language. Internal batteries have an estimated 15-year lifetime.
Scripting Example
The controller can be used as-is in most applcations, or
customized using a BASIC scripting language. A full description is
beyond the scope of this manual, so please visit our website for
other examples and a full command list. Here's a simple example:
a lighting economizer.
This simple program shuts the lights off at 9:30PM daily. Users
can turn them on using a web browser. Should they forget to turn
them off, the power switch takes care of it.
Find more scripting examples, and a full list of commands at
digital-loggers.com/Scripting.html
Windows Logging and Email Noti cation
A Windows utility can be used to record activity and notify you
when specifi ed trigger events occur. This utility also logs power
consumption and generates reports when used in conjunction with
our
larger power controllers.
Learn more and download the utility
free at
digital-loggers.com/pcl.html
16
Web Power Switch 7
digital-loggers.com
