Summary of Contents for EVT EC5000
- Page 1 EyeCheck 5xxx Specification GmbH, Haid-und-Neu-Str. 7, 76131 Karlsruhe, Germany www.evt-web.com, info@evt-web.com Tel.: 0049 721 668 004 23 0...
-
Page 2: Table Of Contents
6.3.4 Delayed Triggering......................18 6.4 General input..........................18 6.4.1 Active Triggering Edge....................18 6.4.2 Input Signal Glitch Filter....................18 6.4.3 Input Delay........................18 6.5 General Output.........................19 6.6 Camera Recovery........................19 7. Dimensions.............................20 GmbH, Haid-und-Neu-Str. 7, 76131 Karlsruhe, Germany www.evt-web.com, info@evt-web.com Tel.: 0049 721 668 004 23 0... -
Page 3: Feature
6. 2 programmable constant current LED drivers 7. Free standard accessories: I/O module and connecting cables 8. Rock-solid system stability, operating temperature from -40°C to +80°C GmbH, Haid-und-Neu-Str. 7, 76131 Karlsruhe, Germany www.evt-web.com, info@evt-web.com Tel.: 0049 721 668 004 23 0... -
Page 4: Application
2. Application 2.1 Application Surface inspection, High-accuracy measuring • OCR, Bar code, DMC, QR recognition • Matching, Classification • 2.2 Application Diagram GmbH, Haid-und-Neu-Str. 7, 76131 Karlsruhe, Germany www.evt-web.com, info@evt-web.com Tel.: 0049 721 668 004 23 0... -
Page 5: Specification
3. Specification 3.1 Product Model – Camera Max. Model Type Resolution Shutter Sensor Description EC5000 Mono 640x480 Global SHARP CCD RJ33B4AA0DT, 1/3", 7.4um EC5000c Color 640x480 Global SHARP CCD RJ33B3AA0DT, 1/3", 7.4um EC5010 Mono 640x480 Global SHARP CCD RJ33B4AA0DT, 1/3", 7.4um... -
Page 6: Product Model - I/O Module
90° 300mA EC-LR60 624nm 60° 100mA EC-LY60 Yellow 590nm 60° 100mA EC-LG60 Green 525nm 60° 100mA EC-LB60 Blue 470nm 60° 100mA EC-LI60 850nm 60° 100mA GmbH, Haid-und-Neu-Str. 7, 76131 Karlsruhe, Germany www.evt-web.com, info@evt-web.com Tel.: 0049 721 668 004 23 0... -
Page 7: Specifications
Eight photo-isolated output ports (Max current 0.3A, Max voltage 40VDC) LED Driver Two constant current LED drivers, output current adjustable: Internal LED driver only supports EVT LED board, with max output 0.3A/24V External LED driver (in IO module) supports general LED illuminator, with max output 1.5A/24V... -
Page 8: System Block Diagram
4 weeks. 3.5 System Block Diagram The block diagram of EyeCheck 5xxx series is as follows: GmbH, Haid-und-Neu-Str. 7, 76131 Karlsruhe, Germany www.evt-web.com, info@evt-web.com Tel.: 0049 721 668 004 23 0... -
Page 9: Interface - Camera
Notice: the 3-meter HDMI cable with M3 setscrew may not match all monitors because of the connector size. Some monitors are ensured to match the cable. The ports for I/O module and HDMI monitor look the same. However EVT provides fault- tolerant design which allows misplug without any damage to the camera. -
Page 10: Interface - I/O Module
The power consumption of the camera is 12W max. However, it takes more power consumption when using I/O module for external LED driving. So power supply with over 24V/24 is recommended. GmbH, Haid-und-Neu-Str. 7, 76131 Karlsruhe, Germany www.evt-web.com, info@evt-web.com Tel.: 0049 721 668 004 23 0... -
Page 11: Trigger Input
The max. output voltage is 24V (so it supports LED illuminator under 24VDC), and the max. output current is 1.5A (1500mA). User can rapidly adjust the current (or brightness of LED) from 0mA to 1500mA by software. GmbH, Haid-und-Neu-Str. 7, 76131 Karlsruhe, Germany www.evt-web.com, info@evt-web.com Tel.: 0049 721 668 004 23 0... -
Page 12: General Input Port
+2.8 to +30V is recognized as high level, with input current below 2mA; voltage out of range from -30V to +30V may damage the circuit. It is recommended to use PNP output type sensors, switches or PLC. GmbH, Haid-und-Neu-Str. 7, 76131 Karlsruhe, Germany www.evt-web.com, info@evt-web.com Tel.: 0049 721 668 004 23 0... -
Page 13: General Output Ports
API sent command OPEN; when command CLOSE is sent, the MOSFET conducts and sinks up to 350mA current. The camera default setting is no output (OPEN) when power GmbH, Haid-und-Neu-Str. 7, 76131 Karlsruhe, Germany www.evt-web.com, info@evt-web.com Tel.: 0049 721 668 004 23 0... -
Page 14: Rs232 Ports
OS from desktop. GmbH, Haid-und-Neu-Str. 7, 76131 Karlsruhe, Germany www.evt-web.com, info@evt-web.com Tel.: 0049 721 668 004 23 0... -
Page 15: Functions Instructions
If using illegal parameters (lower than the minimum value) to set shutter time by API, the camera will set the only according to the minimum value. Model Minimum Value (us) Note EC5000 & EC5000c EC5010 & EC5010c EC5300 & EC5300c EC5200 & EC5200c EC5400 &... -
Page 16: Trigger Input
The time period between general input and user’s program receiving message is called input delay. This input delay time may be variable because of OS thread scheduling and user programming style, usually range from 0.1ms to 1ms. GmbH, Haid-und-Neu-Str. 7, 76131 Karlsruhe, Germany www.evt-web.com, info@evt-web.com Tel.: 0049 721 668 004 23 0... -
Page 17: General Output
0.1ms to 1ms. 6.6 Camera Recovery The EyeCheck 5xxx supports recovery function, including BIOS and OS recovery. User can easily recover the camera to factory default status. GmbH, Haid-und-Neu-Str. 7, 76131 Karlsruhe, Germany www.evt-web.com, info@evt-web.com Tel.: 0049 721 668 004 23 0... -
Page 18: Dimensions
7. Dimensions GmbH, Haid-und-Neu-Str. 7, 76131 Karlsruhe, Germany www.evt-web.com, info@evt-web.com Tel.: 0049 721 668 004 23 0...
