Summary of Contents for Telrad CPE7000 Indoor
-
Page 2: Important Note
Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 3: Europe - Eu Declaration Of Conformity
Europe – EU Declaration of Conformity This device complies with the essential requirements of the R&TTE Directive 1999/5/CE. The following test methods have been applied in order to prove presumption of conformity with the essential requirements of the R&TTE Directive 1999/5/CE: EN 60950-1：2006＋A11＋A1＋A12＋A2: 2013 EN62311 : 2008 EN 300 328 V1.8.1: 2012... - Page 4 Ελληνική ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ [name of manufacturer] ΔΗΛΩΝΕΙ ΟΤΙ [type of equipment] [Greek] ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ. Français Par la présente [nom du fabricant] déclare que l'appareil [type d'appareil] est conforme [French] aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE.
-
Page 5: Industry Canada Statement
Industry Canada statement: This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil est conforme aux CNR exemptes de licence d'Industrie Canada. - Page 6 CPE7000 Indoor LED Indicators Num. Type Logo Color Action Description Power on (System is booting , Blue Solid ON or WiFi is disabled) Power & Wi-Fi Purple Solid ON WiFi is enabled Purple Blinking WiFi is transmitting data Blue Blinking...
- Page 7 CPE7000 Indoor Connectors: 1. SIM card Slot Cover: Open the cover and insert SIM card into the slot with right direction. 2. Telephone Port (RJ-11): Connect your telephone to Indoor CPE with a RJ-11 telephone cable. 3. LAN Port (RJ-45): Port for connecting PC, hub and switch or other network equipment by RJ-45 Ethernet cable.
-
Page 8: Installation
Installation Please follow the steps below to install the device: Step1: Connect the device LAN port to your PC with a RJ-45 Ethernet cable. Step2: Insert SIM card into the device with right direction. Step3: Insert the power cord into the LTE Indoor CPE's DC-12V power jack; and insert the plug into power outlet. -
Page 9: Easy Setup
Easy Setup Please follow the steps below to configure your device through the web interface: Step1: Open the Web browser (Internet Explorer) and enter the default IP address of the IDU CPE : http://192.168.254.251 Step2: Enter IDU administrator login username/password to access the web management interface. - Page 10 Wi-Fi Setting Step1: Select WIFI from main menu. Then screen will display the default setting of SSID, radio channel, working mode, WiFi MAC and SSID broadcast. Step2: Specify a radio channel, working mode, bandwidth in Settings page. Step3: Specify a SSID (Service Set ID), SSID broadcast and Security in Multiple SSID page.
