B-Tech Mountlogic BT10 Installation Manual page 3

11
12
13
14
PLEASE KEEP THIS FOR FUTURE REFERENCE
REF PART NAME
1 TUBE ASSEMBLY
2 HEIGHT ADJUSTMENT COLLAR
3 FLOOR BASE
4 M22 NUT
5 RUBBER FEET
6 M6 X 25mm HEX SCREW
7 CLAMP BRACKET
8 SPEAKER CLAMP
9 M6 x 60mm SCREW
10 FOAM PAD
11 DUAL POINT SPEAKER FIXING
12 SINGLE POINT SPEAKER FIXING
13 SPEAKER CABLE PULL-THROUGH WIRE
14 4mm HEX KEY (FOR PART 6)
INTERFACE KIT
A M5 X 12mm SCREW
B M6 X 12mm SCREW
C ¼" X ½" UNC SCREW
D ¼" X ½" UNC SCREW (FOR PART E)
E THUMB WHEEL (FOR PART D)
B
A
D
QTY
2
2
2
2
6
2
2
4
4
4
2
2
1
1
4
4
4
2
2
C
E
5
