emz smart Sol Operating Instructions Manual page 90

Page 90 PROFESSIONAL MODE
Define switch-ON/OFF temperature.
For the heating function,
T ON must be < T OFF.
For the cooling function,
T ON must be > T OFF.
Up to four time slots can be
assigned to each thermostat function.
First of all, define the switch-ON times.
Continue to scroll.
Define times for activation and deactivation.
Continue via the menu item
›Output parameter‹.
Here, the general settings for the
assigned outputs are defined.
Continue to scroll.
1.3.1 Thermostat R...
T ON
T OFF
t ON 1
t OFF 1
t ON 2
04. 07. 2015
1.3.1 Thermostat R...
t OFF 2
t ON 3
t OFF 3
t ON 4
t OFF 4
04. 07. 2015
1.3.7 Output para...
Tank ch.-over v 1
Solar pump 2
Boiler
t tear-off
n tear-off
04. 07. 2015
40.0°C
55.0°C
00:00
00:00
00:00
10:35
00:00
00:00
00:00
00:00
00:00
10:35
10s
100%
10:35
