Single Prism Divider; Setting A New Single Prism Divider; Editing A Single Prism Divider - Beckman Coulter Navios Instructions For Use Manual

4
To delete Prism divider,
divider for the associated parameter is deleted altogether from this plot and from any other
plot that has this divider set. Any associated Prism plot changes its format and has its statistics
updated to reflect a smaller number of Prism divider(s).

Single Prism Divider

The Analysis > Create Prism Divider >
divider to be set on a single parameter histogram plot. Any displayed Prism plots is automatically
updated with the current Prism statistics. If the number of Prism dividers is changed during the
divider creation, the corresponding Prism plot also reflects this by changing its format according to
the number of active Prism dividers. For further explanation on Prism parameter see
NOTE
Navios software only allows one Prism divider per parameter. As a consequence modifying the Prism
divider of any parameter on any plot automatically updates the divider of that parameter if it is displayed
on any other plot. This includes both histogram and dual parameter plots.
See also:

Setting a New Single Prism Divider

Editing a Single Prism Divider

Setting a New Single Prism Divider
1
Highlight the required histogram plot.
2
Analysis > Create Prism Divider > Single Prism Divider
3
A Single Prism cursor
4
Position the cursor anywhere on the histogram, click to show the prism divider lines. If
is pressed at this point the operation is abandoned.
5
Move cursor to position crosshair then click to set position.
773232AH
on the divider to make it active and press
Single Prism Divider
is displayed in the current window.
Using Navios Software
(
Delete.
menu option allows a single Prism
.
10
Analysis Menu
)
The Prism
What is Prism?
( )
Esc
10-137
