Aquabot XTREME Operator's Manual & Troubleshooting Manual

In ground residential robotic swimming pool cleaner

Advertisement

IN GROUND RESIDENTIAL
ROBOTIC SWIMMING POOL CLEANER
OPERATOR'S MANUAL &
TROUBLESHOOTING GUIDE
Please Read Carefully Before Using Your Pool Cleaner
ENGLISH
PART # 820332

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XTREME and is the answer not in the manual?

Questions and answers

Garth
May 22, 2025

I just changed the drive belts and now it only goes in one direction when in the pool. How can I fix?

1 comments:
Mr. Anderson
May 25, 2025

If your Aquabot XTREME only goes in one direction after changing the drive belts, it may be due to incorrect reassembly. Follow these steps to fix it:

1. Inspect the drive belts to ensure they are correctly installed: one belt should go from the drive pulley to the front wheel tube, and the other from the drive pulley to the rear wheel tube.

2. Verify that the drive belts, drive pulley, stepped sleeve rollers, small rollers, and bushings are correctly positioned as they were before disassembly.

3. Check if the belts are properly tensioned and not loose, stretched, or flat-spotted.

4. Confirm that the side plates and screws are securely installed and that the wheel tube retaining rings are correctly placed.

Improper installation of these parts can affect the cleaner’s movement and cause it to go in only one direction.

This answer is automatically generated

Summary of Contents for Aquabot XTREME

  • Page 1 IN GROUND RESIDENTIAL ROBOTIC SWIMMING POOL CLEANER OPERATOR’S MANUAL & TROUBLESHOOTING GUIDE Please Read Carefully Before Using Your Pool Cleaner ENGLISH PART # 820332...
  • Page 2 CustomerService@AquaProducts.com for personal support and answers to any questions regarding technical or operating issues of your cleaner. The following specifications are for the cleaner models - AQUABOT XTREME POOL TYPE APPLICATION: All residential pool types; Covers floor and lower portion of walls.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Operating Features........................3-4 Quick Start Instructions......................5 Setting Up Your Cleaner......................6-7 ..Setting.up.the.Power.Supply..................... 6 ..Cleaner.Start.Position......................... 6 ..Directional.Guidance........................7 Maintaining Your Pool Cleaner....................8-14 ..Cleaning.and.Changing.the.Filter.Bag..................8 ..Flotation............................9 ..Propeller.Care..........................10 ..Floating.Cable.Care........................10 ..Scrubbing.Brushes.Care.&.Replacement................. 10-11 ..Changing.Drive.Tracks........................
  • Page 4: Operating Features

    OPERATING FEATURES Although.the.shape.and.color.of.cleaners.and.components.featured.herein.may.not.be.identical.to.those.of.your.cleaner,. their.operating.and.service.procedures.are...The reference numbers below are used throughout this manual. Figure 1 Side.Handle Brushes 11.. Filter.Screen Outlet.Top Pump.Motor 12.. Floating.Cable.( see below Propeller Drive.Motor 13.. G-Tooth™.Drive.Track Side.Plate Filter.Bag 14.. Wheel.Tube Wheel.Tube.Retaining.Ring 10.. Bottom.Lid.Assembly.( see page FLOATING CABLE FEATURES Figure 2 2 Prong Male...
  • Page 5 BOTTOM LID ASSEMBLY Figure 3 12..Bottom.Lid 12a...Wire.Frame.Bag.Support 12b..“H”.-.Float.(Fig..3a) 12c..Side.Pocket.Floats.(Fig..3a) 12d..Debris.Intake.Port.Flap 12e..Filter.Bag POWER SUPPLY FEATURES Figure 4 15a...Power.Supply.Handle 15b...Power.Switch.-.ON/OFF 15c...Fuse.Holder* 15d...Power.Supply.(Housing) 15e...Floating.Cable.Socket 15f..Power.Supply.Cable * Fuse Holder is located on the back of the Power Supply...
  • Page 6: Quick Start Instructions

    QUICK START INSTRUCTIONS SETTING.UP.YOUR.NEW.ROBOTIC.POOL.CLEANER.IS.AS.EASY.AS.1,.2,.3! TIP! To help protect your Floating Cable from potentially getting wrapped around your cleaner’s brushes, it is suggested to turn off your pool’s filtration system while your cleaner is in operation. Figure 5a Power Supply Floating Cable Make sure that the Power Supply is positioned at the center of the long side of the...
  • Page 7: Setting Up Your Cleaner

    SETTING UP YOUR ROBOTIC POOL CLEANER WARNING: The Power Supply must be placed at least 12 feet / 4 meters from the pool’s edge at all times! WARNING: A Ground Fault Circuit Interrupter (GFCI) / Residual Current Device (R.C.D.) must be installed to protect your electric outlet and to prevent any possible electrical shock! 1.
  • Page 8: Directional.guidance

    DIRECTIONAL GUIDANCE CABLE FLOAT The.Cable.Float.(Fig..2).is.a.flotation.device.that.enables.your.cleaner.to.turn.on.the.floor.where.the.majority.of.debris.resides.. . This.offers.faster,.more.efficient.and.complete.coverage.of.virtually.any.pool.configuration...Your.cleaner.will.move.down. the.wall.and.about.halfway.across.the.pool.floor.and.then.reverse...When.it.reverses.its.internal.Pump.Motor.will.temporarily. turn.off.allowing.the.Cable.Float.to.lift.its.side.of.the.cleaner.allowing.only.the.opposing.side.to.have.traction...As.the.cleaner. reverses,.the.side.with.traction.will.cause.your.cleaner.to.turn.in.an.arc-radius.manner..The.internal.Pump.will.turn.back.on.and. full.traction.will.be.regained,.allowing.the.cleaner.to.continue.in.a.straight.line.to.the.wall... CLEANING PATTERN Cable Float Pattern Description: Your cleaner.searches.for.the.wall.and.climbs.it.for.a.couple.of. seconds.reaching.only.about.1.5’./..5m.or.so. Your.Cleaner.moves.across.the.floor.to.about.half.the.width.of.the. pool.and.then.reverses.backwards.for.a.few.seconds...The.cleaner. turns.slightly.and.moves.towards.the.wall.again.. Your.cleaner.climbs.the.wall.for.a.couple.of.seconds. Your.cleaner.reverses.to.move.back.across.the.floor.to.about. half.the.width.of.the.pool.and.then.reverses.backwards.for.a.few. seconds..The.cleaner.turns.slightly.and.moves.towards.the.wall. again... Your.cleaner.climbs.the.wall.for.a.couple.of.seconds. Your.cleaner.moves.across.the.floor.to.about.half.the.width.of.the. pool.and.then.reverses.backwards.for.a.few.seconds...The.cleaner. turns.slightly.and.moves.towards.the.wall.again. Your.cleaner.climbs.the.wall.for.a.couple.of.seconds.. Your.cleaner.moves.to.the.opposite.wall.to.restart.the.full.pattern. NOTE: Your robot is equipped with a safety feature that automatically reverses it after a number of minutes should it not locate a wall and tilt to approximately 90º.
  • Page 9: Maintaining Your Pool Cleaner

    MAINTAINING YOUR POOL CLEANER CLEANING AND CHANGING THE FILTER BAG Thoroughly cleaning the Filter Bag (see step 4 below) after every use is the most important maintenance step you can take to ensure optimum performance of your cleaner..The.Filter.Bag’s.(Page.4,.Fig..3).holding.capacity.is.large.in.comparison.to.all.other.brands.of. independent.pool.cleaners,.but.far.smaller.than.that.of.a.pool’s.main.filter...Perhaps.it.is.more.important.to.know.that.your.cleaner’s. Filter.Bag.can.filter.out.particles.down.to.20.times.smaller.than.what.many.main.filters.can...This.means.that.the.fine.particles.such.as. algae.and.bacteria,.invisible.to.the.naked.eye,.which.slip.through.the.main.filter.and.back.into.the.pool.to.settle.into.the.pores.of.the.
  • Page 10: Flotation

    FLOTATION Figure 10a Your.cleaner.is.a.universal.pool.cleaner.which.performs.under.varying.chemical. and.temperature.conditions.in.your.pool...Your.cleaner.offers.the.best.possible. performance. when. it. is. virtually. weightless. in. your. pool.. . Therefore,. careful. balancing.of.its.weight.is.important.for.proper.operation..Generally,.a.new.cleaner. is.universally.balanced.when.used.for.the.first.time.and.additional.Flotation.(Fig.. 10a-b).is.not.required.on.start-up. IMPORTANT: Careful. removal. of. air. trapped. in. the. housing. is. critical.. Each. time. you. place. your. cleaner. in. the. pool. use. the. Handle. (while. submersed).to.turn.it.upside.down.and.gently.rock.it.back.and.forth.to.
  • Page 11: Propeller.care

    PROPELLER CARE Figure 12a It. is. a. good. practice. to. inspect. the. Propeller. (Page. 3;. Fig.. 1). once. or. twice. per. season. to. check. for. obstructions,. which. may. reduce. water. flow. and. thus. vacuuming.ability.and.pool.coverage. IMPORTANT: To protect against personal injury and damage to your GFCI cleaner always unplug your cleaner from its Power Supply prior to Power Supply...
  • Page 12: Changing.drive.tracks

    To protect against personal injury and damage to your cleaner always unplug your cleaner from its Power Supply prior to performing any maintenance or repair procedures! To Change Super Brushes for full length and “split” Wheel Tubes: (Fig. 13) 1.. Using.a.pair.of.pliers,.grab.one.end.of.the.stainless.steel.Rod.that.is.securing. Figure 13 the.old.Brushes.onto.the.Wheel.Tube..Pull.away.from.the.Wheel.Tube.slowly.
  • Page 13: Changing.drive.belts

    IMPORTANT: Always replace both Tracks at the same time! Replacing only one will adversely effect the cleaner’s cleaning pattern! Figure 16 CHANGING DRIVE BELTS Drive.Belts.(Page.13;.Fig..19a-b).may.become.worn.over.the. normal.course.of.use.and.will.require.replacement.based.on. the.frequency.of.use,.the.pool’s.chemical.balance.and.length. of.season...Worn.Drive.Belts.will.impede.your.cleaner’s.ability. to.move.or.climb.and.may.effect.the.cleaning.pattern.impeding. its. ability. to. cover. the. entire. pool.. . If. during. your. periodic. inspection.you.find.that.your.Drive.Belts.are.stretched,.loose.
  • Page 14 DRIVE BELT ASSEMBLY Figure 19a Inside View Drive Belt Drive Pulley Stepped Sleeve Rollers Side Plate Wheel Tube When re-assembling, please make sure that the teeth of the Drive Belts are facing inward. Small Rollers Figure 19b Top View NOTE: When re-assembling be sure that the Drive Tracks are positioned so that they press against the thick side of the Stepped Sleeve Rollers.
  • Page 15: Cleaner.storage

    CLEANER STORAGE When.not.in.use.it.is.important.that.your.cleaner,.its.Floating.Cable.and.Power.Supply.are.properly.stored.in.a.clean.and.dry. area,.away.from.direct.sunlight,.protected.from.below.freezing.temperatures.and.exposure.to.chemicals.and.their.fumes.(i.e.. chlorine)...This.will.help.prevent.any.unnecessary.wear.or.damage.to.your.cleaner.or.its.components...Prior.to.storing.your. cleaner,.thoroughly.clean.your.Filter.Bag.and.dry.off.your.cleaner...Ensure.that.its.Floating.Cable.is.untangled,.not.twisted. nor.in.a.figure.eight,.but.rather.coiled.either.around.your.cleaner’s.body.or.in.large.circular.loops.and.positioned.under.your. cleaner...Be.sure.to.rest.your.cleaner.on.its.side.so.that.its.Brushes.do.not.get.flat.spots. Correct Incorrect Incorrect (do.not.place.cleaner (do.not.coil.cable.in.a on.top.of.power.supply) figure.8.configuration) PREPARING YOUR CLEANER FOR SHIPPING In.the.event.that.you.should.have.to.send.your.cleaner.in.for.repair,.you.must.package.the.cleaner.properly.to.ensure.it. reaches.the.repair.facility.safely.and.without.incurring.damage.during.transport...This.will.delay.your.repair.turnaround. time.and.require.you.to.contact.your.shipper.directly.to.dispute.damages. NOTE: A log of all information from your contact with the Authorized Service Center (i.e. RMA, name, dates, cleaner model and serial number, etc.) should be kept with your operator manual and / or other important documents for your reference (See page 22: NOTES).
  • Page 16 A. protective. barrier. (preferably. thick. The. cleaner’s. Floating. Cable. should. be. coiled. cardboard). should. be. placed. on. top. of. the. and.encircled.around.the.Power.Supply.located. Floating.Cable.and.Power.Supply.(Fig..22). at.the.base.of.the.shipping.box.(Fig..21). Figure 21 Figure 22 Figure 23 Your. cleaner. should. be. completely. wrapped. in. bubble-wrap. or. equivalent. protective. material.. The. protected.cleaner.should.be.positioned.in.the.center.
  • Page 17: Troubleshooting Guide (Summary)

    TROUBLESHOOTING GUIDE ~ SUMMARY ~ The.most.common.troubleshooting.issues.are.presented.in.this.summary...Should.you.wish.a.more.detailed.description. of.a.procedure.or.have.other.troubleshooting.issues.please.refer.to.the.In.Depth.Troubleshooting.Guide.on.pages.18-21. WARNING: Before performing any troubleshooting maintenance procedures on your cleaner, it should be disconnected from the Power Supply (transformer) and the Power Supply should be unplugged from the electrical outlet to prevent the possibility of personal injury or damage to the cleaner! 1.
  • Page 18 7. DoeS NoT CLeAN eNTiRe PooL (miSSeS AReAS) A..Clean.Filter.Bag.thoroughly.(Page.8). B.. Install.Flotation.to.help.the.cleaner.climb.walls.partially.if.it’s.not.climbing.(Page.9). C.. Operate.the.cleaner.several.cycles.(up.to.7.hours.each). 8. geTS STUCk oN, mAiN DRAiNS, ReTURN FiTTiNgS, LighTS, STAiRS oR iN CoRNeRS A..Check.Scrubbing.Brushes.for.wear.(Pages.10-11.SCRUBBING.BRUSHES.and.REPLACEMENT). B.. Adjust.Flotation.(Page.9,.FLOTATION). 9. PoWeR SUPPLY APPeARS To ShUT oFF BeFoRe ComPLeTiNg A CLeANiNg CYCLe A..Unplug.the.Power.Supply.and.check.the.Fuse..(Page.4;.Fig..4) 10.
  • Page 19: Troubleshooting Guide (In Depth)

    TROUBLESHOOTING GUIDE ~ IN DEPTH ~ IMPORTANT: Before performing any troubleshooting maintenance procedures on your cleaner, it should be disconnected from the Power Supply (transformer) and the Power Supply should be unplugged from the electrical outlet to prevent the possibility of personal injury or damage to the cleaner. PUMPS WATER, BUT CLEANER DOES NOT MOVE OR MOVES SLOWLY Remove the cleaner from the pool and place it upside down (on a non-abrasive surface so that it won’t become scratched or scuffed) and unplug it from the Power Supply.
  • Page 20 DEBRIS COMES OUT OF THE CLEANER WHEN REMOVING IT FROM POOL (BOTTOM LID DOES NOT CLOSE PROPERLY) Filter Bag Ensure.that.the.Filter.Bag.is.properly.mounted.on.the.Wire.Bag.Support.Frame.(Page.8;.Figs..9a-b)...The.Filter.Bag’s.small. Label.on.the.elastic.edge.should.be.on.the.outside.of.the.bag.and.positioned.at.the.center.of.either.long.side.of.the.Bottom. Lid.Assembly.plastic...Stretch.the.elastic.bottom.over.each.Wire.and.slide.the.Filter.Bag.down.until.the.Filter.Bag.reaches. the.Bottom.Lid.plastic...At.that.point.the.Filter.Bag’s.elastic.bottom.should.be.stretched.over.the.plastic.lips.located.on. each.short.side.of.the.Bottom.Lid.Assembly,.and.will.hold.the.Filter.Bag.in.place..Pull.the.Filter.Bag.top.corners.into.each. of.the.top.4.corners.of.the.Wire.Frame...Insert.the.Bottom.Lid.into.the.bottom.of.the.cleaner...Be.sure.that.the.Filter.Bag’s. fabric.is.not.interfering.with.the.locking.of.the.Lock.Tabs.(Page.8;.Fig.8)...Be.sure.that.each.of.the.Lock.Tabs.are.“Locked”. closed. Debris intake Port Flaps (Page 4; Fig. 3, 12d) Check.that.the.Intake.Valve.Flaps.on.the.underside.of.your.cleaner.(in.the.Bottom.Lid.Assembly./.Page.4;.Fig..3).move.freely. to.open.and.close...Clean.Flaps.if.necessary. Lock Tabs (Page 8; Fig 8) Check.that.the.Lock.Tabs.are.not.warped...They.should.be.straight.and.aligned.with.the.cleaner’s.body...If.they.are.warped.
  • Page 21 DOES NOT CLEAN ENTIRE POOL (MISSES AREAS) Your.cleaner.is.designed.to.clean.the.pool.many.times.over.within.its.recommended.cleaning.cycle.by.moving.along.the. width.of.the.pool.(side.wall.towards.side.wall),.not.the.length. Your. cleaner. operates. by. crossing. over. 50%. of. the. floor’s. width,. stop. and. reverse. on. an. angle. or. arc. to. move. back. towards. the. original. side. wall.. . Once. the. cleaner. reaches. the. original. wall. it. will. reverse. and. repeat. this. process. with. varied.distances.across.the.width.of.the.pool..It.will.only.partially.climb.the.original.wall.every.4.times...(See.also.Pages.
  • Page 22 GETS STUCK ON, MAIN DRAINS, RETURN FITTINGS, LIGHTS, STAIRS OR IN CORNERS Your. cleaner. has. approximately. one. inch. of. clearance. between. the. floor. and. its. underside.. . The. Brushes. (Page. 16,. SCRUBBING. BRUSHES. CARE. AND. REPLACEMENT). enable. the. cleaner. to. climb. over. most. obstacles. like. main. drains,. return.filters,.lights,.and.pop-up,.in-floor.systems,.and.to.climb.up.stairs.in.most.pools...But,.in.some.cases,.the.size.or.
  • Page 23 MAKE A RECORD FOR FUTURE USE MODEL... PURCHASE.DATE... PLACE.PURCHASED..SERIAL.NUMBER... NOTE: Serial number can be found on the warranty card, the packing carton and your cleaner. QUESTIONS? Contact the Retailer you purchased your cleaner from ADDITIONAL NOTES:...
