PLEASE LEAVE THIS MANUAL WITH THE OSO UNIT AFTER INSTALLATION
This cylinder is manufactured and approved in accordance with EN 12897 : 2006
Thank-you for purchasing the Delta HP VIP unvented hot water cylinder.
Delta HP VIP is an unvented hot water cylinder in capacities 200, 250 and 300 litres. Its energy
efficiency as defined by standing heat losses is the best in its class due to the use of vacuum insulated Panels
save the hou
(VIP) and will
This manual gives detailed advice for installation and should be read carefully prior to fitting any unvented unit. OSO
Delta HP VIP cylinders are not suitable for gravity fed primary systems. In known hard water regions, precautions should
be taken to prevent limescale formation in hot water cylinders, in accordance with Building Regulation Part L, Domestic
Heating Compliance Guide.
This OSO cylinder must be installed by a competent person and be installed in compliance with the OSO Installation and
Maintenance Instructions, all current legislation, codes of practice and regulations governing the installation
of unvented hot water cylinders in force at the date of installation.
PLEASE READ THIS MANUAL BEFORE INSTALLATION AND LEAVE WITH THE CYLINDER . THE MANUAL
AND ATTACHED LOGBOOK SERVE AS THE CYLINDER GUARANTEE.
OSO Hotwater UK Ltd.
For capacities 200, 250 and 300 litres
seholder significant energy costs over the lifetime of the cylinder.
Delta HP VIP
Installation Manual
Contents
1 . General information ..........................2
2. Preparation of installation area.........4
3. Pipe connections..............................4
4. Commissioning and filling up............5
5. Draining and Flushing......................5
6. Electrical Installation.........................5
7. Safety and Servicing ........................ 9
8. Fault finding.....................................10
10. Log book ........................................13
Page no.
Delta HP VIP
1
