WET/DRY VACUUM WDV-18

OPERATING MANUAL

Read this manual carefully and keep it near the machine, protected from liquids and other damaging substances.
Failure to follow the instructions may result in injury or damage to equipment and property.
Carefully inspect all components for freight damage. If such damage is discovered, file a "CONCEALED
DAMAGE REPORT" immediately with the delivering carrier.
The contents of this manual are based on the latest product information available at the time of publication. Pacific
Floorcare reserves the right to make changes or improvements without being obliged to apply changes to the
machines previously sold. Thank you for purchasing a Pacific Floorcare product.
New manuals can be downloaded from:
www.pacificfloorcare.com/manuals

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WDV-18 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pacific WDV-18

Summary of Contents for Pacific WDV-18

  • Page 1: Operating Manual

    DAMAGE REPORT” immediately with the delivering carrier. The contents of this manual are based on the latest product information available at the time of publication. Pacific Floorcare reserves the right to make changes or improvements without being obliged to apply changes to the machines previously sold.

  • Page 2: Specifications

    SPECIFICATIONS 1. Overall Machine Units Weight Dimensions Width at body inches Width at squeegee inches Length inches Height inches Noise 2. Wheels Type and Dimensions Rear wheels inches Front caster inches 3. Recovery Tank Capacity Draining Drain hose 1.5" inches 4.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SECTION PAGE # 1. SAFETY INSTRUCTIONS o GROUNDING o EXTENSION CORDS o LIFTING AND TRANSPORTATION o PREPARATION 2. SQUEEGEE 3. DRAINING THE MACHINE 4. COVER ASSEMBLY 5. OPTIONAL DRY FILTER 6. WIRING DIAGRAM 7. MAINTENANCE 8. TROUBLESHOOTING 9.

  • Page 4: Safety Instructions

    1. IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING VACUUM CLEANER WARNING: To reduce the risk of fire, electric shock, or injury:  Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing.

  • Page 5: Grounding

    GROUNDING INSTRUCTIONS This appliance must be grounded. If it should malfunction or break down, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord having an equipment-grounding conductor and grounding plug.

  • Page 6: Extension Cords

    USING EXTENSION CORDS The machine comes standard with a 50 foot, 16 gauge, 3 conductor cord (50’ 16/3 AWG). Do not use an extension cord in conjunction with the cord provided with the machine. Replacement cords must meet or exceed the specification of the original cord.

  • Page 7: Lifting And Transportation

    LIFTING AND TRANSPORTATION CAUTION: Two person lift. Never attempt to lift the machine alone.  Unplug the cord and wrap it securely around the handle  Secure the machine with straps during transport in a vehicle or trailer to prevent damage PREPARATION ...

  • Page 8: Squeegee

    2. SQUEEGEE Remove and install the Squeegee Head: Use the two black center knobs to remove and install the squeegee assembly from the machine. Remove and Install the Squeegee Blades: NOTE: The Squeegee Blades can be used twice by flipping them over to the other edge.
  • Page 9 Raise and lower the Squeegee Assembly:  Move the foot lever forward and allow the Squeegee Assembly to lower to the working position  Press the foot lever down and back to lock the Squeegee Assembly to the up position RAISE ...

  • Page 10: Draining The Machine

    3. DRAINING THE MACHINE NOTE: The vacuum must be turned off prior to draining the machine. DRAIN HOSE: 1. Back the machine up to the drain 2. Lift the drain hose from the holster 3. Remove the drain cap 4. Lay the hose into the drain 5.

  • Page 11: Cover Assembly

    4. COVER ASSEMBLY Open To open the cover assembly release the latch on the front of the machine and rotate the cover backwards until it stops. Close Rotate the cover forward, verify it is properly seated on the tank, and secure the latch to the catch on the tank.

  • Page 12: Optional Dry Filter

    5. DRY FILTER The optional dry filter is installed over the ball float. The dry filter must be removed for wet recovery. NOTE: Once the mount bracket is installed it does not need to be removed again.   1. Use the 2 screws and lock washers and install the bracket as shown 2.

  • Page 13: Maintenance

    7. MAINTENANCE * Read all safety instructions prior to performing maintenance WARNING: Always unplug the cord from the power outlet before performing any service, maintenance, or inspection of the machine. 1. After each usage:  Inspect cords, switches, caster and wheels for wear ...

  • Page 14: Cover Assembly

    9. PARTS DIAGRAMS 14  12/1/2017 ...

  • Page 15: Tank Assembly

      15  12/1/2017 ...
  • Page 16 16  12/1/2017 ...

  • Page 17: Squeegee Link Assembly

    17  12/1/2017 ...

  • Page 18: Optional Accessories Kit

        18  12/1/2017 ...

  • Page 19: Warranty Policy

    If unable to locate the Dealer, you may contact Pacific at the address listed herein for the location of the nearest Pacific repair center or agent or for other instructions pertaining to your warranty difficulty.
  • Page 20 http://www.pacificfloorcare.com/ 20  12/1/2017 ...
