Black Box SWI069A Manual

Network power switch
Hide thumbs
Table of Contents

Advertisement

Quick Links

© Copyright 2000. Black Box Corporation. All rights reserved.
1000 Park Drive
•
Lawrence, PA 15055-1018
•
724-746-5500
•
Fax 724-746-0746

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWI069A and is the answer not in the manual?

Questions and answers

Related Manuals for Black Box SWI069A

Summary of Contents for Black Box SWI069A

  • Page 1 © Copyright 2000. Black Box Corporation. All rights reserved. 1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax 724-746-0746...
  • Page 2 Order toll-free in the U.S. 24 hours, 7 A.M. Monday to midnight Friday: 877-877-BBOX SUPPORT FREE technical support, 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 INFORMATION Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com • E-mail: info@blackbox.com...
  • Page 4 TRADEMARKS TRADEMARKS USED IN THIS MANUAL ProComm is a registered trademark of DATASTORM TECHNOLOGIES, INC.™ UNIX is a registered trademark of UNIX Systems Laboratories, Inc. Any other trademarks used in this manual are acknowledged to be the property of the trademark owners.
  • Page 5 NETWORK POWER SWITCH FEDERAL COMMUNICATIONS COMMISSION CANADIAN DEPARTMENT OF COMMUNICATIONS RADIO FREQUENCY INTERFERENCE STATEMENTS This equipment generates, uses, and can radiate radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart J of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference when the equipment is...
  • Page 6 NOM STATEMENT NORMAS OFICIALES MEXICANAS (NOM) ELECTRICAL SAFETY STATEMENT INSTRUCCIONES DE SEGURIDAD 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
  • Page 7 NETWORK POWER SWITCH 12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada. 13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos colocados sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del aparato.

  • Page 8: Table Of Contents

    CONTENTS Contents Chapter Page 1. Specifications ......................7 2. Introduction......................8 2.1 Description ....................8 2.2 Features ......................8 2.3 Physical Description ..................9 2.3.1 Front Panel ..................9 2.3.2 Back Panel ..................10 3. Installation ......................11 3.1 Option Switches ..................11 3.2 Console Port Connection................12 3.3 Connecting an External Modem ..............12 3.4 Connecting the Network Cable ..............12 3.5 Power Supply Connection ................12 3.6 Connection to Switched Outlets ..............13...

  • Page 9: Chapter Page

    5.6 Operating Tips ..................30 6. Saving and Restoring Configuration Parameters ..........31 6.1 Sending Parameters to a File ..............31 6.2 Restoring Saved Parameters..............31 Appendix A: Interface Descriptions ................33 Appendix B: Troubleshooting ..................34 B.1 Calling Black Box ..................34 B.2 Shipping and Packaging................34...

  • Page 10: Specifications

    CHAPTER 1: Specifications 1. Specifications Power Input/Output AC Inputs — Dual bus circuits, 15 Amps each Voltage — 100–140 VAC, 50/60 Hz Connectors — IEC-320 inlet, line cords supplied AC Outputs — (8) outputs: 1–4 Bus A, 5–8 Bus B (15-Amp rating), NEMA 5-15 outlet Load —...

  • Page 11: Introduction

    NETWORK POWER SWITCH 2. Introduction 2.1 Description Network equipment sometimes locks up, requiring a service call just to flip the power switch to perform a simple reboot. The Network Power Switch gives network administrators the ability to perform this function from anywhere on the LAN/WAN, or if the network is down, to simply dial in from a modem for out-of- band power control.

  • Page 12: Physical Description

    CHAPTER 2: Introduction 2.3 Physical Description 2.3.1 F RONT ANEL The LEDs on the front panel are described below. ON: Lights when AC Power is applied to the Network Power Switch. RDY: Flashes when the Network Power Switch is ready to receive commands. RXD: Lights when the Network Power Switch receives commands.

  • Page 13: Back Panel

    NETWORK POWER SWITCH 2.3.2 B ANEL Bus B (Plugs 5–8): Includes the following components: A) Power Inlet with Cable Clamp B) Circuit Breaker: 15 Amps C) Switched AC Outlets (5–8): Each outlet can switch up to 15 Amps. The total for all four outlets must not exceed 15 Amps. Bus A (Plugs 1–4): Same as item 1 above, except that the Bus A power inlet supplies power to plugs 1 through 4.

  • Page 14: Installation

    CHAPTER 3: Installation 3. Installation 3.1 Option Switches The Option Switches select default settings for the Baud Rate, Command Echo, Boot Delay, and Disconnect Timeout. Default settings selected via the Option Switches will be used when the unit is reset to default parameters as described in Section 3.7.

  • Page 15: Console Port Connection

    NETWORK POWER SWITCH Switch Function Down Default Baud Rate 38.4 kbps 9600 bps (factory setting) Default Boot Delay 10 sec. 5 sec. (factory setting) Default Command Echo Enable Disable (factory setting) Default Disconnect Timeout 30 min. 2 min. (factory setting) 3.2 Console Port Connection The male DB9 connector, which is used for connection to a local PC or control device.

  • Page 16: Connection To Switched Outlets

    CHAPTER 3: Installation 3.6 Connection to Switched Outlets The main power switch must be on in order for the Network Power Switch to operate. When the Switch is powered on, the eight AC outlets will be switched on or off, as specified by the user-defined Power-Up Default (see Section 4.5). Each outlet can switch up to 15 Amps AC.

  • Page 17: Default Button (Local)

    NETWORK POWER SWITCH 3.7.2 D EFAULT UTTON OCAL Typically, this method is used when devices have not been connected to the Network Power Switch, and you have immediate access to the installation site. NOTE This method will temporarily switch all plugs off. Set the Master Power Switch to the off position.

  • Page 18: Configuration

    CHAPTER 4: Configuration 4. Configuration 4.1 System Mode and User Mode In order to restrict access to sensitive command functions, the Network Power Switch features two separate operating modes: System Mode and User Mode. System Mode allows access to all configuration menus, command functions, and status screens.

  • Page 19: Communicating With The Network Power Switch

    NETWORK POWER SWITCH 4.2 Communicating with the Network Power Switch In order to configure the Network Power Switch or invoke command functions, you must first connect to the Network Power Switch and access command mode. 1. The Network Power Switch is transparent to parity and will accept 7-bit or 8-bit characters, but will always answer back at 8 bits, no parity.
  • Page 20 CHAPTER 4: Configuration Network Power Switch v2.04 Site ID: YOURSITE, INC. Commands: Display Display this Help Screen /S[P] Display Plug Status, [P] with Passwords Configuration View/Set General Parameters /P [n] View/Set Plug Parameters View/Set Network Parameters Download Configuration to File Control --------------------------------------- Set Plugs to Default Settings...

  • Page 21: Network Power Switch Command/Menu Conventions

    NETWORK POWER SWITCH 4.3 Network Power Switch Command/Menu Conventions When invoking Network Power Switch commands and selecting items from configuration menus, note that: • All Network Power Switch commands can be invoked at the NPS> command prompt, or from the General Parameters Menu, Port Parameters Menus, or Network Parameters Menu.
  • Page 22 CHAPTER 4: Configuration 3. Modem Initialization String: To define the Modem Initialization String (up to 16 characters), type 3 and press [Enter]. For more information on the initialization string, refer to the user’s guide for your external modem. Make certain that the modem is set to auto-answer in one ring. GENERAL PARAMETERS: 1.

  • Page 23: Plug Parameters

    NETWORK POWER SWITCH commands. For example, if the Disconnect Timeout is set at 5 minutes, the Network Power Switch will automatically disconnect after 5 minutes of inactivity. Type 7, press [Enter], and follow the instructions in the submenu. 8. Plug Confirmation: Enables/Disables the plug confirmation feature. When enabled, the Network Power Switch will display a prompt before performing Boot/On/Off operations, and will also display the System Status screen after these commands are successfully completed.
  • Page 24 CHAPTER 4: Configuration PLUG #1 PARAMETERS: 1. Plug Name: (undefined) 2. Password: (undefined) 3. Boot Delay: 5 Sec 4. Power Up Default: Enter Selection or <ESC> to Exit... Figure 4. Plug Parameters Menu (Plug 1 Shown). 1. Plug Name: (Up to 16 Characters) Assigns a name to the plug. Typically the name describes the equipment connected to the outlet.

  • Page 25: Network Parameters

    NETWORK POWER SWITCH NETWORK PARAMETERS: 1. IP Address: (undefined) 2. Subnet Mask: (undefined) 3. Gateway Address: (undefined) 4. IP Security MAC Address: 00-40-05-5e-f3-90 Enter Selection or <ESC> to Exit… Figure 5. Network Parameters Menu (System Mode Only). 4.6 Network Parameters In order to communicate with the Network Power Switch via network, the IP Address, Subnet Mask, and Gateway Address must first be defined via the Network Parameters menu.

  • Page 26: Implementing Ip Security

    CHAPTER 4: Configuration IP SECURITY 1. Security Mask #1: (none) 2. Mask #1 Action: Permit 3. Security Mask #2: (none) 4. Mask #2 Action: Permit 5. Security Mask #3: (none) 6. Mask #3 Action: Permit 7. Security Mask #4: (none) 8.

  • Page 27: Save Configuration Parameters

    NETWORK POWER SWITCH Security Mask #1: 255.255.255.255 Mask #1 Action: Deny Security Mask #2: 192.1.1.5 Mask #2 Action: Permit Since 255 is a wild card, Mask #1 blocks all IP Address. Mask #2 then specifically grants access to 192.1.1.5 only. Example 2: Allow access only by addresses that begin with 192.

  • Page 28: Operation

    CHAPTER 5: Operation 5. Operation Your PC or Control Device must send ASCII characters at the same data rate as the Network Power Switch. The Switch accepts 8 bits with no parity, or 7 bits with even or odd parity, but will always answer back at 8 bits, no parity. 5.1 Access the Network Power Switch Command Mode In order to invoke commands, you must first access the Network Power Switch Command Mode.

  • Page 29: Displaying Plug Status

    NETWORK POWER SWITCH 5.2 Displaying Plug Status The Status Screens display the On/Off state and user-defined parameters for the switched plugs. There are two Network Power Switch Status Screens: the System Status Screen and the User Status Screen. The System Status Screen (Figure 6) lists On/Off status and parameters for all eight plugs.

  • Page 30: Boot/On/Off Commands

    CHAPTER 5: Operation 5.3 Boot/On/Off Commands These commands are used to Boot or change the On/Off status of the Network Power Switch’s eight switched plugs. Commands can be applied to one, several, or all owned plugs. Plugs may be specified by name or number. NOTE When User Mode is active, commands will only be applied to plugs owned by the User’s password.

  • Page 31: Applying Commands To Several Plugs

    NETWORK POWER SWITCH 5.3.1 A PPLYING OMMANDS TO EVERAL LUGS Boot/On/Off commands can be applied to one plug, several plugs, a range of plugs, or all plugs as described below: NOTE When commands are applied to several plugs, the Network Power Switch will delay for approximately 1 second between plug operations.

  • Page 32: The Default Command

    CHAPTER 5: Operation 5.4 The Default Command The Default Command (/D) sets all plugs to their default On/Off status. The default status is set using the Plug Parameters menus described in Section 4.5. Plugs will be set to these defaults when /D is invoked, or after a power interruption.

  • Page 33: Operating Tips

    Modem Port has priority over the Console Port. 2. Ping Packet Size: The Network Power Switch will not accept Ping Packets larger than approximately 1000 bytes. If you have any questions about configuring or operating the Network Power Switch, please contact Black Box Technical Support at 724-746-5500.

  • Page 34: Saving And Restoring Configuration Parameters

    CHAPTER 6: Saving and Restoring Configuration Parameters 6. Saving and Restoring Configuration Parameters After you’ve properly configured the Network Power Switch, you can download parameters and save them as an ASCII text file. Later, if the configuration is accidentally altered, the file with the saved parameters can be uploaded to automatically reconfigure the unit without manually assigning each parameter.
  • Page 35 NETWORK POWER SWITCH 3. Upload the file with the saved parameters. If necessary, key in the file name and directory path. 4. When the upload is complete, make certain to terminate the communications program’s upload mode. NOTE The current On/Off status of each Network Power Switch plug will not be saved or restored.

  • Page 36: Appendix A: Interface Descriptions

    APPENDIX A: Interface Descriptions Appendix A. Interface Descriptions Console Port Interface RS-232 Port Modem Port Interface RS-232 Port...

  • Page 37: Appendix B: Troubleshooting

    • Package it carefully. We recommend that you use the original container. • If you are shipping the Network Power Switch for repair, make sure you include everything that came in the original package. Before you ship, contact Black Box to get a Return Materials Authorization (RMA) number.
