BT606
ATLAS ™ LOUDSPEAKER FLOOR STANDS
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 2 Speaker Stands
PLEASE KEEP THIS FOR FUTURE REFERENCE
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Product Dimensions..........................................................................................................................11
B-Tech Contact Details.....................................................................................................................12
4mm Hex Key
(supplied)
B-TECH AUDIO VIDEO MOUNTS
FEATURES
● Designed for loudspeakers up to 35kg (77lbs)
● Sound isolating loudspeaker floor stands
● Fillable columns for superior dampening
● Top and bottom isolating spikes provided
● Stand height: 60cm (23.6")
CONTENTS
TOOLS REQUIRED
Adjustable spanner
(optional)
Level
(optional)
Dry sand and
funnel (optional)
