Summary of Contents for Scott SLIMISSIMO 20200
-
Page 1: Instruction Manual
SLIMISSIMO Instruction Manual Model no.: 20200 Page 1 of 20... - Page 2 IMPORTANT INFORMATION For safety purpose you should read the instructions carefully before using the appliance for the first time. Save the instructions for future reference. The appliance is designed for domestic use and may only be operated in accordance with these instructions for use.
- Page 3 Do not use any accessories or attachments with this appliance other than those recommended by SCOTT. Do not insert fingers or other objects into the grinder. To disconnect from the mains supply outlet, do not drag the cord itself. Pull by the head of plug.
-
Page 4: General Description
A. GET TO KNOW YOUR COFFEE MACHINE GENERAL DESCRIPTION Accessories Coffee Machine 1. External drip tray 12. Cleaning brush 2. Internal drip tray 13. Cleaning cloth (for control panel) 3. Coffee grounds container 14. Cleaning agent x 3 packs 4. Adjustable coffee spout 5. -
Page 5: Control Panel
CONTROL PANEL Power ON/OFF button Hot water button Espresso button Lungo button Flashing: Low water level or water tank is missing Lack of coffee bean Lighting up stably: Coffee grounds container is full Flashing: Internal drip tray or coffee grounds container is missing Lighting up stably: Brewer is missing or installed improperly Flashing: Service door is opened or installed improperly Lighting up stably: Requires to process descaling... -
Page 6: Machine Installation
B. MACHINE INSTALLATION Remove all protective films, stickers and other packaging materials from the appliance. Place the appliance on a safe and stable surface with an easily reachable power supply and allow minimum distance from the sides of the machine. Insert the external drip tray, make sure it is inserted correctly. -
Page 7: First Time Use
Fill the water tank with water. Fill the coffee bean container with coffee beans. Unwind and straighten the power cord and insert the socket into the back of the machine. Insert the plug into a wall socket with suitable power voltage. FIRST TIME USE Press hot water button to clean inner parts of the coffee machine before first use. -
Page 8: Operation
C. OPERATION MAKING YOUR COFFEE Switch on the appliance by pressing the Power ON/OFF button The appliance is in standby condition. Place a cup under the coffee spout and adjust the height of the spout to fit the cup. Depending on the size or height of the cup, remove the drip tray or adjust the position of the drip tray as below: According to your preference, press Espresso button or Lungo button... -
Page 9: Filling The Coffee Bean Container
Rinse the water tank with fresh water and fill the tank to “MAX” level. Place it into the machine and make sure it is fully inserted. Important: Never fill the water tank with warm, hot, sparkling water or any other liquids which can damage the water tank and the machine. - Page 10 DAILY CLEANING OF THE APPLIANCE Timely cleaning and maintenance of the appliance is very important to prolong the life of the appliance. 1. Remove the external drip tray. 2. Drain the drip tray over sink and wash it with fresh water.
- Page 11 5. Push the recess area of service door. 6. Remove the service door. 7. Press the release buttons firmly. 8. Remove the brewer. Page 11 of 20...
- Page 12 9. Wash the brewer with fresh water. Dry it afterwards. 10. Insert the brewer to its original position and install the service door to its original position. Note: When lights up stably, it indicates that the brewer is missing or installed improperly. When flashes, it indicates that the service door is missing or installed improperly.
- Page 13 VI. TURNING OFF THE MACHINE Switch off the appliance by pressing the Power ON/OFF button. VII. AUTO-SHUT OFF The Appliance is equipped with auto-shut off function (see D. FURTHER SETTING – III. MODE SELECTION). The default auto-shut off time varies with the mode selected. D.
-
Page 14: Mode Selection
III. MODE SELECTION The machine is equipped with different settings: Default Setting, ECO Mode and Speed Mode. ECO Mode helps save energy, Speed Mode can make coffee more quickly than in default setting. Default Setting Speed Mode ECO Mode Illumination light Pre-brewing Auto shut off time 20 mins... -
Page 15: Cleaning And Maintenance
E. CLEANING & MAINTENANCE DESCALING When is flashing, it indicates that the appliance needs to undergo descaling. The appliance will remain in the best condition if this function is performed at least once a month or more regularly depending on the hardness of water used. Follow the procedures below: Note: The complete descaling process will take approximately 30 minutes. -
Page 16: Manual Rinsing
EMPTY SYSTEM FUNCTION It is recommended to use the empty system function before storing or before taking to repair agent. Switch on the appliance. Press and hold the button and Lungo button simultaneously for 5 seconds. will then be flashing. Remove the water tank from the appliance. - Page 17 CLEANING COFFEE GROUNDS OUTLET After using the appliance for a long period of time, coffee grounds may stick on the wall of grounds outlet. It is recommended to clean the outlet by following the steps below to ensure that coffee grounds can be delivering to the brewer. 1.
- Page 18 4. Remove the brewer. 5. Wash the brewer with fresh water. 6. Use cleaning brush to clean the grounds outlet. 7. After completing all cleaning processes, replace all units to original position. Page 18 of 20...
-
Page 19: Troubleshooting
F. TROUBLESHOOTING The appliance does not work. Possible Cause Solution - The appliance is not connected to the mains - Plug in and press the Power ON/OFF button. supply. - Check the cord and the plug. No or delayed response in several trials of pressing the function keys on panel. Possible Cause Solution - Appliance is under electromagnetic... -
Page 20: Recycling Your Electricals
Please arrange to take this appliance to recycling points set up around the country. To find out more information about the recycling of electrical items and the recycling point, please visit www.recycle-more.co.uk SCOTT (UK) Limited Unit 1, The iO Centre, Fingle Drive, Stonebridge, Milton Keynes, MK13 0AT, United Kingdom.
