State of the art hyper-optimized video management platform designed for ease, speed and efficiency.
Blackjack
or upto 3 Panzilla
DW-BJCUBE4T-DL
CUBE Deluxe
Server
Quick Start
Guide
NOTE: Download All Your Support Materials and Tools in One Place
1. Go to: http://www.digital-watchdog.com/support-download/
2. Search your product by entering the part number in the 'Search by Product' search bar. Results for applicable part numbers will
populate automatically based on the part number you enter.
3. Click 'Search'. All supported materials, including manuals, Quick Start Guides (QSG), software and firmware will appear in the results.
Attention: This document is intended to serve as a quick reference for initial set-up.
See the DW Spectrum full manual for more information on features and functionality.
Tel: +1 (866) 446-3595 / (813) 888-9555
Technical Support Hours: 9:00AM – 8:00PM EST, Monday thru Friday
®
Cube Deluxe — Up to 96 2.1MP Cameras (1080p True HD Resolution)
®
MEGApix
DW-BJCUBE8T-DL
Default Login Information for DW Spectrum
Username: admin
1 Set
Recovery USB
Keyboard and
1 Set
Mouse
®
48MP Cameras -DWC-PZV2M72T
Blackjack Cube-Deluxe
DW-BJCUBE12T-DL DW-BJCUBE16T-DL DW-BJCUBE20T-DL
Password: admin1234
WHAT'S IN THE BOX
Quick Start Guide
Blackjack Cube-DL
®
IPVMS
1 Set
Power Cable
1 Set
1 Set
digital-watchdog.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Digital Watchdog DW-BJCUBE4T-DL
Summary of Contents for Digital Watchdog DW-BJCUBE4T-DL
- Page 1 Cube Deluxe — Up to 96 2.1MP Cameras (1080p True HD Resolution) ® ® or upto 3 Panzilla MEGApix 48MP Cameras -DWC-PZV2M72T Blackjack Cube-Deluxe DW-BJCUBE4T-DL DW-BJCUBE8T-DL DW-BJCUBE12T-DL DW-BJCUBE16T-DL DW-BJCUBE20T-DL Blackjack Cube-DL ® Default Login Information for DW Spectrum IPVMS Username: admin Password: admin1234 WHAT’S IN THE BOX...
- Page 2 BLACKJACK CUBE DELUXE HARDWARE HDD LED Power Button / Power LED 5.25" Bay Front Back USB 2.0 Port Microphone Jack Headphone Jack USB 2.0 Port AC Power Socket Display Port (Not Used) HDMI Port (Not Used) VGA Port (Not Used) USB 3.0 Ports USB 2.0 Ports LAN Port...
- Page 3 Quick Start Guide SETTING UP THE CUBE DELUXE STEP 1: When setting up the Blackjack Cube Deluxe, make sure the following are in the box: Cube Server Quick Start Guide • • Recovery USB Power Cable • • Keyboard and Mouse •...
-
Page 4: Media Server
® SETTING UP DW SPECTRUM MEDIA SERVER Login : admin Password : admin1234 ® STEP 1: Initial run from Blackjack server ® 1. Open DW Spectrum Client by double click on the DW Spectrum icon 2. Click on the preconfigured server. 3. - Page 5 Quick Start Guide STEP 2: To rename the server 1. Right click on the server name listed on the Resources then click Server Settings. 2. Go to General tab, then type in the new server name in the Name field and click OK.
- Page 6 STEP 3: To check for update 1. Click on the menu then click System Administration. 2. Go to Updates tab. Click Update System if turned orange.
- Page 7 Quick Start Guide If you are on the latest version, it will say “You have the latest version installed” and the Update System button will be greyed out. 3. Click OK when update is completed. STEP 4: Enter License 1. Go to System Administration then click License tab. 2.
- Page 8 3. Click OK to when the License is activated. STEP 5: Configure recording 1. Right click on the camera to setup recording, then click Camera Settings.
- Page 9 Quick Start Guide 2. Go to Recordings tab. 3. Click to turn on recording. 4. Configure Schedule Settings for Quality, FPS and Recording Type. 5. Click and drag mouse over the Recording Schedule to assign the recording setting.
- Page 10 Click on All to apply to the all schedules. 6. Red dot will appear next to the camera when the recording is started.
- Page 11 Quick Start Guide STEP 6: Backuping Database 1. Go to System Administration and click General tab. 2. Click Create Backup… button. 3. Navigate to the folder where to save and enter name of the backup file then click save. Strongly recommend to also backup to the external storage media. NOTE: More information and instructions are available in the Spectrum 3.0 Manual.
-
Page 12: Troubleshooting Tips
Important: OS not listed will be not be supported by DW ™ Tech Support Tel: +1 (866) 446-3595 www.digital-watchdog.com Fax: (813) 888-9262 sales@dwcc.tv Copyright © Digital Watchdog. All rights reserved. Rev Date: 08/17 Specifications and pricing are subject to change without notice.
