ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
PARTS LIST
PART
MATERIAL CODE
NO.
1
KTS022W-CS01
2
62KTS022WB102
You will need the following tools:
- Phillips Screwdriver (Not Included)
Step 1:
Insert the seat assembly (#1) into the back
assembly (#2). Make sure align the holes of them.
See Figure 1.
!
Do not discard any of the packaging until you have checked that you have all the parts and pack
of fittings.
!
Keep children away during assembly. This item contains small parts which can be swallowed by
children. Children should always be under direct adult supervision while using the product.
!
Retain the assembly instructions for future reference.
!
Please quote following FQC NO. when contacting service center.
INTENDED FOR RESIDENTIAL USE ONLY.
KTS022W
PART
Q'TY
1
SEAT ASSEMBLY
1
BACK ASSEMBLY
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 2
-WM
PART
MATERIAL CODE
NO.
3
17C17A1904001Y4
4
61K022WC00001BA
FIGURE 1
COURTYARD CREATIONS INC.
PART
Q'TY
4
SCREW ST3.9*13
1
CUSHION
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Courtyard Creations KTS022W-WM
Summary of Contents for Courtyard Creations KTS022W-WM
- Page 1 Children should always be under direct adult supervision while using the product. Retain the assembly instructions for future reference. Please quote following FQC NO. when contacting service center. SERVICE CENTER TOLL FREE NO. TEL: 1-877-539-7436 FAX: 1-877-539-7439 DON’T RETURN TO STORE! STOP COURTYARD CREATIONS INC. PAGE 1 OF 2...
-
Page 2: Cleaning And Maintenance
FIGURE 2 FIGURE 3 Step 2: Step 3: Fasten the back assembly (#2) to the seat Place the cushion (#4) onto the chair. Secure the assembly (#1) by using screws (#3). See Figure 2. cushion to the chair by using the plastic snaps. See Figure 3.
