Connecting to the Target Board

Attach one end of the six-conductor ribbon cable to the Smart Cable six-pin DBG connec-
tor, as shown in Figure 1
tor on the target board. Ensure that pin 1 on the ribbon cable (indicated by the dark stripe)
is aligned with pin 1 on the target connector. To learn more about connecting the Ethernet
Smart Cable to your target board, refer to the
Note (TN0035) or the
Using the Ethernet Smart Cable on ZDS II –
eZ80Acclaim! Versions Earlier than 4.10.0
Observe the following procedure to obtain the IP address of the Ethernet Smart Cable
when configured for DHCP.
1. Download the ESCScan utility installation file from
Downloadable Software
SD0012.
2. Run the installation file to install it to your local drive.
3. Run the
escscan.exe
similar to the example screenshot shown in Figure 8.
UM020705-1012
on page 3. Attach the free end of the ribbon cable to the connec-
Z8 Encore! Design for Debug Technical Note
category, in which you'll find ESCScan listed as Product ID
application file from the installation directory; it will appear
Figure 8. escscan.exe Application Screenshot
eZ80Acclaim! Design for Debug Technical
the Zilog
Ethernet Smart Cable
User Manual
(TN0036).
Store; simply click the
Page 11 of 13
