Digital Loggers Web Power Switch 7 User Manual page 17

Specs
Alert Beeper
Applications
Circuit Breaker
Clock / RTC
Control / Display
Dimensions
EEPROM
Enclosure
Ethernet Interface
FCC Testing
Humidity
Input Power Cord
Inlet and Outlet Rating UL, CSA 15A, 120VAC only
Input Frequency
Operating Temperature -30º to 170ºF, -34º to 77ºC
Options - User
Power Supply Rating
Password Transmission Encrypted, base 64
Power Dissipation
Power Fail Hold-Over
Power-Up Modes
Relay Contact Spec
Software Controls
Surge Protection
Size (Single-Pack Carton) 2.4x7.7x15.8"
Weight (bare)
14
73dBa at 12". Programmable.
Commercial, industrial, and residential remote
power control and reboot. Indoor use only.
Manual reset, 15A Thermal, UL
15 year Li battery, NTP support
Reset -to-factory-default switch, 2x16 Backlit LCD
w/ PowerSave
Outside 1.6x5.8x13" 12.3"Between mtg. holes
512Kb I2C Standard
Aluminum chassis, double grounded. Injection
Molded high-temp thermoplastic base plate.
Vented 2 sides. Fanless.
10/100 autosensing, Static IP, TCP port selectable,
8 pin RJ-45 w/ internal FCC ltering
Part 15 S/D
8-80% RH Operating. Non-condensing. No liquid
exposure is permoossible.
Removable C19 14AWG 6' length standard
Power supply - DC-400Hz
Right-Angle 19" rack-mount bracket.
90-240V, AC/DC Autosensing
Movable HTTP port for security
3.9W Typ Max (all on) <3 W idle
350ms minimum (all relays on)
Last used settings, all power on or o , sequential
on or run BASIC program script
15-25A AC/DC, 1/2HP
Individual outlets on/o , all on/
o /cycle. Net settings, Web UI
3600WMetal Oxide Varistor
Single unit 3.6 lbs excl. cord & packaging.
Web Power Switch 7 17
