Latching Input Mode - Use the Quick Talk
Input mode if repeated transmissions are desired with a
momentary switch (i.e. a push-button). The latching
effect maintains message repeats after the momentary
switch change has ended.
Example: To use a Quick Talk
you want it to re-transmit a message several times after
a "Press for Help" push-button is pressed. With the
TM
Quick Talk set to Latching Input mode, release of the
push-button is ignored and the message is re-
transmitted as scheduled.

Message Repeat

Repeat Message on each transmission
Your recorded voice message can be programmed to
repeat from one time to nine times on each Quick
TM
Talk radio transmission, depending on how you
program this feature. More urgent messages may have
more phrase repeats.
Example: You recorded the message "Pump Motor
Hot", then programmed Quick Talk
phrase two (2) times in each transmission. In this case,
activating the switch results in the Quick Talk
transmitting:
"...beep. Pump motor hot. Pump motor hot. beep..." The
beginning and ending beeps are added automatically to
attract attention to Quick Talk
Repeat Message with multiple transmissions
You can set a limit to the number of times the message
will be transmitted at the scheduled intervals.
Example: Suppose you have a vehicle detector switch
that closes when it detects a vehicle at the delivery door
of your building. Your recorded message might then be
"Vehicle at Delivery Door". You may want this message
TM
Q T D
UICK ALK EFAULT
TX Frequency (all inputs) 24 151.625 MHz (RQT-151)
QC/DQC Code (all inputs) 44 No Tone
DQC Invert
Compand
Input Type
Analog Setpoints
Input Operation
Latching Input Mode
Debounce/Holdoff Time
Number of Inputs
TX Alert Tone
Battery Saver
Low Battery Message
Power Fail Message
For assistance, call RITRON at 800-872-1872, or go to
TM
Latching
TM
in a paint department,
TM
to repeat the
TM
TM
transmissions.
P ...........................................................................................................
ROGRAMMING
22 154.600 MHz (RQT-151M)
26 467.850 MHz (RQT-451)
No
No
Contact Closure
High 3.5 VDC
Low 1.7 VDC
Normal
No
Open/High 10 sec.
Closed/Low 10 sec.
Inputs 1-2
Yes
Yes
Yes
No
to be transmitted every two minutes for approximately a
quarter hour after a vehicle is detected, then to stop
transmitting until the vehicle is moved. In this case, you
would program the message Wait Time for every two
minutes, and set the Message Limit to "8", as described
here.
When a vehicle arrives, the switch closes and the
message is transmitted every 2 minutes until it has
been sent 8 times over a span of 16 minutes, unless the
vehicle leaves before 16 minutes has lapsed. In this
case, the switch opens and the message ceases when
the vehicle is moved.
When another vehicle arrives, the Quick Talk
transmits the message every two minutes for about a
quarter of an hour, or until the vehicle leaves.
TM
The Quick Talk is set at the factory to transmit switch
status messages without limit. For example, if you
programmed the Quick Talk
message every hour, it would continue to do so until the
battery runs down.
Wait time between repeated transmissions
This sets the amount of time the Quick Talk
between repeated transmissions. You can program a
different Wait Time for the open condition, and for the
closed condition of your switch.
Example: The switch status message for switch open is
"Pump motor temperature OK". You may schedule the
TM
Quick Talk to transmit this message once every two
hours; this way, you know the Quick Talk
properly.
If the corresponding switch status message for switch
closed is "Pump Motor Over Temperature", you may
TM
schedule the Quick Talk
every two minutes, so the situation would receive
prompt attention.
Message Delay on TX
Recorded Messages
Input 1 Open/High
Input 1 Closed/Low
Input 2 Open/High
Input 2 Closed/Low
Power Fail
Low Battery
Number of Times Recorded Message is
repeated on each Transmission
Inputs 1-4 Open/High
Inputs 1-4 Closed/Low
Number of Times the Transmission is sent
Inputs 1-4 Open/High
Inputs 1-4 Closed/Low
Wait Time between Transmissions
Inputs 1-4 Open/High
Inputs 1-4 Closed/Low
www.ritron.com
TM
again
TM
to transmit a status
TM
will wait
TM
is operating
to broadcast this message
1 sec.
"Switch 1 open"
"Switch 1 closed"
"Switch 2 open"
"Switch 2 closed"
"Power fail"
"Low battery"
One time
One time
Repeat forever
Repeat forever
On change only
On change only
6
