Using Navios Software
Cytometer Menu

Pause and Rotate

CAUTION
Risk of sample misidentification. Sample misidentification can occur if you use the
Pause and Rotate button and remove the sample tube and replace it with a
different sample tube. To prevent sample misidentification, do not swap sample
tubes when using Pause and Rotate button.
The Pause and Rotate button
MCL to a fixed position on the carousel so that additional reagent, for example, can be added to the
sample.
NOTE
To prevent excessive air from entering the flowcell, do not leave the Cytometer paused for extended
periods of time.
NOTE
When you use the Pause and Rotate button function, and remain in the Pause and Rotate state, the
Elapsed Time setting limit is ignored.

Idle Mode

The Idle Mode button
procedures can be performed.
Prime
The Prime button
with sheath solution.

Cleanse

The Cleanse
cleaning solution. The Cytometer will automatically transition to the idle mode
second cleanse cycle completes.

Laser Control

Laser Control
The
their lifetimes. The Blue laser cannot be placed into Standby mode by the software.
NOTE
If the Laser Control dialog is open when a laser changes state (e.g. from Warming Up to On), the
current state of the laser may not display correctly. Close the Laser Control dialog and re-open it to display
the current status of the lasers.
10-168
allows you to pause processing of a single sample and rotate the
places the Cytometer in Idle mode so that various cleaning and replacing
allows you to declog or remove bubbles or blockages from the sample line
button allows you to initiate a cycle to flush the instrument sample lines with
Dialog allows you to place the Red and Violet lasers into a Standby state to extend
after the 60
773232AH
