User manual
Generators
(open frame type)
Read and follow all safety
WARNING!
warnings and instructions carefully before
using this machine. Failure to follow the
warnings and instructions may result in
electric shock, fire and/or serious injury.
Save this manual for future reference.
Products covered by this
ATTENTION!
manual will vary in appearance, assembly,
inclusions, description and packaging.
NOTE! This manual covers multiple styles
of generators as well as options /
accessories that may not be suitable for
the machine you have purchased.
IMPORTANT! A UPS or power filter is
recommended for powering expensive
equipment (all models).
Advertisement
Table of Contents
Related Manuals for GENPOWER GENPTL40IGPRACAB
Summary of Contents for GENPOWER GENPTL40IGPRACAB
- Page 1 User manual Generators (open frame type) Read and follow all safety WARNING! warnings and instructions carefully before using this machine. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save this manual for future reference. Products covered by this ATTENTION! manual will vary in appearance, assembly,...
-
Page 2: Table Of Contents
Index Index ................................1 Safety Warnings ............................2 Parts Diagram ............................4 Before use ..............................5 Starting the engine ............................. 7 Stopping the Engine ........................... 9 Using your Generator ..........................10 Balancing power on a 3-Phase generator ....................12 Maintenance ............................. 13 Transporting/Storage .......................... -
Page 3: Safety Warnings
Safety Warnings or bystanders could result as well as the risk of serious or fatal burn injuries, General Safety Warnings damage to the generator. Do not use check for fuel leakage. If fuel leakage is this unit for any job other than those for found, do not start or run the engine until It is important you read which it is intended as described in this... - Page 4 IMPORTANT! - Machine, Fuel handling or Electrical Safety If you are not familiar with safe operation / handling of this machine, or are in any way unsure of any object of this products suitability or correct use for your application you should complete training conducted by a person or organisation qualified in safe use and training related to this product.
-
Page 5: Parts Diagram
Parts Diagram ATTENTION! Products covered by this manual will vary in appearance, assembly, inclusions, description and packaging. 1. AC socket 11. Air filter* 21. AC Socket 2. Circuit Breaker reset button 12. Pull Start chord & grip 22. Voltmeter* 3. Voltmeter* 13. -
Page 6: Before Use
Before Use Connecting the Battery (if equipped) For safety the connection plugs were disconnected from battery before shipping. Please follow the below steps to connect your battery. Bolt the RED wire to the POSITIVE terminal and the BLACK wire to the NEGATIVE terminal on the battery. - Page 7 Adding Fuel CAUTION! Use only CAUTION! Before WARNING! Do not use clean, fresh non-ethanol fuel substitutes such as refuelling ensure the unleaded (4-stroke ethanol, methanol or engine is switched off petrol models) or clean, biofuel. Using such fuel and is cool. fresh commercially will cause damage and NOTE! It is normal for...
-
Page 8: Starting The Engine
Starting the engine CAUTION! Do not allow CAUTION! The starter ATTENTION! Disconnect the starter grip to snap grip can be drawn back all appliances before back. Return it slowly by very quickly before you starting engine. hand. can release it. This may pull your hand forcefully toward the engine and cause an injury. - Page 9 Remote control start (if equipped) Applicable generators may be fitted with an isolator switch; you must have this switch turned on to be able to use the remote control to start / stop the engine. Some model generators must have the ignition key or engine switch in the “ON”...
-
Page 10: Stopping The Engine
Stopping the Engine To stop the engine in an emergency, turn the engine switch to the OFF position. In normal use: 1. Switch OFF all connected equipment and pull the inserted plug out. 2. Switch OFF the “ AC Circuit Breaker” 3. -
Page 11: Using Your Generator
Using your Generator Fuel WARNING! Be careful WARNING! Fuel is WARNING! Do not extremely flammable and is overfill the fuel tank. not to spill fuel when explosive under certain refuelling. Spilled fuel or After refuelling, make conditions. sure the fuel filter cap is fuel vapour may ignite. - Page 12 Oil alert system (if equipped) ATTENTION! Generators WARNING! This is a ATTENTION! Check Oil must operate on a level backup feature only; level before each use or surface or engine warranty is void if run every 3 hours of damage may occur. with low oil.
-
Page 13: Balancing Power On A 3-Phase Generator
Balancing power on a 3-Phase generator IMPORTANT! This section only applied to 3-Phase capable generators. WARNING! Failure to balance output on a 3-Phase generator can cause damage and void warranty. IMPORTANT! Only one third of the total generator capacity is available from any single phase 240v outlet. WARNING! 3-Phase generators are not suitable for running power-hungry appliances from 240v Single Phase outlets. -
Page 14: Maintenance
Residual Current Device (RCD) Circuit Breaker (if equipped) WARNING! If the RCD is tripped due to earth leakage of a connected device or appliance, have the device inspected and repaired by a qualified technician. If the device is faulty, do not use it until it is safe to do so. - Page 15 Spark Plug Service CAUTION! The Spark plug must be securely CAUTION! Never use a spark plug with an tightened. An improperly tightened plug can improper heat range. become very hot and possibly damage the generator. To ensure proper engine operation, the spark plug must be properly gapped and free of deposits. 1.
- Page 16 290714114500...
- Page 17 290714114500...
-
Page 18: Transporting/Storage
Transporting/Storage To prevent fuel spillage when transporting or during temporary storage, the generator should be secured upright in its normal operating position, with the engine switch and fuel switch OFF and the fuel cap vent closed. It is also reocmmmended the remote control switch be turned off to avoid accidental starting. -
Page 19: Troubleshooting
Troubleshooting The Engine Will Not Start No power from outlet socket Disconnect the electrical Is there fuel in the Is the output If ‘no’ Refill the fuel tank If ‘no’ appliances. Stop tank? indicator ON? and re-start the engine. If ‘yes’ Is the engine switch Turn the engine Is the engine... -
Page 20: Specifications
Continuous Rated Output when considering whether a product is right for your needs. NOTE! Power produced by generators can fluctuate. IMPORTANT! UPS or power filter recommended for powering expensive equipment (all models). GENPTL40IGPRACAB Manufacturer: GenPower Engine Type: 4-Stroke... - Page 21 GENPTL60IGPRACAA Manufacturer: GenPower Engine Type: 4-Stroke Engine Displacement: 208cc Engine Output: 8hp Fuel Type: 95+ Non Ethanol Petrol AC Voltage: 240/415V 50Hz Continuous Rated Output: 2.5kW (2700W) OSE Max output: 4.5kVA @ 0.8 cos (Other Seller Equivalent) DC Output: 12V - 8.3A...
-
Page 22: Appendix
Appendix 290714114500... - Page 23 Some experts believe the incorrect or prolonged use of almost any product could cause serious injury or death. For information that may reduce your risk of serious injury or death consult thepoints below and additionall y , the information available at www.datastreamserver.com/safety - Consult all documentation, packaging and - The product has been supplied by a general merchandise...
