Introduction

Reset Button

Use the reset button to clear an AP's configuration and set it back to its
factory defaults. To restore the factory default, use a small pin to press
and hold the reset button for 10 seconds while the AP has power applied.
Antenna
The Fusion 70 Access Point comes standard with three internal antennas.
However, the AP also includes three external antenna connectors that
allow you to connect external antennas (optional) to them to increase the
range of each radio.
Table 5
describes which antennas to use for each mode.
Table 5
Mode
2x3
2x2
1x1
6

Antenna Options

Antennas Used
A, B and C
A and C (not supported)
A (not supported)
001605, Rev. A
