- Page 1 UVR16x2 Version V1.18 EN Freely programmable universal controller Programming Part 1: General information...
-
Page 3: Table Of Contents
Table of contents Principles ..........................5 Planning basics ..........................6 Designations ........................... 6 General information on programming parameters ................8 Date / time / location ......................9 Power reserve ..........................10 Value summary ........................11 Inputs ............................ 12 Programming the parameters ......................13 Sensor type and measured variable .................. - Page 4 Active CAN nodes ......................... 43 DL bus ........................... 44 DL settings ............................ 44 DL input ............................45 DL bus address and DL bus index .................... 45 Designation ..........................46 DL bus timeout ......................... 46 Sensor check ........................... 46 Measured variable ........................46 Value at timeout ........................
-
Page 5: Principles
Principles Principles This manual is designed as a guide to programming directly on the device, but also provides important information about the elements required for programming with the TAPPS 2 programming software (functions, inputs and outputs, etc.). Programming with TAPPS 2 is always recommended. It enables the programmer to draw (= program) all program operations in the form of a graphical flow chart and to define parameters for them accordingly. -
Page 6: Planning Basics
Principles Planning basics To ensure efficient programming, the following order must be observed: A prerequisite for programming and defining parameters is an accurate hydraulic scheme. Using that scheme, you must define what should be controlled and how. Based on the required control functions, you must define the sensor positions and draw them on the scheme. - Page 7 Principles View with designations defined previously An alphanumeric keyboard is provided for changing a designation or creating a new one. Up to 100 different designations can be defined by the user. The maximum number of characters per designation is 24. Designations defined previously are available for all elements (inputs, outputs, functions, fixed values, bus inputs and outputs).
-
Page 8: General Information On Programming Parameters
Principles General information on programming parameters for inputs, outputs, fixed values, functions, default settings, and CAN and DL inputs and outputs. Every entry must be finished by selecting If you want to discard your entries, select Example: Entering numeric values A keypad is displayed for entering numeric values. -
Page 9: Date / Time / Location
Date / time / location Date / time / location The "Date" and "Time" are shown in the status line at top right. Tapping that status field takes you to the menu for the date, time and location details. Example: The system value parameters are displayed first. -
Page 10: Power Reserve
The values for geographical latitude and longitude are used to determine the location-specific solar data. That data can be used in functions (e.g. shading function). The factory default settings for the GPS data are for the location of Technische Alternative in Amaliendorf, Austria. -
Page 11: Value Summary
Summary of values Value summary This menu item shows the current values for inputs 1 – 16, the DL inputs and the analogue and digital CAN inputs. The various values are displayed by tapping the group required. Example: Inputs... -
Page 12: Inputs
Inputs Inputs The controller has 16 inputs for analogue signals (measurements), digital signals (ON/OFF) or pulses. When this item is selected in the main menu, the inputs are displayed together with their designation and their current measurement or status. Example of a programmed system; input 1 is still unused:... -
Page 13: Programming The Parameters
Select the measured variable: Temperature Select the sensor type: KTY (2 kΩ = formerly Technische Alternative's standard type), PT 1000 (= current standard type), room sensors: RAS, RASPT, THEL thermocouple, KTY (1 kΩ), PT 100, PT 500, Ni1000, Ni1000 TK5000 Solar radiation (sensor type: GBS01) Voltage (inputs 1-6 and 9-16: max. - Page 14 Inputs Pulse input Inputs 15 and 16 can capture pulses with max. 20 Hz and a pulse duration of at least 25 ms (S0 pulses). Inputs 1 – 14 can capture pulses with max. 10 Hz and a pulse duration of at least 50 ms. Select the measured variable Wind speed A quotient must be entered for the "Wind speed"...
-
Page 15: Designation
Inputs Designation Enter the input designation by selecting a predefined designation from various designation groups or from the user defined designations. Sensor type Analogue / Temperature: General Generator Consumer Line Climate User (user defined designations) You can also assign a number from 1 to 16 to every designation. Sensor correction The option of sensor correction is available for the measured variables Temperature, Solar radiation, Humidity and Rain. -
Page 16: Sensor Check For Analogue Sensors
Inputs Sensor check for analogue sensors When "Sensor check" is active (setting: "Yes"), a short circuit or a lead break will automatically generate an error message: A warning symbol is displayed in the upper status line, and the defective sensor is shown with a red border around it in the "Inputs" menu. Example: Short-circuit of sensor 1... -
Page 17: Assignment Of The Possible Sensor Types To The Inputs
1000 1045 1091 1114 1138 1186 1235 1285 1337 1390 1444 1500 TK5000 The standard type used by Technische Alternative is PT1000. KTY (2 kΩ) was the factory-fitted standard type until 2010/2011. PT100, PT500: As these sensors are more susceptible to external interference, their sensor leads must be screened and the Average time should be increased. -
Page 18: Outputs
Outputs Outputs The controller has 16 outputs. Tapping the outputs display in the upper status line takes you to the "Outputs" menu. Undefined outputs are hidden. When selected, the outputs are displayed together with their designation and their current status (see chapter "Display on screen"). -
Page 19: Programming The Parameters
Outputs Programming the parameters Once the required output is selected, the output type can be defined. First, you must specify the basic output type. Output type The following different output types exist, although they are not available for selection for all outputs: Switching output Output pair 0 - 10 V... - Page 20 Outputs All switching outputs A start delay and a run-on time can be defined for all switching outputs. All outputs Manual mode can be restricted to certain user groups (User, Technician, Expert) for all outputs. Outputs 12 to 16 as analogue outputs These outputs provide a voltage between 0 and 10 V, e.g.
- Page 21 Outputs Output status of the analogue outputs For the output status you can define whether the ON status should be issued above or below an adjustable threshold. Example: If the analogue output is over 3.00 V, the output status switches from OFF to ON. Depending on the technical attributes of the pump being controlled, it may thus be possible to set the output status to be ON only when the...
- Page 22 Outputs Display in the Outputs menu The display in the menu shows the operating state of the analogue output. The output status can be changed by selecting it. Auto: Output issued according to the source and scaling Manual: Adjustable value Manual/OFF: Output issued according to "Dominant off"...
-
Page 23: Designation
Outputs Designation Enter the output designation by selecting a predefined designation from various designation groups or from the user defined designations. General Climate User (user defined designations) You can also assign a number from 1 to 16 to every designation. Overview of outputs Output Output pairs... -
Page 24: Output Meter
Outputs Output meter Selecting this icon allows you to see the hours run and pulses (times switched on) for every output. Example: For output 1, the meter reading since 01/01/2014 can be viewed. If you tap the button, you will be asked whether you want to delete the total meter readings and the "Previous day"... - Page 25 Outputs Below the hours run, the pulses (how many times switched on) can be viewed. The meter shows the total number of pulses (times switched on), the number of pulses on the previous day and the number today. If you tap the button, you will be asked whether you want to delete the pulses counted today.
-
Page 26: Display Of Links
Outputs Display of links When you select this icon, the output's links to the functions will be displayed. Example: In this example, output 1 is controlled by two functions, and it has just been switched on by function 29 (Solar1). Tapping a function takes you directly to the menu for that function. -
Page 27: Blocking Protection
Outputs Blocking protection Circulating pumps which do not run for a long period (e.g. heating circuit pump during the summer) often encounter start-up problems as a result of corrosion. This problem can be avoided by starting the pump periodically for 30 seconds. The Blocking protection menu item added after output 16 allows you to specify a time and all the outputs to receive blocking protection. -
Page 28: Display On Screen
Outputs Display on screen Example of a system already programmed: Outputs 1, 4 and 5 are switched on Outputs 3 and 4 are in manual mode The switched-on outputs are highlighted in green. Outputs in manual mode are marked with a hand symbol under the output number. Example: Outputs switched dominant (by the "Message"... -
Page 29: Fixed Values
Fixed values Fixed values In this menu you can define up to 64 fixed values, which can be used as input variables for functions, for example. When this item is selected in the main menu, the fixed values already defined are displayed together with their designation and their current value or status. -
Page 30: Programming The Parameters
Fixed values Programming the parameters Example: Fixed value 1 Fixed value type Once the required fixed value is selected, the fixed value type can be defined. Digital Analogue Pulse Digital Select the measured variable: Off / On No / Yes Select whether the status can be changed via a selection box or simply by a click. -
Page 31: Analogue
Fixed values Analogue Select from a wide range of units and dimensions After assigning the designation, you must define the permitted limits and the current fixed value. The value can be adjusted in the menu within those limits. Example: Changing an analogue fixed value Tapping a button with a light background allows you to change the fixed value via a keypad. -
Page 32: Pulse
Fixed values Pulse A fixed value of this type allows short pulses to be generated by tapping it in the menu “Fixed values”. Example: A pulse can also be triggered in the menu of the fixed value by tapping. Function quantity Select the function quantity: When activated, either an ON pulse (from OFF to ON) or an OFF pulse (from ON to OFF) will be generated,... -
Page 33: Messages
Messages Messages This menu item displays activated messages. Example: Message 21 is active. If there is at least one active message, a warning symbol will appear in the upper status line. If the message has been hidden, the pop-up window for the message can be displayed by tapping the warning symbol. -
Page 34: Can Bus
CAN bus CAN bus The CAN network allows communication between CAN bus devices. When analogue or digital values are sent via CAN outputs, other CAN bus devices can utilise those values as CAN inputs. This menu contains all of the information and settings needed to set up a CANopen network. Up to 62 CAN bus devices can be operated in one network. -
Page 35: Datalogging
CAN bus Datalogging This menu is not visible in the User mode. This menu is used to define the parameters for CAN datalogging of analogue and digital values. CAN datalogging requires at least version 1.13 on the C.M.I. datalogger. CAN datalogging is only possible with the C.M.I. datalogger. In contrast to data recording via the DL bus, the data to be logged via the CAN-bus can be freely selected. -
Page 36: Can Settings
CAN bus CAN settings Node Define a unique CAN node number for the device (setting range: 1 – 62). The device with node number 1 provides the time stamp for all other CAN bus devices. Designation Every controller can be given its own designation. Bus rate The standard bus rate of the CAN network is 50 kbit/s (50 kBd), which is specified for most CAN bus devices. -
Page 37: Can Analogue Inputs
CAN bus CAN analogue inputs Up to 64 CAN analogue inputs can be programmed. They are defined by specifying the transmission node number and the number of the transmission node's CAN output. Node number After the node number of the transmission node is entered, the other settings can be specified. The number of a CAN analogue output is taken from the device with that node number and applied here. -
Page 38: Designation
CAN bus Designation Every CAN input can be given its own designation. The designation can be selected from various designation groups or can be user defined, as for the other controller inputs. Example: CAN bus timeout Define the timeout time for the CAN input (minimum value: 5 minutes). As long as the information continues to be read from the CAN bus, the network error for the CAN input will be "No". -
Page 39: Value At Timeout
CAN bus Value at timeout This setting is only displayed if "Measured variable" is set to "User". If the timeout time is exceeded, you can define here whether the controller should issue the last value transmitted ("Unchanged") or a definable substitute value. Sensor correction This setting is only displayed if "Measured variable"... -
Page 40: Can Digital Inputs
CAN bus CAN digital inputs Up to 64 CAN digital inputs can be programmed. They are defined by specifying the transmission node number and the number of the transmission node's CAN output. Their parameters are programmed in almost exactly the same way as for the CAN analogue inputs. Under Measured variable / User the Display for the CAN digital input can be changed from Off / On to No / Yes and you can define whether the controller should issue the last status transmitted ("Unchanged") or a definable substitute status when the timeout time is exceeded. -
Page 41: Designation And Transmission Condition
CAN bus Designation and transmission condition Every CAN analogue output can be given its own designation. The designation can be selected from various designation groups or can be user defined, as for the inputs. Example: Transmission condition Example: If change > 1.0 K If the current value has changed by more than 1.0 K compared to the last transmitted value, a new transmission is made. -
Page 42: Can Digital Outputs
CAN bus CAN digital outputs Up to 32 CAN digital outputs can be programmed. They are defined by specifying the source in the controller. Their parameters are programmed in exactly the same way as for the CAN analogue outputs except for the transmission conditions. -
Page 43: Active Can Nodes
CAN bus Active CAN nodes Updating the view Tapping the button displays the active CAN nodes in the CAN bus network. "Status" displays the controller's CAN bus status. Following a controller start the status changes automatically, according to a predefined process, from init. → preop(erational) → operat(ional). Only then is it possible to communicate with other CAN bus devices. -
Page 44: Dl Bus
DL bus DL bus The DL bus acts as a bus cable for various sensors and/or for datalogging by C.M.I. or D-LOGG. The DL bus is a bidirectional data link and is only compatible with products from Technische Alternative. The DL bus network operates independently of the CAN bus network. This menu contains all of the information and settings needed to set up a DL bus network. -
Page 45: Dl Input
DL bus DL input Sensor values from DL bus sensors are transferred via a DL input. Up to 32 DL inputs can be programmed. Example: Programming the parameters of DL input 1 Select: Analogue or digital DL bus address and DL bus index Every DL sensor must have its own DL bus address. -
Page 46: Designation
DL bus Designation Every DL input can be given its own designation. The designation can be selected from various designation groups or can be user defined, as for the other controller inputs. Example: DL bus timeout As long as the information continues to be read from the DL bus, the network error for the DL input will be "No". -
Page 47: Sensor Correction
DL bus Sensor correction This setting is only displayed if "Measured variable" is set to "User". The value of the DL input can be corrected by applying a fixed differential value. Sensor error This setting is only displayed if sensor check is active and "Measured variable" is set to "User". When "Sensor check"... -
Page 48: Dl Output
DL bus DL output Analogue and digital values can be transmitted to the DL bus network via a DL output. For example, a digital command to activate an O2-DL O sensor can be output. Example: Programming the parameters of DL output 1 Specify the source in the controller which supplies the value for the DL output. -
Page 49: Designation And Destination Address
DL bus Designation and destination address Specify the designation and the destination address of the DL sensor to be activated. Provision has been made for the specification of an index number, but there is not yet any DL bus device which requires that specification. For the activation of the O sensor, the index therefore has no effect and can be ignored. -
Page 50: General Settings
General settings General settings Displayed in Expert mode only Displayed in Technician or Expert mode only This menu allows settings to be made which then take effect for all other menus and displays. Language Select the display language Brightness Select the brightness of the display to match the surroundings (setting range: 5.0 – 100.0 % Display timeout The display will be switched off if the user does not do anything for the period of time set here. -
Page 51: Simulation
General settings Simulation Option of activating the simulation mode (only possible in Expert mode): No averaging of the outside temperature in heating circuit control. All temperature inputs are measured as PT1000 sensors, even if a different sensor type is defined. The RAS features of room sensors are ignored. -
Page 52: User Defined Designations
General settings User defined designations In this menu, you can enter, change or delete user defined designations for all elements of the controller. This menu can only be selected from within the Technician or Expert level. View with designations defined previously An alphanumeric keyboard is provided for changing a designation or creating a new one. -
Page 53: User
User User Current user Select whether the user is an Expert, Technician or User. To enter the Technician or Expert level a password must be entered, which can be set by the programmer. When function data is loaded from the Expert or Technician level, the controller returns to the User level and applies the programmed passwords. - Page 54 User List of permitted actions User Displays and permitted actions Function overview with options for control Access to main menu only if enabled for "User" in the "General settings" Summary of values Inputs: display only, no access to the parameters Outputs: changes to the output status of the outputs enabled for User, display of hours run, no access to the parameters Fixed values: changes to the value or status of the fixed values enabled for...
-
Page 55: Version And Serial Number
Version Version and serial number This menu item displays the operating system version (firmware). The display then shows the serial number, internal production data and the names of the current function data and function overview. The serial number is also visible on the controller's rating plate (upper side panel). -
Page 56: Data Administration
Data administration Data administration Only visible in Technician or Expert mode You can perform the following actions in this menu: Save, load or delete function data Load firmware Load or delete a function overview Display the status of the data transfer Restart the controller Function data Display the current function... -
Page 57: Load
Data administration Load… Function data can be loaded from the SD card onto the controller. Multiple function data can be saved to the SD card. After selecting the function data required (*.dat file), you will be prompted to specify how the meter readings and the heat meter's calibration values should be treated. -
Page 58: Deleting, Renaming And Sending Saved Files
Data administration Deleting, renaming and sending saved files In order to rename or delete a saved file, tap the file icon. The following options then appear for selection: Delete file Rename file Send file to selected nodes Return from this selection by tapping the file icon again. Delete file A confirmation prompt appears, which you can confirm by tapping Tapping... -
Page 59: Save
Data administration Save… The current function data can be saved to the SD card. You can give the function data a name of your own. More than one set of function data can be saved. Example: In this example there are already several sets of function data saved on the SD card. If you want to save the function under a new name, tap . -
Page 60: Firmware Load
Data administration Firmware Load… Firmware (= operating system, file *.bin) can be loaded from the SD card onto the controller or other X2 devices on the CAN bus. More than one operating system version may be saved on the SD card. As when loading function data, the saved firmware files can be deleted, renamed or loaded onto other X2 devices. -
Page 61: Status
Data administration Status This indicates whether a data administration transfer of data from the SD card to the controller or vice versa was successful or not. This status display does not apply to data transfers from another controller, a C.M.I. or a CAN monitor. -
Page 62: Restart
Data administration Restart At the end of the "Data admin" menu, there is an option to restart the controller following a confirmation prompt, without disconnecting the controller from the network. Reset Pressing the reset button on the front of the controller briefly (with a narrow-tip pen) and releasing it before the beep ends will restart the controller (= reset). -
Page 63: Calibration
Data administration Calibration If the touch-sensitive points on the touchscreen no longer align with the background graphics, making it difficult to operate the controller, you can re-adjust the touchscreen using "Calibration". You can start calibration by pressing the touchscreen surface when the TA logo is displayed after the controller is started. -
Page 64: System Values
System values System values This menu displays the status of system values that are available for selection as the source for function input variables and CAN and DL outputs. The system values are divided into 4 groups: General system values When programmed accordingly, these system values allow monitoring of the controller system. - Page 65 System values Time system values Date system values Second (seconds of the current time) Minute (minutes of the current time) Month Hour (hour of the current time) Year (without the century) Second pulse Day of the week (starting with Monday) Minute pulse Calendar week Hour pulse...
-
Page 66: Function Overview
Function overview Function overview The function overview will only be displayed with controller version V1.04 or higher. Programming of the function overview is done using the "TA-Designer" software and is described in that software's help file. If multiple UVR16x2 controllers or X2 devices in the system are linked by CAN BUS, values from these other devices can be displayed as well. -
Page 67: Led Indicator Light
LED indicator light LED indicator light The indicator light can indicate a variety of statuses by means of three colours. Indications at controller start Indicator light Explanation Steady red light The controller is booting up (= start routine after switching on, resetting or updating) or Steady orange light Hardware is initialising after booting up... -
Page 68: Technical Data Uvr16X2 (Relay Versions)
Technical data UVR16x2 (Relay versions) Temperature sensors of type PT1000, KTY (2 kΩ/25 °C), KTY All inputs (1 kΩ/25 °C), PT100, PT500, Ni1000, Ni1000TK5000 and room sensors RAS or RASPT, radiation sensor GBS01, thermocouple THEL, humidity sensor RFS, rain sensor RES01, pulses max. 10 Hz (e.g. -
Page 69: Technical Data Uvr16X2
Technical data UVR16x2…-D (Triac versions) Differences in the original properties compared with relay version: Output 1, 2, 6, 7 Triac outputs Outputs 3, 4, 8-11 Relay outputs, partially with N/C and N/O contacts Relay changeover contact – potential-free Output 5 Outputs 12 - 16 Analogue outputs 0-10 V (max. - Page 72 Legal notice This operating manual is protected by copyright. Use outside the copyright requires the consent of Technische Alternative elektronische Steuerungsgerätegesellschaft m. b. H. This applies in particular to reproductions, translations and electronic media. elektronische Steuerungsgerätegesellschaft m. b. H. A-3872 Amaliendorf Langestrasse 124, Austria...
