BT608
ATLAS ™ LOUDSPEAKER FLOOR STANDS
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 2 Speaker Stands
PLEASE KEEP THIS FOR FUTURE REFERENCE
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Product Dimensions..........................................................................................................................11
B-Tech Contact Details.....................................................................................................................12
4mm Hex Key
(supplied)
B-TECH AUDIO VIDEO MOUNTS
FEATURES
● Designed for loudspeakers up to 15kg (33lbs)
● Sound isolating loudspeaker floor stands
● Fillable columns for superior dampening
● Top and bottom isolating spikes provided
● Stand height: 80cm (31.5")
CONTENTS
TOOLS REQUIRED
Adjustable spanner
(optional)
www.btechavmounts.com
Level
(optional)
Dry sand and
funnel (optional)
Advertisement
Related Manuals for B-Tech ATLAS Mountlogic BT608/B
Summary of Contents for B-Tech ATLAS Mountlogic BT608/B
- Page 1 ● Top and bottom isolating spikes provided ● Stand height: 80cm (31.5") CONTENTS Installation Safety Notes........................2 Parts List.............................4 Installation Instructions........................6 Product Dimensions..........................11 B-Tech Contact Details........................12 TOOLS REQUIRED Adjustable spanner 4mm Hex Key Level Dry sand and (optional) (supplied) (optional) funnel (optional) B-TECH AUDIO VIDEO MOUNTS www.btechavmounts.com...
- Page 2 Do not attempt to install this product until all instructions and warnings have been read and properly understood. Please keep these instructions for future reference. B-Tech International Limited, its distributors and dealers are not liable or responsible for damage or injury caused by improper installation, improper use or failure to observe these safety instructions.
- Page 3 Niniejszy produkt musi być zamontowany na odpowiedniej powierzchni, a podczas użytkowania nie wolno przekraczać podanego maksymalnego obciążenia. A B-Tech International Ltd. recomenda que a instalação deste produto seja efectuada por um instalador de AV profissional ou outra pessoa devidamente habilitada. A B-Tech International Ltd. e os seus distribuidores e concessionários não são responsáveis por danos ou lesões causados por uma instalação incorrecta.
- Page 5 M6 X 25mm HEX SCREW M6 X 30mm BOTTOM SPIKE M6 NUT (5mm THICK) M6 X 15mm TOP SPIKE M6 NUT (3mm THICK) FOAM PAD FLOOR PROTECTION DISC 4mm HEX KEY (FOR PART 4) B-TECH LOGO STICKER PLEASE KEEP THIS FOR FUTURE REFERENCE...
- Page 7 ii. OPTIONAL - For enhanced performance the poles can be filled with sand.
- Page 8 Attach speaker platform to the poles.
- Page 9 Attach the spikes or alternative foam pads to the speaker platform. i. Spikes ii. Foam pads...
- Page 10 Attach spikes or foam pads to base plate. i. Spikes Optional - Floor Protection Discs ii. Foam Pads...
- Page 11 6.9" 125mm 4.9" 175mm 240mm 125mm 95mm 4.9" 3.7" 6.9" 9.4" 80mm 3.1" 95mm 240mm 3.7" 9.4" These instructions are intended as a guide only and B-Tech accepts no liability for the accuracy of the information contained in this document.
- Page 12 ©2013 B-Tech International Ltd. All rights reserved. B-Tech Audio Video Mounts is a division of B-Tech International Ltd. B-Tech, Better By Design and Mountlogic are registered trademarks of B-Tech International Ltd. All other brands and product names are trademarks of their respective owners.
