Firstech BLADE Series Install Manual

FTI-CDP1 - Vehicle Coverage and Preparation Notes
Make Model
DL-CH8
RAM 3500 TIP Start Diesel
Firmware: Covered vehicles use either BLADE-AL(DL)-CH8, confirm application, flash module, and update the controller
firmware before installing.
Install: Type 2 vehicles use the included CAN extension cable to source CAN data from the green CAN junction block
(left side of the dash) or from the BCM (pin#25, CANH, brown, pin #26, CANL, yellow).
Lighting: Type B parking lights use the 10-pin connector, secure unused 6-pin connector for safety.
Ignition: Common ignition provisions are listed in the BLADE diagram, ignition is also available at the vehicle BCM
(connector C5/E, pin #27, pink/white).
Hood: Hood status wire is available at the vehicle BCM, connector C1, pin #11 (violet/blue).
FTI-CDP1 - Installation and Configuration Notes
Required CAN connections.
A
Not required.
B
Vehicle hood status ( - ).
C
Ignition jumper, NO CONNECTION required.
D
Ignition connection.
E
Year
2018
CONNECT TO PINK.
BLADE FEATURE COVERAGE
Install CAN Lights
Park / Auto
Type 2 CJB Type B
IGN Hood I/O Changes
Green White/Blue
BCM BCM
CM7000/7200 Cut loop for A/T
CM-900S/900AS
CM900AS/900S Jumper
