PARTS & OPERATING MANUAL
WIDE AREA VACUUM
This operator's book has important information for the use and safe operation of this machine. Read
this book carefully before starting the machine. Keep this book and tell all operators to read the book. If
you do not follow the instructions, you can cause an injury or damage equipment, furniture or buildings.
For new books, please download your copy from our website www.pacificfloorcare.com or write to:
Pacific Floorcare
2259 S. Sheridan Drive
Muskegon, MI 49442-6252
Carefully inspect all components to ensure that there is no concealed freight damage. If such damage is
discovered, file a "CONCEALED DAMAGE REPORT" immediately with the delivering carrier.
The contents of this manual are based on the latest product information available at the time of
publication. Pacific reserves the right to make changes or improvements without notice.
Thank you for purchasing a Pacific Floorcare product. Warranty registration will allow us to better
serve you over the lifetime of the product. For quick and easy registration, go to:
WAV-26 UPRIGHT
PLEASE READ THIS BOOK
www.pacificfloorcare.com/Register Product.
Advertisement
Table of Contents
Related Manuals for Pacific WAV-26
Summary of Contents for Pacific WAV-26
- Page 1 Pacific reserves the right to make changes or improvements without notice. Thank you for purchasing a Pacific Floorcare product. Warranty registration will allow us to better serve you over the lifetime of the product. For quick and easy registration, go to:...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS IN THIS BOOK BEFORE USING THIS MACHINE! If you do not understand, ask your supervisor. WARNING: To reduce the risk of fire, electric shock, or injury: 1. DO NOT USE THIS VACUUM FOR PICK UP OF WET DEBRIS. 2. -
Page 3: Wiring Diagram
IMPORTANT SAFETY INSTRUCTIONS This machine must be grounded. If it should malfunction or break down, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This machine is equipped with a cord having an equipment-grounding conductor and grounding plug. -
Page 4: Operation
OPERATING INSTRUCTIONS WARNING! For the safe operation of this machine follow the instructions given in this booklet and the training given by your supervisor. Failure to do so can result in personal injury and/or damage to machine and property! DO NOT OPERATE MACHINE IN AN EXPLOSIVE ENVIRONMENT! NEVER USE THIS MACHINE TO PICK UP VOLATILE OR EXPLOSIVE MATERIALS! The model shown in this manual is intended for commercial use. -
Page 5: Maintenance
MAINTENANCE WEEKLY: 1. Inspect and clean the vacuum inlet filter. Open the bag door at the rear of the machine. At the bottom of the chamber is the inlet filter. Remove the filter from the machine by pulling it off of the vacuum motor. You may need to remove your bag to access this freely. - Page 6 WAV-26 WIDE AREA VACUUM - BRUSH ASSEMBLY ITEM PART NUMBER DESCRIPTION 650908 BRUSH, WAV 3 INCH DIAMETER 653601 GUARD, THREAD 654201 HOUSING, BEARING 657701 SHAFT, LONG 657702 SHAFT, SHORT 902035 BEARING, BRUSH SHAFT 962144 SCREW, FLAT, TAP, 4-24 X .50...
- Page 7 WAV-26 WIDE AREA VACUUM - LEVER & WHEEL ASSEMBLY ITEM PART NUMBER DESCRIPTION 655121 LABEL, HEIGHT, BRUSH 656701 PIN, TAPERED 657704 SHAFT, WLDMNT, WHEEL 659702 WHEEL, 1.5 DIA, 2.5L 920012 NUT, HEX, NYLOCK, .31 - 18 962044 SCREW, PAN, #10-32 X .50 962458 SCREW, SHLDR, .38, .31-16, 2.5...
- Page 8 WAV-26 WIDE AREA VACUUM - SHOE ASSEMBLY BRUSH ASSEMBLY WHEEL ASSEMBLY...
- Page 9 ITEM PART NUMBER DESCRIPTION 651306 BELT, V, BRUSH 652403 COLLAR, CLAMP, .38D 655201 MOTOR, BRUSH, WAV 656901 PULLEY, BRUSH 656902 PULLEY, BRUSH MOTOR 657903 SHOE, WELDMENT, BRUSH 962044 SCREW, PAN, #10-32 X .50 962105 SCREW, FLAT, #8-32 X .38 980022 WASHER, LOCK, SPLIT, #10 W168D SCREW, SET, .25-20, .25...
- Page 10 WAV-26 WIDE AREA VACUUM - BASE ASSEMBLY 5 13 SHOE ASSEMBLY...
- Page 11 ITEM PART NUMBER DESCRIPTION 651201 BUMPER, EXTRUSION, OPEN 653404 GASKET, SHOE, 0.38 X 0.09 654202 HOUSING, BASE 655120 LEVER, FOOT, HANDLE 658302 SPRING, EXTENSION 920012 NUT, HEX, NYLOCK, .31 - 18 962044 SCREW, PAN, #10-32 X .50 962144 SCREW, FLAT, TAP, 4-24 X .50 962458 SCREW, SHLDR, .38, .31-16, 2.5 962460...
- Page 16 655003 ON BOARD HAND TOOL KIT (OPTIONAL) For those that would like or require tools with the wide area vacuum, there is an on board tool kit available as an accessory. You must order the complete tool kit (#655003) to be able to attach it to your unit but replacement parts for this kit are listed below.
- Page 17 655003 ON BOARD HAND TOOL KIT SNAP PLACEMENT TEMPLATE Start screw & Cut Here Start screw & snap at these snap at these three points three points indicated by indicated by plus sign plus sign Cut Here Cut Here Left Right Side of Side of...
- Page 19 INSTRUCTIONS TO MOUNT 655003 ON BOARD HAND TOOL KIT 1. Cut out templates on page 17 2. Align the template up to the correct side (right or left) of the handle (Figure 1) 3. Use a powered drill to screw the self-tapping snaps into the handle at each “+”...
- Page 20 The inoperative machine or warranted parts must be delivered to the authorized dealer with shipping and delivery charges prepaid. If unable to locate the Dealer, you may contact Pacific at the address listed herein for the location of the nearest Pacific repair center or agent or for other instructions pertaining to your warranty difficulty.
