energy costs. Set to Ecological, the heat source will be selected
based on ecological parameters, resulting in a minimisation of
primary energy consumption.
# Code
[A.6.7] [7‑04] Defines whether switching between
operation modes is either economically
or ecologically optimised.
▪ 0 (Economical)(default): reduction of
energy costs
▪ 1 (Ecological): reduction of primary
energy
necessarily energy costs
Primary energy factor
The primary energy factor indicates how many units of primary
energy (natural gas, crude oil, or other fossil fuels, prior to
undergoing any human-made conversions or transformations) are
needed to obtain 1 unit of a certain (secondary) energy source, such
as electricity. The primary energy factor for natural gas is 1.
Assuming an average electricity production efficiency (including
transportation losses) of 40%, the primary energy factor for
electricity equals 2.5 (=1/0.40). The primary energy factor allows you
to compare 2 different energy sources. In this case, the primary
energy use of the heat pump is compared to the natural gas use of
the gas boiler.
# Code
N/A [7‑03] Compares the primary energy use of the
heat pump with that of the boiler.
Range: 0~6, step: 0.1 (default: 2.5)
INFORMATION
▪ The primary energy factor can always be set, but is
only used in case the savings mode is set to
Ecological.
▪ To set electricity price values, do NOT use overview
settings. Set them in the menu structure instead
([7.4.5.1], [7.4.5.2], and [7.4.5.3]). For more information
on how to set the energy prices, see the operation
manual and the user reference guide.
Space heating control
The basic required settings in order to configure the space heating of
your system are described in this chapter. The weather-dependent
installer settings define the parameters for the weather-dependent
operation of the unit. When weather-dependent operation is active,
the water temperature is determined automatically depending on the
outdoor temperature. Low outdoor temperatures will result in warmer
water and vice versa. During weather-dependent operation, the user
has the possibility to shift up or down the target water temperature
by a maximum of 10°C.
See the user reference guide and/or operation manual for more
details about this function.
CHYHBH05+08AA + EHYKOMB33A
Daikin hybrid for multi heat pump – heat pump module
4P471761-1A – 2017.10
Description
consumption, but not
Description
Leaving water temperature: Main zone
# Code
[A.3.1.1.1] N/A LWT setpoint mode:
▪ Fixed: The desired leaving water
temperature is:
▪ NOT weather-dependent (i.e. does
▪ fixed in time (i.e., NOT scheduled)
▪ Weather dep. (default): The desired
leaving water temperature is:
▪ weather-dependent (i.e. depends
▪ fixed in time (i.e., NOT scheduled)
# Code
[7.7.1.1] [1‑00] Set weather-dependent heating:
T t
[1‑01]
[1‑02]
[1-02]
[1‑03]
[1-03]
▪ T
(main)
▪ T
# Code
[7.7.1.1] [1‑00] << continuation
[1‑01] ▪ [1‑00]:
temperature. –40°C~+5°C (default: –
[1‑02]
10°C)
[1‑03]
▪ [1‑01]:
temperature.
15°C).
▪ [1‑02]:
temperature
temperature equals or drops below
the low ambient temperature.
[9‑01]°C~[9‑00]°C (default: 60°C).
Note: This value should be higher
than [1-03] as for low outdoor
temperatures
required.
▪ [1‑03]:
temperature
temperature equals or rises above
the high ambient temperature.
[9‑01]°C~min(45, [9‑00])°C (default:
35°C).
Note: This value should be lower
than [1-02] as for high outdoor
temperatures less warm water is
required.
8 Configuration
Description
NOT depend on the outdoor
ambient temperature)
on the outdoor ambient
temperature)
Description
[1-00] [1-01]
: Target leaving water temperature
t
: Outdoor temperature
a
continued >>
Description
Low outdoor ambient
High outdoor ambient
10°C~25°C (default:
Desired leaving water
when the outdoor
warmer water
Desired leaving water
when the outdoor
Installer reference guide
T a
is
