This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions;
(1) This device may not cause harmful interference.
(2) This device may accept any interference received, including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate this device.
firstechllc.com | compustar.com | dronemobile.com | momentocam.com | arcticstart.com
User Manual
By Firstech LLC, Version: 1.0
Applicable to the following remote:
RF-2WG15R-FM
RF-1WG15R-FM
Advertisement
Table of Contents
Related Manuals for Firstech Compustar FMX RF-2WG15R-FM
Summary of Contents for Firstech Compustar FMX RF-2WG15R-FM
- Page 1 User Manual By Firstech LLC, Version: 1.0 Applicable to the following remote: RF-2WG15R-FM RF-1WG15R-FM This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions; (1) This device may not cause harmful interference. (2) This device may accept any interference received, including interference that may cause undesired operation.
-
Page 2: Table Of Contents
Introduction ............................3 Warranty Coverage ..........................3 Quick Reference Valet Mode ....................... 4 Remote Maintenance ........................... 4 2 Way Remote Button Functions ......................4 Remote Option Menu Table........................5 Remote LED Functions ........................6 1 Way Remote Button Functions ......................6 General Features ............................ -
Page 3: Introduction
Introduction Thank you for purchasing a Firstech system for your vehicle. Please take a minute to review this entire manual. Note that this manual applies to the 2 Way 4 Button G15 LED FMX Remotes whether you purchased the ALARM IT, START IT, or MAX IT system. This manual also supports the 1 Way Remote that is included with your RF Kit. -
Page 4: Quick Reference Valet Mode
Quick Reference Valet Mode When servicing or loaning your vehicle to others, the system should be placed in Valet Mode. Valet Mode prevents the system from remote starting and disables all alarm functions. IMPORTANT: While in Valet mode the remote will still control power lock and unlock systems. The parking lights will not flash. The system can be put into valet one of three ways: 1. -
Page 5: Remote Option Menu Table
Half second Unlocks doors and/or disarms alarm. Twice 2.5 seconds Resets the run time or turbo timer Three Aux 1. Triggers the auxiliary 1 output Half second (most commonly used for rear defrost or Once window roll-down). Trunk release. Triggers the trunk release 2.5 seconds Twice output and opens the vehicle’s trunk. -
Page 6: Remote Led Functions
Remote LED Functions Your remote will communicate to and from your vehicle while in range. The unique icon LED design will display LED’s indicating lock/unlock status, remote start confirmation, remaining run time and much more. Event LED Icon LED Duration Chirp(s) Runtime Remaining: Once every 5 seconds... -
Page 7: General Features
2.5 seconds Option programming menu 2 - Installers Only. Half second Activates passive arming (vehicle will arm/lock 30 seconds after the vehicle is disarmed) Activates timer start mode. Timer start mode has multiple programmable settings: Half second duration settings, temperature settings and self start settings. Activates the built in Turbo Timer function. -
Page 8: Automatic Transmission Remote Start Function
10 and 20 seconds prior to passively locking and arming. If you want the system to passively arm and not passively lock, ask your local Firstech dealer Automatic Transmission Remote Start Function Hold the Key/Start button for 2.5 seconds to remote start an automatic transmission... -
Page 9: Trunk Release
STEP 3: Exit the vehicle and close the door. The vehicle’s doors will lock/arm and then engine will shut down. If the vehicle’s engine does not shut off, your door trigger may not be functioning properly. Discontinue use of the remote start feature and take your vehicle to a local authorized Firstech dealer for service. -
Page 10: Shock Sensor On/Off
Upon lock/arm and unlock/disarm, you can eliminate vehicle’s audible confirmation by muting the siren. Normally, the siren will chirp once to indicate the system is locked/armed and twice to indicate the system is unlocked/disarmed. To mute the siren, tap the Lock and Unlock buttons simultaneously for a half second. -
Page 11: Drive Lock/Ignition Controlled Door Locks
The vehicle’s parking lights will flash twice and/or siren chirp twice to confirm drive lock is on. IMPORTANT: Drive lock mode requires additional work from your authorized Firstech dealer. Drive lock has two settings;... -
Page 12: Rps Touch And Rps (Remote Paging Sensor)
RPS Touch and RPS (Remote Paging Sensor) The RPS is an optional feature. The car call/RPS feature uses a small sensor that is mounted on the inside of your windshield. RPS Touch (Remote Paging Sensor) The new RPS touch has multiple features including: remote paging, 4 digit pin unlock/disarm, and arm/lock. -
Page 13: Timer Start Mode
STEP 1: Disarm/unlock the alarm (remote must be programmed first) and choose a 4 digit code. You can not have zeros. STEP 2: Turn ignition key to the “on” position and leave the driver’s door open. STEP 3: Knock on the windshield in front of the RPS a total of 5 times (each time you knock the LED on the RPS will flash RED). -
Page 14: Cold/Hot Start Mode
If you purchased an Alarm or Alarm and Remote Start system, you can add additional sensors from Firstech. Protect your investment by adding a battery back up system to protect main power or a FT-DAS sensor to protect custom wheels and tires. -
Page 15: Programming Remotes On Push To Start (Pts) Vehicles
Programming Remotes on Push to Start (PTS) Vehicles Most Push to Start vehicles do not have a key that you can turn between the On and Acc positions. This makes programming remotes difficult. We have a different set of steps for programming remotes. STEP 1: Press the PTS button to turn the vehicle to the ‘On’... -
Page 16: Remote Start Shutdown Error Codes
Remote Start Shutdown Error Codes If the remote start sequence has been completed and the vehicle shuts down, the vehicle’s parking lights will flash 4 times, pause then flash again with the error code. Tap the Start on 2 Way remotes to initiate the shutdown error codes. -
Page 17: Limited Lifetime Warranty
Limited Lifetime Warranty Firstech, LLC Warrants to the original purchaser that this product shall be free of defects in material and workmanship under normal use and circumstances for the period of time that the original owner of this product owns the vehicle in which it is installed; except that the remote controller unit for the period of one year from the date of installation to the original owner of this product.
