20__ 20__ 1001AA This decal is located on the scissor assembly. It must be completed after an annual inspection has been completed. Do not use the aerial platform if an inspection has not been recorded in the last 6 months.

  • Page 63: Table 4.3A Specifications And Features

    Section 4 Tables Table 4.3a Specifications and Features MODEL 3215 3219 3220 3226 Weight 1120 kg 1579 kg 1889 kg 1890 kg Overall width 0.81 m 0.83 m 1.80 m 2.34 m Overall length Platform Size (inside) 0.66 m x 1.63 m 0.70 m x 2.10 m Height Working Height...

  • Page 64: Table 4.3B Specifications And Features

    Tables Section 4 Table 4.3b Specifications and Features MODEL 4626 4632 Weight 2805 kg 2935 kg 1.2 m Overall width 2.3 m Overall length 1.1 m x 2.1 m Platform Size (inside) Height Working Height 9.9 m 11.8 m Platform Elevated Height 7.9 m 9.7 m Stowed Platform Height...

  • Page 65: Table 4.4 Maximum Platform Capacities (Evenly Distributed)

    Section 4 Tables Table 4.4 Maximum Platform Capacities (Evenly Distributed) Extension Persons Maximum Extension Capacity Maximum Tilt Cutout Setting Model Persons Capacity Manual Force [kg] Wind [m/s] [deg] [kg] Extension 3215 0.91 1.5 x 3.5 12.5 3219 0.91 1.5 x 3.5 12.5 3220 0.91...

  • Page 66: Table 4.5 Floor Loading Pressure

    Tables Section 4 Table 4.5 Floor Loading Pressure Total Aerial Total Aerial Platform Load Platform MODEL Wheel LCP** OUP** Weight kPa (kN/m kPa (kN/m min* 1120 3215 max* 1347 min* 1579 10.6 3219 max* 1806 12.0 min* 1889 3220 max* 2252 11.8 min*...
  • Page 67 Intermixing tires of different types or using tires of types other than those originally supplied with this equipment can adversely affect stability. Therefore, replace tires only with the exact Skyjack-approved type. Failure to operate with matched approved tires in good condition may result in death or serious injury.

  • Page 68: Table 4.6 Maintenance And Inspection Schedule

    B - Perform Scheduled Maintenance Inspection. Refer to Service & Maintenance manual. * - Maintenance must be performed only by trained and competent personnel who are familiar with mechanical procedures. † - Refer to Skyjack's website @ www.skyjack.com for latest service bulletins prior to performing quarterly or yearly inspection.

  • Page 69: Table 4.7 Operator's Checklist

    Model: Hourmeter Reading: Operator's Name (Printed): Date: Time: Operator's Signature: Each item shall be inspected using the the appropriate section of the Skyjack operating manual. As each item is inspected, check the appropriate box. INSPECTION FREQUENCY - PASS FREQUENTLY ...
  • Page 70 Notes SJIII DC Electric Page 70 December 2007...

  • Page 71: Section 5 - Labels

    Section 5 - Labels Label Legend Label Legend Safety Red Safety Red indicates DANGER. Safety Orange Safety Orange indicates WARNING. Safety Yellow Safety Yellow indicates CAUTION. Safety Green Safety Green indicates emergency lowering. Safety Blue Safety Blue indicates safety information. SJIII DC Electric December 2007 Page 71...
  • Page 72 Labels Section 5 Labels and Nameplates - Models 3215 & 3219 Right Side Label Pictorial Description Skyjack Logo Skyjack Caution Tape Stripe Caution stripe Wheel Load* Indicates rated wheel load. *Wheel load will vary with each model. Model Number* Product Identifier *Model number will vary, may not be as shown.
  • Page 73 Section 5 Labels Labels and Nameplates - Models 3215 & 3219 Right Side (Continued) Description Label Pictorial Battery Spacers* Place spacers only as shown in diagram. *Spacers vary over different MEWP . Crushing Hazard Danger - Crushing hazard Model Number* Product Identifier *Model number will vary, may not be as shown.
  • Page 74 Labels Section 5 Labels and Nameplates - Models 3215 & 3219 Front Side Label Pictorial Description Crushing Hazard Danger - Crushing hazard Caution Tape Stripe Caution stripe Maintenance Support Deploy maintenance support here. Refer to the Operating manual for Free-wheeling Procedure. Open free-wheeling valve by turning counterclockwise.
  • Page 75 Section 5 Labels Labels and Nameplates - Models 3215 & 3219 Left Side Clearance Requirements Label Pictorial Description Caution Tape Stripe Caution stripe Wheel Load* Indicates rated wheel load. *Wheel load will vary with each model. Crushing Hazard Danger - Crushing hazard Keep Clear Keep clear.
  • Page 76 Clearance requirements for operating non-insulated mobile plant, including elevating work platforms near power lines. Model Number* Product Identifier *Model number will vary, may not be as shown. Skyjack Logo Skyjack Model Number* Product Identifier *Model number will vary, may not be as shown.
  • Page 77 Section 5 Labels Labels and Nameplates - Models 3215 & 3219 Electrical Panel Hydraulic Tray Label Pictorial Description Ground Circuit Breaker Push to reset ground circuit breaker. Power Circuit Breaker Push to reset power circuit breaker. Hydraulic Oil ATF Dexron III Replace hydraulic fluid with ATF Dexron III only.
  • Page 78 Labels Section 5 Labels and Nameplates - Models 3215 & 3219 Back Side Clearance Requirements Label Pictorial Description Serial Plate* Product identification and specifications *Serial plates will vary, may not be as shown. This MEWP complies with requirements of AS/NZS 1418.10:2011 Standard.
  • Page 79 Section 5 Labels Labels and Nameplates - Models 3215 & 3219 Back Side (Continued) Clearance Requirements Label Pictorial Description Charger Information Charger specification information and operation status; consult manual. PART NO. 128537 VOLT. AUTO SELECTABLE DUAL AC INPUT 85VAC/264VAC 50/60Hz E230227 CURRENT 4A 8.5A...
  • Page 80 Labels Section 5 Labels and Nameplates - Models 3215 & 3219 Back Side (Continued) Clearance Requirements Label Pictorial Description Winching/Towing/Pushing Procedure Refer to Operating manual. 1. Block or chalk wheels to prevent MEWP from rolling. 2. Turn main power disconnect switch to off position. 3.
  • Page 81 Section 5 Labels Labels and Nameplates - Models 3215 & 3219 Back Side (Continued) Clearance Requirements Label Pictorial Description Hazard Identification Refer to Section 1: Safety Rules. Read and understand the outlined risks associated with this work platform prior to operation. Manual Storage Box Indicates location of operating manual.
  • Page 82 Labels Section 5 Labels and Nameplates - Models 3215 & 3219 Back Side (Continued) Clearance Requirements Cylinder Label Pictorial Description Operator’s Daily Inspection Refer to the Operating manual. Perform visual inspection and function tests at the beginning of each shift. Refer to Section 4: Maintenance and Inspection Schedule.
  • Page 83 Section 5 Labels Labels and Nameplates - Models 3215 & 3219 Top Side Outlet Box Lanyard Anchorage Point Railing Pins Label Pictorial Description Forklift Pocket Insert fork fully into pocket to lift MEWP . Lift and Tie Down Points Only use these points for lifting or tying down. Warning - Do Not Alter DO NOT alter or disable limit switches or other safety devices.
  • Page 84 Labels Section 5 Labels and Nameplates - Models 3215 & 3219 Top Side (Continued) Label Pictorial Description How to engage maintenance support for inspection or maintenance. Refer to Operating manual. 1. Raise platform until there is adequate clearance to swing down maintenance support.
  • Page 85 Section 5 Labels Labels and Nameplates - Models 3215 & 3219 Platform Control Console Label Pictorial Description Platform Control Console Squeeze “ ” trigger to enable controller. Operate “ ” rocker switch to steer. Move controller handle forward to “ ”...
  • Page 86 Labels and Nameplates - Models 3220, 3226 & 46xx Right Side Label Pictorial Description Keep Clear Keep clear. Stay away from aerial platform when in operation. Skyjack Logo Skyjack Wheel Load* Indicates rated wheel load. *Wheel load will vary with each model. Fuse Location...
  • Page 87 Section 5 Labels Labels and Nameplates - Models 3220, 3226 & 46xx Right Side (Continued) Label Pictorial Description Crushing Hazard Danger - Crushing hazard Model Number* Product Identifier *Model number will vary, may not be as shown. Battery Spacers* Place spacers only as shown in diagram. *Spacers vary over different units.
  • Page 88 Labels Section 5 Labels and Nameplates - Models 3220, 3226 & 46xx Front Side 127711AA 127711AA Label Pictorial Description Crushing Hazard Danger - Crushing hazard Maintenance Support Deploy maintenance support here. Lift and Tie Down Points Only use these points for lifting or tying down. Caution Tape Stripe Caution stripe SJIII DC Electric...
  • Page 89 Section 5 Labels Labels and Nameplates - Models 3220, 3226 & 46xx Left Side Clearance Requirements Label Pictorial Description Skyjack Logo Skyjack Caution Tape Stripe Caution stripe Wheel Load* Indicates rated wheel load. *Wheel load will vary with each model.
  • Page 90 Labels Section 5 Labels and Nameplates - Models 3220, 3226 & 46xx Left Side (Continued) Clearance Requirements Label Pictorial Description Crushing Hazard Danger - Crushing hazard Model Number* Product Identifier *Model number will vary, may not be as shown. Annual Inspection Ensure that work platform has received annual inspection prior to operation.
  • Page 91 Section 5 Labels Labels and Nameplates - Models 3220, 3226 & 46xx Left Side (Continued) Clearance Requirements Label Pictorial Description Emergency Lowering Procedure Refer to Operating manual. 1. Turn main power disconnect switch to off position. 2. To open lift cylinder holding valve located at the bottom of the cylinder: (A) push (B) turn knurled knob counterclockwise.
  • Page 92 Labels Section 5 Labels and Nameplates - Models 3220, 3226 & 46xx Electrical Panel Hydraulic Tray Cylinder Label Pictorial Description Hydraulic Oil ATF Dexron III Replace hydraulic fluid with ATF Dexron III only. Ground Circuit Breaker Push to reset ground circuit breaker. Power Circuit Breaker Push to reset power circuit breaker.
  • Page 93 Section 5 Labels Labels and Nameplates - Models 3220, 3226 & 46xx Back Side Clearance Requirements 138211AB Label Pictorial Description Warning - Do Not Alter Do not alter or disable limit switches or other safety devices. Platform Capacity* Rated work load in each configuration *Platform capacity varies over different aerial platforms.
  • Page 94 Labels Section 5 Labels and Nameplates - Models 3220, 3226 & 46xx Back Side (Continued) Clearance Requirements 138211AB Label Pictorial Description Emergency Lowering Procedure Refer to Operating manual. 1. Turn main power disconnect switch to off position. 2. To open lift cylinder holding valve located at the bottom of the cylinder: (A) push (B) turn knurled knob counterclockwise.
  • Page 95 Section 5 Labels Labels and Nameplates - Models 3220, 3226 & 46xx Back Side (Continued) Clearance Requirements 138211AB Label Pictorial Description Manual Storage Box Indicates location of operating manual. Hazard Identification Refer to Section 1: Safety Rules. Read and understand the outlined risks associated with this work platform prior to operation.
  • Page 96 Labels Section 5 Labels and Nameplates - Models 3220, 3226 & 46xx Back Side (Continued) Clearance Requirements 138211AB Label Pictorial Description Winching/Towing/Pushing Procedure Refer to Operating manual. 1. Block or chalk wheels to prevent aerial platform from rolling. 2. Turn main power disconnect switch to off position. 3.
  • Page 97 Section 5 Labels Labels and Nameplates - Models 3220, 3226 & 46xx Back Side (Continued) Label Pictorial Description Base Controls Select “ ” to lower or “ ” raise platform. Select “ ” platform to enable platform controls, “ ” off to dis- able controls or “...
  • Page 98 Labels Section 5 Labels and Nameplates - Models 3220, 3226 & 46xx Back Side (Continued) 13 15 Label Pictorial Description Connect Platform AC Supply Connect AC power supply here for platform accessory outlet. Refer to the Operating manual for Free-wheeling Procedure. Open free-wheeling valve by turning counterclockwise.
  • Page 99 Section 5 Labels Labels and Nameplates - Models 3220, 3226 & 46xx Top View Lanyard Anchorage Railing Pins Point Label Pictorial Description Lift and Tie Down Points Only use these points for lifting or tying down. Forklift Pocket Insert fork fully into pocket to lift aerial platform. Falling Hazard - Railing Pins (Horizontal) (If Equipped) WARNING! Falling Hazard.
  • Page 100 Labels Section 5 Labels and Nameplates - Models 3220, 3226 & 46xx Top View (Continued) Label Pictorial Description How to engage maintenance support for inspection or maintenance. Refer to Operating manual. 1. Raise platform until there is adequate clearance to swing down maintenance support.
  • Page 101 Section 5 Labels Labels and Nameplates - Models 3220, 3226 & 46xx Platform Control Console Label Pictorial Description Platform Control Console Squeeze “ ” trigger to enable controller. Operate “ ” rocker switch to steer. Move controller handle forward to “ ”...
  • Page 102 Labels Section 5 Labels and Nameplates - Models 3220, 3226 & 46xx Control Box - Powered Extension Platform Label Pictorial Description Lift Enable (If Equipped) Select to enable lift mode. Powered Extension Platform Extend/Retract (If Equipped) Select “ ” to extend or “ ”...
  • Page 104 Reliable lift solutions by people who care. www.skyjack.com...
