TECHNICAL DATA

Intended Use
The differential temperature controller may be used exclusively as controller for the con-
trol of solar thermal plants. It must be operated within the scope of all the specifications
described. Installation and set-up of the controller may only be performed by specialists.
The fitter must have read and understood the operating manual.
The fitter explains all the relevant functions to the operator.
For operation, it is essential that the housing is closed and free of damage.
Scope of supplies
1 Differential temperature controller smart Sol
1 Instruction manual
Differential temperature controller smart Sol
Type of mounting
Housing
Mode of operation
Type of protection
Dimensions Width x Height x Depth [mm]
Weight [g] Basic version
Storage/operating temperature [°C]
Handling
Display
Power reserve of real time clock,
at least [h]
Connection to power supply
Design
Service voltage [VAC]
Line frequency [Hz]
Auxiliary consumption typ. [W]
Power consumption max. [W]
Fuse
Rated pulse voltage [V]
Wall-mounting
Plastics, in several parts
Type 1
IP 20
115 x 173 x 46
370
0-40, non-condensation
via rotary encoder and pushbuttons
TFT colour display 47 x 35 mm, backlit
8
3 spring-type terminals PE, N and L
230 ±10%
50 ±1%
1,74
3.5
Micro fuse, type 5 x 20 mm, T2A/250 V
2500
