I Q
DENTIFICATION OF UICK
1 Battery Holder
The battery holder accommodates the six (6)
standard "AA" alkaline cells required to power the
®
Quick Assist .
NOTE: Always install a fresh set of alkaline
batteries before programming the unit.
2 Front Panel LED
The red front panel LED is lit whenever the Quick
®
Assist is transmitting a message.
3 SMB Antenna Connector
This connects the internal antenna to the radio
printed circuit board.
4 External Audio Input
Allows input to the Quick Assist
from an external audio source, such as the Line
Out audio from your computer.
5 Microphone
Microphone for recording voice messages.
FIG-1: CONTROLS & CONNECTIONS
3
4
5
6
7
8
For assistance, call RITRON at 800-872-1872, or go to
®
A C
SSIST ONTROLS AND
®
voice recorder
2
9
C ....................................................................
ONNECTIONS
6 USB Programming Connector
Connects the Quick Assist
computer for programming.
7 Record Button
Press this button to initiate voice recording.
8 Internal Antenna
The internal antenna radiates radio signals.
9 Front Panel Push Button
When the front panel push button is pressed the Quick
®
Assist transmits your pre-recorded voice message. This
sealed push button provides a water-resistant enclosure.
10 Battery Connector
In-line connector between the printed circuit board and the
battery holder.
IMPORTANT: Do not remove any other fasteners or further
disassemble the Quick Assist
the unit and voiding the manufacturer's warranty.
1
10
www.ritron.com
®
to the USB port on your
®
unit; doing so risks damage to
4
