Charcoal filter

• The charcoal filter should only be used if you
want to use the hood in recirculation mode.
• To do this you will need an original charcoal
filter (available from your local Service Force
Centre).
• The charcoal filter cannot be cleaned.
The filter should be replaced at least every
three months or more frequently if the hood is
used more than three hours per day.
• Replacing the charcoal filter
1. Remove the metal inlet grille.
2. Carefully turn the charcoal filters anti-
clockwise and remove them from the two
sides of the motor housing.
3. Place the new charcoal filters over the
sides of the motor housing, and turn
clockwise.
• Always specify the hood model code number
and serial number when ordering replacement
filters. This information is shown on the rating
plate located on the inside of the unit.
• The charcoal filter can be ordered from your
local Service Force Centre.
