If your Quick Assist was previously programmed with a
®
Quiet Call code and you need to remove it, follow the
programming instructions, using No Tone code, "44", as
shown in the table.
What is Digital Quiet Call
®
Digital Quiet Call (DQC) is a digital sub-audible coded
squelch system.
Do I need to program my Quick Assist
Quiet Call code?
If your radio system does not use Digital Quiet Call
other trade name equivalent, you will not need to program a
®
Digital Quiet Call code.
What is the purpose of testing the Quick Assist
transmitter?
After programming your radio, your Quick Assist
transmit on the same frequency as your radio receivers,
using any coded squelch signals required for your radio
system.
Do I need to test my Quick Assist
Yes; performing this test now will save you time and
confusion later.
I / R
NSTALLATION EPLACEMENT OF
1. Remove the Quick Assist
surface.
2. Remove the four corner screws holding the case
halves together, located on the back side of the
enclosure.
3. Separate the case halves and disconnect the battery
holder from the radio printed circuit board by
separating the in-line connectors.
4. Remove the lid on the battery holder by pressing the
tab at the top, and then remove the old batteries.
5. Install the new batteries. Be sure to observe the
correct polarity of the batteries, shown in the bottom
of the battery holder.
6. Install the battery holder lid and connect the two
polarized, in-line battery connectors.
7. Press the front panel push button and test the Quick
®
Assist by listening on a receiving radio.
8. Secure the case halves with the four corner screws
and re-install on the wall or mounting surface.
NOTE: Be sure to properly dispose of the used batteries
removed from the Quick Assist
For assistance, call RITRON at 800-872-1872, or go to
®
?
®
with a Digital
®
, or any
®
radio
®
will
®
Transmitter?
B ...................................................................................................
ATTERIES
®
from the wall or mounting
®
.
TO TEST THE QUICK ASSIST
TRANSMITTER:
a. Turn on your radio receiver.
b. Press the red button on front of the Quick
®
Assist .
®
c. Quick Assist transmits the "Assistance
needed" message, which you should be able
to hear on your radio receiver.
If you do not hear the messages, you have
probably not properly programmed the Quick
®
Assist transmitter frequency or the Quiet Call
Coded Squelch. In this case, repeat the
programming, then perform this test again.
What is the purpose of recording a unique
Voice Phrase for the Low Battery Message?
When it senses the installed batteries are nearly
®
run down, Quick Assist
each hour the factory- programmed message:
"Low Battery". If you maintain several Quick
®
Assist transmitters within radio range of each
other, you may customize this feature to easily
determine which unit needs new batteries.
Do I need to program this feature?
If you use only one Quick Assist
you regularly change Quick Assist
factory programmed message may be sufficient
for your application.
www.ritron.com
®
RADIO
®
will transmit one time
®
in any area, or if
®
batteries, the
3
