BT11
STEALTH ™ HOME CINEMA
SPEAKER FLOOR STANDS
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 2 Speaker Stands
PLEASE KEEP THIS FOR FUTURE REFERENCE
REG DESIGN NO: 3003354
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Product Dimensions..........................................................................................................................11
B-Tech Contact Details.....................................................................................................................12
INSTALLATION TOOLS REQUIRED
Crosshead
screwdriver
B-TECH AUDIO VIDEO MOUNTS
FEATURES
● Designed for home cinema speakers up to 5kg (11lbs)
● Die-cast base for greater stability, esoteric performance
and to curb unwanted vibration
● Adjustment height: 685mm (27") - 1060mm (42")
● Suitable for speakers with single point, dual point
and keyhole fixings
● Alternative mounting platform supplied for speakers
without fixing holes
● Comprehensive mounting kit included
● Integrated cable management with
speaker cable pull-through wire
● Simple assembly and speaker mounting
● This pack contains 2 floor stands
CONTENTS
4mm Hex Key
(Supplied)
www.btechavmounts.com
22mm Spanner
(Supplied)
