How to use this manual
1. Microphone In/Line In jack
2 channel audio cable (available
2.
separately)
3. Headphone jack
Connecting your DAT player
Connectivity or Features
1. Microphone In/Line In jack
3.50mm (1/8-inch) stereo-to-RCA cable
2.
(available separately)
3. Line Out jacks
Connecting your MD player
file://C:\Users\Lee Fong\AppData\Local\Temp\~hhC3B1.htm
Connects to the Headphone jack on your playback device.
Connects the playback device to your Sound Blaster X-Fi Notebook.
Connects to the Microphone In/Line In jack on your Sound Blaster X-
Fi Notebook.
Connects to the Line Out jacks on your playback device.
Connects the playback device to your Sound Blaster X-Fi
Notebook.
Connects to the Microphone In/Line In jack on your Sound
Blaster X-Fi Notebook.
Page 12 of 19
Description
17/4/2008
