emz smart Sol Operating Instructions Manual page 9

Max. cross sections to be connected
Cable end sleeve:
Single-wire
Fine-wired
Interfaces TS1 / TS2 / TS3 / TS4
Design
Assignment as inputs
Admissible temperature probe
Optional assignment of
TS3 / TS4 to the impeller sensor
Optional assignment as
output on TS4
Triac outputs RO1 / RO2
Design
Output voltage [VAC]
Output power max.
per output [VA]
Output current max.
per output [A]
Switching output REL: Floating change-over contact
Design
Switching voltage max. [V]
Switching capacity max. [VA]
Switching current max. [A]
TECHNICAL DATA
0.25 to 0.75 mm
2
0.50 to 1.50 mm
2
0.75 to 1.50 mm
2
2 spring-type terminals each
Temperature sensor Pt 1000
DFZ 1-100 pulses/litre
PWM signal 100Hz...2kHz or
analogue output 0...10V, max. 10mA
3 spring-type terminals each, PE, N and L
230 ±10%
200
1
3 spring-type terminals
253
230
1
