Fujitsu AWY24FBAJ Service Manual

Split type room air conditioner

Hide thumbs

Quick Links

Download this manual

SPLIT TYPE

ROOM AIR CONDITIONER

C E IL IN G W A L L

Models

t y pe

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

OUTLINE AND DIMENSIONS . . . . . . . . . . . . . . . . . . . .

REFRIGERANT SYSTEM DIAGRAM . . . . . . . . . . . . .

CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

ERROR DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

PCB CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . . . . . .

DISASSEMBLY ILLUSTRATION

PARTS LIST

STANDARD ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . 36

Indoor unit

Outdoor unit

AWY24FBAJ

AOY24FNAD

AWY24UBAJ

AOY24UNADL

C O N T E N T S

. . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Need help?

Do you have a question about the AWY24FBAJ and is the answer not in the manual?

Questions and answers

Summary of Contents for Fujitsu AWY24FBAJ

Page 1: Table Of Contents
SPLIT TYPE Models Indoor unit Outdoor unit ROOM AIR CONDITIONER AWY24FBAJ AOY24FNAD AWY24UBAJ AOY24UNADL C E IL IN G W A L L t y pe C O N T E N T S SPECIFICATIONS .......
Page 2: Specifications
SPECIFICATIONS TYPE Cool Cool & Heat INDOOR UNIT AWY24FBAJ AWY24UBAJ OUTDOOR UNIT AOY24UNADL AOY24FNAD COOLING CAPACITY (kW) 6.80 ----- 7.40 HEATING CAPACITY (kW) ELECTRICAL DATA POWER SOURCE FREQUENCY (Hz) RUNNING CURRENT (Cool) RUNNING CURRENT (Heat) ----- 2.12 2.12 INPUT WATTS (Cool)
Page 3: Outline And Dimensions
OUTLINE AND DIMENSIONS Unit : mm INDOOR UNIT Models : AWY24FBAJ AWY24UBAJ 1,150 Models : AOY24FNAD AOY24UNADL 2004.01.08...
Page 4: Refrigerant System Diagram
REFRIGERANT SYSTEM DIAGRAM Models : AWY24FBAJ / AOY24FNAD Models : AWY24UBAJ / AOY24UNADL 2004.01.22...
Page 5: Circuit Diagram
CIRCUIT DIAGRAM Models : AWY24FBAJ / AOY24FNAD INDOOR UNIT OUTDOOR UNIT TO POWER SOURCE 2004.03.17...
Page 6 Models : AWY24UBAJ / AOY24UNADL INDOOR UNIT OUTDOOR UNIT 2004.01.08...
Page 7: Error Display
ERROR DISPLAY The OPERATION, TIMER and SWING lamps operate as follows according to the error contents. Fast flashing Slow flashing Error display Error contents OPERATION TIMER SWING (RED) (YELLOW) (ORANGE) Indoor unit circuit board error Indoor unit room temperature sensor wire 2 times opened Indoor unit room temperature sensor wire...
Page 8 INDOOR PRINTED CIRUIT BOARD CIRCUIT DIAGRAM Model : AWY24FBAJ CONTROLLER PCB ASSEMBLY ( MAIN PCB ) EZ-0031FWSE-C B3B-XASK-1-A R62-R64 B2B-XASK-1-A CN1-3 ROOM TEMPERATURE THERMISTOR GRAY 10K <1/10W> x 3 CN1-2 CN5-1 BLACK CN1-1 CN5-2 GRAY BLACK R61 1.0K <1/10W> P126...
Page 9 Model : AWY24UBAJ CONTROLLER PCB ASSEMBLY ( MAIN PCB ) EZ-00314HSE-C B3B-XASK-1-A B2B-XASK-1-A ROOM TEMPERATURE THERMISTOR R62 - R64 CN1-3 GRAY 10K <1/10W> x 3 CN5-1 CN1-2 BLACK GRAY CN1-1 CN5-2 R61 1.0K <1/10W> BLACK NO.1 P126 FAN SWITCHING THERMAL FUSE R26 1.0K HEAT EXCHANGER THERMISTOR R60 1.0K <1/10W>...
Page 10: Disassembly Illustration
DISASSEMBLY ILLUSTRATION (Indoor unit) Models : AWY24FBAJ AWY24UBAJ 63-1 174-1 108-2 184-1 172-3 574-2 108-1 574-1 253-2 Fan motor earth wire 2004.01.22...
Page 11 652-1 2004.01.22...
Page 12 146-1 588-1 2004.01.22...
Page 13 2003.12.01...
Page 14 2003.12.01...
Page 15 522-2 253-2 522-1 2003.12.01...
Page 16 108-2 407-2 408-1 253-1 408-1 408-1 x 13 2003.12.01...
Page 17 759-1 253-3 2003.12.01...
Page 18 70-1 70-2 2003.12.01...
Page 19 815-1 2004.01.22...
Page 20 DISASSEMBLY ILLUSTRATION (Outdoor unit) Models : AOY24FNAD AOY24UNADL 2004.02.10...
Page 21 2004.02.12...
Page 22 Model : AOY24UNADL Model : AOY24FNAD 2004.02.12...
Page 23 Model : AOY24FNAD 824-4 823-2 815-3 989-1 989-2 218-3 Model : AOY24UNADL 824-4 823-2 218-4 815-3 218-3 989-1 989-2 2004.02.12...
Page 24 Model : AOY24FNAD 13-2 82-1 2004.03.17...
Page 25 Model : AOY24UNADL 13-2 18-1 82-1 2004.03.17...
Page 26: Parts List
"Order" column. Part No. Part No. Ref. Ord. Ref. Ord. Description Description Q'ty Q'ty AWY24FBAJ AWY24FBAJ 8-2 Filter Frame 9367681013 Upper Flap 9367688012 Base-B 9368216016 Lower Flap 9367689019 Control Box 9367663002...
Page 27 When you order parts, please make a photocopy of this page and fill the number of the parts in the "Order" column. Part No. Part No. Ref. Ord. Ref. Ord. Description Description Q'ty Q'ty AWY24UBBJ AWY24UBBJ Filter Frame 9367681013 Lower Flap 9367689019 Base-B 9368216016...
Page 28 When you order parts, please make a photocopy of this page OUTDOOR UNIT and fill the number of the parts in the "Order" column. Part No. Part No. Ref. Ord. Ref. Ord. Description Description Q'ty Q'ty AOY24FNAD AOY24FNAD Fan Cover (Guard) 9371187013 82-1 Check J oint...
Page 29 When you order parts, please make a photocopy of this page and fill the number of the parts in the "Order" column. Part No. Part No. Ref. Ord. Ref. Ord. Description Description Q'ty Q'ty AOY24UNADL AOY24UNADL Fan Cover (Guard) 9371187013 R ubber Mount 9351049010 Emblem-R ear "FUJ ITS U"...
Page 30: Standard Accessories
STANDARD ACCESSORIES OUTDOOR UNIT ACCESSORIES INDOOR UNIT ACCESSORIES Name and Shape Part No. Name and Shape Part No. Wall hook bracket Cable clip 313739340109 9367987009 Tapping screw 301463040100 9371190020 Remote control unit (AR-JW2) Drain pipe (Cool model)) 9303029015 [Heat & Cool model 9371190013 (Reverse cycle)only] (AR-JW1)
Page 31 0401G2476...

This manual is also suitable for:

Aoy24fnad Awy24ubaj Aoy24unadl
