Power and Environmental

Table 3
AC power
Operating
LEDs
The Fusion 70 Access Point has the following three LEDs on to provide a
visual indication of the operation status of the AP.
Table 4
LED
Power
2.4G
Link/Activity

PoE Compliant

The Fusion 70 Access Point is IEEE 802.3af compliant, so it can provide
power to the unit by using an Ethernet connection that utilizes power-
sourcing equipment (PSE). If you intend to use an Ethernet connection for
power, ensure that the connecting device is Power over Ethernet (PoE)
IEEE compliant.
001605, Rev. A
Power and Environmental
Input voltage
Frequency
Operating Temperature
Relative Humidity
LEDs
Description
Solid green: Power on
Off: Power off
Solid amber: CPU or system failed
Blinking amber: System initializing or resetting (software self-
testing)
Solid green: Good link at 2.4GHz
Blinking: Receiving/transmitting data
Off: No data transfer
Solid yellow: Good Link on 100Mbps
Blinking yellow: Receiving/transmitting data at 100M
Solid green: Good link on 1000Mbps
Blinking green: Receiving/transmitting data at 1000Mbps
Off: No Link
90-264 V AC
47-63 Hz
32 to 104ºF (0-40C)
5% to 95% (non-condensing)
Introduction
5
